  • 1864078K00 Suzuki SENSOR ASSY, KNOCK

1864078K00 Suzuki SENSOR ASSY, KNOCK, Price: 74.54$, Weight: 0.06kg

    • Make Number Name Availability Weight, kg Ship in, Days Price

    Suzuki

    1864078K00

    SENSOR ASSY, KNOCK

    		 1

    0.06

    2-3

    74.54$


    Compatibility

    Model CodeModel Code BreakdownDiagram
    TDA4W-4ミッション;略称;AUDIO;ESP View
    ModelModel CodeModificationDiagram
    JB424WJB424JB424W-4 (E06) View
    Model CodeModel Code BreakdownModel Year FromSpecDiagram
    YA11S-3駆動;ドア数;略称2009011.5 2WD5DR;1.5 4WD5DR;1.5 2WD4DR View
    EngineModel CodeModificationDiagram
    M16AAKK416AKK416-2 (E10,E96,E61,E48,E85,E94) View
    EngineModel CodeModificationTypeDiagram
    M16AAZG416AZG416-5TYPE 5 View
    EngineModel CodeModificationDiagram
    M16AAPK416APK416 (E10,E61,E96,E71,E85,E94) View

    Engine Knock Detection Sensor Assembly

    This sensor is a key safety part for modern Suzuki petrol engines. It “listens” to abnormal combustion (knock/ping) that can happen from low-octane fuel, heavy load, overheating, or carbon buildup. When the ECU knows knock is starting, it can protect the engine before damage happens ️.

    Why this part is needed

    Knock creates sharp vibration waves that can harm pistons, rings, bearings, and head gasket. This sensor helps the ECU keep power and fuel economy while preventing expensive internal wear.

    How it works

    Inside is a piezoelectric element that converts engine block vibrations into a voltage signal. The ECU filters the signal, detects knock frequency, then adjusts ignition timing (and sometimes fueling) to stop detonation.

    What happens if it’s broken

    Common symptoms

    Fault codes, check engine light, weak acceleration, higher fuel use, rough running, or the ECU going into a “safe” timing mode. In worst cases, real knock may go unnoticed and cause severe engine damage .

    Compatibility

    • Swift
    • Grand Vitara
    • Sx4/S-Cross
    • Vitara
    • Escudo
    • Sx4
