553503T500 Hyundai / KIA SPRINGASSY-AIRRR, Price: 687.06$, Weight: 3kg
| Make | Number | Name | Availability | Weight, kg | Ship in, Days | Price |
|---|---|---|---|---|---|---|
Hyundai / KIA |
553503T500 |
SPRINGASSY-AIRRR |
2 |
3 |
4-5 |
687.06$ |
Originals
| Make | Number | Name | Availability | Weight, kg | Processing, days | Price | |
|---|---|---|---|---|---|---|---|
| Mobis |
553503T500
|
SPRING ASSY-AIR, RR LH
|
0 |
2.53
|
4-5
|
548.76$
|
Not Available |
Rear Left Air Suspension Spring Assembly
Why you need it
This rear-left air spring keeps ride height correct, supports load, and delivers the smooth, quiet comfort expected from a luxury sedan . When the original bag ages, the rubber dries and cracks. Replacing it restores level stance, stable handling, and protects the compressor and shock.
How it works
A reinforced elastomer bellows seals to alloy caps with crimp rings. The control unit adds or releases air via the valve block, using signals from height sensors. Pressure inside the bag lifts the left-rear corner, balancing the chassis with the opposite side and keeping the body even under passengers, cargo, and road changes .
What happens if it’s broken
Expect a low left-rear corner after parking, hissing sounds, long compressor cycles, bouncy or harsh ride, uneven tire wear, and stability warnings ⚠️. Driving with a leak can burn out the compressor, strain the damper and bushings, and reduce braking grip on rough roads.
Tech tips
Install new O-rings, clean ports, torque the airline, soap-test for leaks, clear codes, and recalibrate ride height. For best balance, replace in axle pairs ✅.
Compatibility
- K9
- Quoris 11 (2012-2014)
- Quoris 15 (2015-2017)
- Quoris 11 (2011-2014)
- Quoris 11 (2011-2015)
