MD097041 Mitsubishi FITTING,WATER OUTLET HOSE, Price: 16.81$, Weight: 0.09kg
| Make | Number | Name | Availability | Weight, kg | Ship in, Days | Price |
|---|---|---|---|---|---|---|
Mitsubishi |
MD097041 |
FITTING,WATER OUTLET HOSE |
8 |
0.09 |
2-3 |
16.81$ |
Compatibility
| Frame | Market | Model | Model Year From | Model Year To | Modification | Diagram |
|---|---|---|---|---|---|---|
| S10# | Japan | S11A | 07.1986 | 07.1992 | 2000(V6) - SUPER SALOON EXTRA(SUPER-CHARGER),4FA/T | View |
| Frame | Market | Model | Model Year From | Model Year To | Modification | Diagram |
|---|---|---|---|---|---|---|
| K0-K3# | North America (PUERTO RICO & GUAM) | K26T | 05.1986 | 05.1996 | 3000/4WD(TRUCK) | View |
| Frame | Market | Model | Model Year From | Model Year To | Modification | Plant | Diagram |
|---|---|---|---|---|---|---|---|
| L04,14# | North America | L141G | 01.1983 | 04.1991 | 3000/RR COIL | MMNA | View |
| Frame | Market | Model | Model Year From | Model Year To | Modification | Diagram |
|---|---|---|---|---|---|---|
| V20-40W | General (BRAZIL) | V43W | 06.1992 | 06.2000 | 3000/LONG WAGON | View |
| Frame | Market | Model | Model Year From | Model Year To | Modification | Diagram |
|---|---|---|---|---|---|---|
| V10-40# | Europe (EUROPE) | V43W | 12.1990 | 04.2004 | 3000/LONG WAGON | View |
| Frame | Market | Model | Model Year From | Model Year To | Modification | Diagram |
|---|---|---|---|---|---|---|
| V30,40# | General (EXPORT) | V33V | 12.1990 | 06.2003 | 3000/LONG VAN/RR LEAF SUS | View |
| Frame | Market | Model | Model Year From | Model Year To | Modification | Diagram |
|---|---|---|---|---|---|---|
| V10,20# | General (EXPORT) | V23W | 12.1990 | 06.2003 | 3000/SHORT WAGON | View |
| Frame | Market | Model | Model Year From | Model Year To | Modification | Plant | Diagram |
|---|---|---|---|---|---|---|---|
| K0-K3# | North America | K26T | 05.1986 | 05.1996 | 3000/4WD(TRUCK) | MMNA | View |
Coolant Outlet Hose Fitting for Reliable Engine Cooling ❄️
This precision outlet fitting links the thermostat housing to the upper radiator hose, guiding hot coolant out of the engine. It seals the passage with an O-ring/gasket and keeps hose alignment correct under heat and vibration. Built from heat‑resistant alloy, it prevents leaks and pressure loss in tough daily use and off‑road conditions.
Why this part is needed
Without a sound outlet neck, the cooling system cannot hold pressure. Proper pressure raises the coolant boiling point, improves heat transfer, and protects the head gasket, heater core, and radiator.
How it works
When the thermostat opens, coolant flows through this neck into the radiator. A machined spigot grips the hose; the flange bolts to the housing. The seal keeps a closed loop so the water pump can circulate efficiently. Some versions include a boss for sensors or bleed ports.
When it fails ⚠️
- Coolant leaks, sweet smell, white residue
- Overheating, temp gauge spikes, heater goes cold
- Low coolant warnings, air pockets, cavitation noise
- Risk of warped head or blown gasket if ignored
Pro install tips
- Clean mating surfaces; use new O-ring/gasket
- Torque evenly; align hose, fit new clamp
- Refill correct coolant, bleed air, pressure test
Compatibility
- L200
- Pajero/Montero
- Pajero
- Debonair V
- Montero
- Truck
- Pajero/Montero<Short>
- Pajero/Montero<Long>
