1138177E02 Suzuki COVER, Price: 123.24$, Weight: 1.274kg

    • Make Number Name Availability Weight, kg Ship in, Days Price

    Suzuki

    1138177E02

    COVER

    		 2

    1.274

    2-3

    123.24$


    Substitutions

    Make Number Name Availability Weight, kg Processing, days Price
    Suzuki
    1138177E01
    COVER, TIMING CHAIN
    		0
    0.807
    -
    137.95$
    		 Not Available

    Compatibility

    Model CodeModificationDiagram
    RH420RH420-2 (E03,E28,E33:MY 2003) View
    Model CodeModel Code BreakdownDiagram
    TL52W-3エンジン;ドを数;駆動;γƒŸγƒƒγ‚·γƒ§γƒ³ View
    ModelModel CodeModificationDiagram
    JB420WJB420JB420W (P91) View
    Model CodeModel Code BreakdownModel Year FromSpecDiagram
    YA11S-2エンジン;駆動;ドを数;η•₯η§°2008071.5 2WD5DR;2.0 2WD5DR;1.5 4WD5DR;2.0 4WD5DR;1.5 2WD4DR View
    ModelModel CodeModificationTypeDiagram
    RW415RW415RW415TYPE 1 View

    Front Engine Timing Case Cover ️

    This cover seals the front of the engine where the timing chain and sprockets live. It keeps engine oil inside for lubrication, blocks dust and water from outside, and holds the front crankshaft oil seal in the correct position. It also gives a rigid mounting surface for the chain guides and tensioner, so the timing drive stays quiet and accurate over high mileage.

    How it works ️

    A precision-cast housing bolts to the block and oil pan with a gasket or RTV sealant. The integrated front crank seal hugs the pulley hub, returning oil to the sump. Internal ribs control splash and help drain-back, while the flat machined face keeps the timing set aligned. Proper sealing prevents oil loss and keeps contaminants away from the chain, guides, and oil pump drive.

    What happens if it fails ⚠️

    • Oil leaks at the front seal or joint lines, low oil level, burning oil smell.
    • Chain rattle, harsh noise, or poor cam/crank correlation (possible check-engine light).
    • Contamination from water or dirt, accelerating chain and guide wear.
    • Potential oil pressure drop if the sealant bead fails near pump passages.

    Tech notes for replacement

    Check cover flatness; always renew the front crank seal. Clean mating surfaces, apply OE-style sealant beads, and torque bolts in sequence. Let sealant cure before filling fluids. Inspect pulley and keyway, and verify timing marks on reassembly.

    Compatibility

    • Grand Vitara
    • Sx4/S-Cross
    • Aerio
    • Escudo
    • Sx4
