8713835050 Toyota RESISTOR, BLOWER, Price: 22.68$, Weight: 0.137kg
| Make | Number | Name | Availability | Weight, kg | Ship in, Days | Price |
|---|---|---|---|---|---|---|
Toyota |
8713835050 |
RESISTOR, BLOWER |
6 |
0.137 |
|
22.68$ |
Originals
| Make | Number | Name | Availability | Weight, kg | Processing, days | Price | |
|---|---|---|---|---|---|---|---|
| Toyota |
RESISTOR, BLOWER
|
6 |
0.158
|
2-3
|
18.90$
|
Compatibility
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| RZN18#,VZN18# | VZN180L-GKPGKA | ATM,MTM: AUTOMATIC TRANSMISSION; Grade: SR5-V6 TYPE(-0008),SR5 TYPE(0008-); Gear Shift Type: ATM, 4-SPEED FLOOR SHIFT; Engine: (5VZFE) 3400CC EFI | 11.1995 - 08.2002 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| KDN185,KZN185,RZN18#,VZN18# | RZN185W-GAMVK | ATM,MTM: MANUAL TRANSMISSION; Body: WIDE BODY; Grade: SSR-V TYPE; Fuel Induction: ELECTRIC FUEL INJECTION SYSTEM; Gear Shift Type: MTM, 5-SPEED FLOOR SHIFT; Engine: (3RZFE) 2700CC EFI | 11.1995 - 07.1998 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| KZJ9#,LJ9#,RZJ9#,VZJ9# | VZJ95L-GKMEKV | ATM,MTM: MANUAL TRANSMISSION; NO. Of Doors: 5-DOOR; Driver's Position: LEFT-HAND DRIVE VEHICLES; Grade: VX TYPE; Fuel Induction: ELECTRIC FUEL INJECTION SYSTEM; Engine: (5VZFE) 3400CC EFI; Destination: GULF CORPORATION COUNCIL | 08.1996 - 09.2002 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| KDJ9#,KZJ9#,RZJ9#,VZJ9# | KZJ90W-GJPGT | ATM,MTM: AUTOMATIC TRANSMISSION; Seating Capacity: 5-SEATER; NO. Of Doors: 3-DOOR; Grade: RZ TYPE; Engine: (1KZTE) 3000CC DIESEL TURBO | 04.1996 - 08.2000 | View |
Cabin Blower Speed Resistor
Keep your HVAC running right with a durable blower motor resistor. This small controller sets the fan speeds you select on the dash, giving smooth airflow for A/C and heater. Built for Toyota SUVs, it restores proper ventilation, comfort, and windshield defogging.
Why you need it ️
Without a healthy resistor, the cabin fan won’t follow your speed settings. Correct fan control improves cooling, heating, and demisting, and protects the blower motor from overload.
How it works ⚙️
The unit uses a resistor network and thermal fuse to step down voltage to the blower. The switch or control module chooses a circuit path, and the resistor’s heat sink dissipates warmth while mounted in the duct for cooling airflow.
What happens if it fails ⚠️
Common signs include fan stuck on high only, only low speeds, no fan at all, intermittent operation, or a hot/burnt connector smell. A/C may feel weak simply due to no airflow, not due to refrigerant.
Install tips ✅
Located near the blower housing (often behind the glove box). Disconnect battery, remove two screws, swap the module, and inspect the plug for heat damage. Replace a clogged cabin filter to reduce resistor heat.
Compatibility
- 4Runner
- Hilux Surf
- Land Cruiser 90
- Land Cruiser Prado
