8710602030 Toyota SERVO SUB-ASSY, DAMPER(FOR AIRMIX), Price: 145.13$, Weight: 0.214kg
| Make | Number | Name | Availability | Weight, kg | Ship in, Days | Price |
|---|---|---|---|---|---|---|
Toyota |
8710602030 |
SERVO SUB-ASSY, DAMPER(FOR AIRMIX) |
0 |
0.214 |
|
145.13$ |
| Not Available | ||||||
Originals
| Make | Number | Name | Availability | Weight, kg | Processing, days | Price | |
|---|---|---|---|---|---|---|---|
| Toyota |
SERVO SUB-ASSY, DAMPER(FOR AIRMIX)
|
0 |
0.246
|
-
|
120.94$
|
Not Available |
Compatibility
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| ADT25#,AZT25#,CDT250,ZZT25# | ZZT251R-AWMNKW | ATM,MTM: MANUAL TRANSMISSION; Driver's Position: RIGHT-HAND DRIVE VEHICLES; Body: WAGON; Grade: ENTRY TYPE; Fuel Induction: HIGH EFFICIENCY TWIN CAM; Gear Shift Type: MTM, 5-SPEED FLOOR SHIFT; Engine: (1ZZFE) 1800CC 16-VALVE DOHC EFI | 01.2003 - 11.2008 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| CDE120,NDE120,ZZE12# | ZZE123R-DHFGFW | ATM,MTM: MANUAL TRANSMISSION; NO. Of Doors: 5-DOOR; Driver's Position: RIGHT-HAND DRIVE VEHICLES; Body: HATCHBACK; Grade: TOYOTA SPORTS TYPE; Fuel Induction: TWIN CAM; Gear Shift Type: MTM, 6-SPEED FLOOR SHIFT; Engine: (2ZZGE) 1800CC 16-VALVE DOHC EFI | 11.2001 - 05.2004 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| CDE120,NDE120,ZZE12# | ZZE121L-AEPNKW | ATM,MTM: AUTOMATIC TRANSMISSION; Driver's Position: LEFT-HAND DRIVE VEHICLES; Body: SEDAN; Grade: SOL TYPE; Fuel Induction: HIGH EFFICIENCY TWIN CAM; Gear Shift Type: ATM, 4-SPEED FLOOR SHIFT; Engine: (3ZZFE) 1600CC 16-VALVE DOHC EFI | 10.2001 - 10.2006 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| AUR10,CUR10,ZNR1# | ZNR11R-GRMEKW | Seating Capacity: 7-SEATER; Driver's Position: RIGHT-HAND DRIVE VEHICLES; Grade: SOL TYPE; Fuel Induction: HIGH EFFICIENCY TWIN CAM; Gear Shift Type: MTM, 5-SPEED FLOOR SHIFT; Engine: (1ZZFE) 1800CC 16-VALVE DOHC EFI | 02.2004 - 02.2009 | View |
HVAC Air Mix Damper Servo Motor for Toyota Climate Control
This precision actuator drives the blend door that mixes hot and cold airflow inside the heater box. It keeps cabin temperature steady and makes the switch between A/C ❄️ and heat smooth and quiet. If your vents blow the wrong temperature or change by themselves, this unit is a prime suspect.
Why this part is needed
Accurate air mix means comfort, clear windows, and efficient climate control. The servo positions the flap to the exact angle the climate ECU requests, ensuring fast warm-up, quick cooling, and stable temps on long trips.
How it works
Inside sits a compact DC motor, reduction gears, and a feedback sensor. The ECU sends a control signal; the gears rotate a keyed shaft to move the damper. The sensor reports position so the ECU stops precisely, preventing overtravel and noise.
What happens if it’s broken
Common failures include stripped plastic gears, worn potentiometer tracks, or a seized motor. Symptoms: clicking behind the dash, stuck on hot or cold, weak defrost, temperature swings, or HVAC fault codes. You may run A/C or heater harder, wasting fuel. Replacing the actuator restores quiet, accurate temperature control ✅.
Compatibility
- Avensis
- Corolla Hb
- Corolla Sed/Wg
- Corolla Verso
