1273769GE1 Suzuki BEARING, UPPER, Price: 19.34$, Weight: 0.04kg
| Make | Number | Name | Availability | Weight, kg | Ship in, Days | Price |
|---|---|---|---|---|---|---|
Suzuki |
1273769GE1 |
BEARING, UPPER |
0 |
0.04 |
2-3 |
19.34$ |
| Not Available | ||||||
Substitutions
| Make | Number | Name | Availability | Weight, kg | Processing, days | Price | |
|---|---|---|---|---|---|---|---|
| Taiho |
CAMSHAFT BEARING
|
0 |
0.037
|
4-5
|
10.50$
|
Not Available |
Compatibility
| Model Code | Model Code Breakdown | Model Year From | Spec | Diagram |
|---|---|---|---|---|
| RB21S-6 | エンジン;ドア数;駆動;ミッション | 200512 | セダン1.5L;HB1.5L;セダン1.8L;HB1.8L | View |
| Model Code | Model Code Breakdown | Model Year From | Spec | Diagram |
|---|---|---|---|---|
| ME34S-7 | 駆動;略称 | 200906 | MW 2WD;MW 4WD | View |
| Model Code | Model Code Breakdown | Diagram |
|---|---|---|
| TD54W-2 | ドア数;エンジン;ミッション;ギヤ数;略称;エアバッグ;ESP | View |
| Model | Model Code | Modification | Type | Diagram |
|---|---|---|---|---|
| JB416X | JB416 | JB416X-6 (E02,E22) | TYPE 6 | View |
| Model | Model Code | Modification | Diagram |
|---|---|---|---|
| RM413 | RM413 | RM413 (Magyar) | View |
| Model Code | Model Code Breakdown | Diagram |
|---|---|---|
| JB43W-7 | ミッション;略称 | View |
| Model Code | Model Code Breakdown | Model Year From | Spec | Diagram |
|---|---|---|---|---|
| ZC31S-3 | 駆動;ミッション;グレード;ディスチャージ | 200902 | M16A | View |
| Model | Model Code | Modification | Diagram |
|---|---|---|---|
| RH418 | RH418 | RH418-4 | View |
| Model Code | Model Code Breakdown | Model Year From | Spec | Diagram |
|---|---|---|---|---|
| YA11S-3 | 駆動;ドア数;略称 | 200901 | 1.5 2WD5DR;1.5 4WD5DR;1.5 2WD4DR | View |
| Engine | Model Code | Modification | Diagram |
|---|---|---|---|
| M16A | AKK416 | AKK416-2 (E10,E96,E61,E48,E85,E94) | View |
| Engine | Model Code | Modification | Type | Diagram |
|---|---|---|---|---|
| M16A | AZG416 | AZG416-5 | TYPE 5 | View |
| Engine | Model Code | Modification | Diagram |
|---|---|---|---|
| M16A | APK416 | APK416 (E10,E61,E96,E71,E85,E94) | View |
| Model Code | Model Code Breakdown | Model Year From | Spec | Diagram |
|---|---|---|---|---|
| MA34S-7 | 駆動;略称;デアイサ | 200906 | 4WD;2WD | View |
| Model Code | Modification | Type | Diagram |
|---|---|---|---|
| RC413 | RC413-2 | TYPE 2 | View |
Upper Engine Bearing Shell for Suzuki Powertrains
This precision upper bearing shell supports the crankshaft/connecting rod journal, keeping oil clearance correct and friction low. It’s an OEM‑grade replacement designed for reliable lubrication and long service life in daily use or harsh city traffic.
Why this part is needed
The bearing centers the rotating journal, forms a stable oil film, and protects the block and crank from metal-to-metal contact. Correct clearance means quiet running, stable oil pressure, and clean starts even when hot.
How it works
Oil feeds through the block and groove to the bearing surface. As the crank spins, a hydrodynamic wedge of oil lifts the journal off the shell. A tri‑metal structure (steel back, copper/lead layer, soft overlay) resists load, embeds small debris, and prevents scuffing.
What happens if it fails ⚠️
Knocking at low RPM, low oil pressure, shiny flakes in oil, and rising temps. Continued driving risks spun bearing, scored crankshaft, loss of power, and full engine seizure. Fix early to save the crank.
Tech tips
- Measure journals; check clearance with Plastigauge.
- Use assembly lube, clean oil passages, fresh filter.
- Tighten to spec; pair with matching lower shell if required.
Compatibility
- Jimny
- Swift
- Grand Vitara
- Sx4/S-Cross
- Vitara
- Liana
- Ignis
- Wagonr+
- Aerio
- Chevrolet Cruize/Mw
- Escudo
- Kei/Swift
- Sx4
- Wagon R
