46310F4011 Toyota ACTUATOR ASSY, PARKING BRAKE, RH, Price: 580.81$, Weight: 1.5kg
| Make | Number | Name | Availability | Weight, kg | Ship in, Days | Price |
|---|---|---|---|---|---|---|
Toyota |
46310F4011 |
ACTUATOR ASSY, PARKING BRAKE, RH |
1 |
1.5 |
|
580.81$ |
Originals
| Make | Number | Name | Availability | Weight, kg | Processing, days | Price | |
|---|---|---|---|---|---|---|---|
| Toyota |
ACTUATOR ASSY, PARKING BRAKE, RH
|
1 |
1.725
|
2-3
|
484.01$
|
Compatibility
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| MAXH10,NGX10,50,ZGX10,ZYX1# | ZYX11R-AHXNBW | ATM,MTM: CONTINUOUSLY VARIABLE TRANSMISSION; Driver's Position: RIGHT-HAND DRIVE VEHICLES; Engine: (2ZRFXE) 1800CC 16-VALVE DOHC EFI; Destination: EUROPE | 09.2019 - ... | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| MZEA11,ZRE21#, ZWE21# | ZWE219R-DEXNBW | ATM,MTM: CONTINUOUSLY VARIABLE TRANSMISSION; Driver's Position: RIGHT-HAND DRIVE VEHICLES; Engine: (2ZRFXE) 1800CC 16-VALVE DOHC EFI; Destination: EUROPE | 01.2023 - ... | View |
Right‑Hand Electronic Parking Brake Actuator for Toyota
Keep your rear right wheel safely locked with this EPB actuator ?️. It’s a direct‑fit, plug‑in motor unit that applies and releases the parking brake under ECU control. Ideal when the original motor is weak, noisy, or throwing dashboard warnings. Reliable holding power means safer parking on slopes and smooth auto‑hold in traffic.
How it works ?
A sealed electric motor drives a worm gear and screw that pushes the caliper mechanism to clamp the brake pads. When you press the switch or select Auto Hold, the module receives a command, spins the motor, and measures current to confirm clamp force. On release, it reverses to free the pads. Weather‑sealed connectors and O‑rings keep moisture out for long life.
What happens if it fails ⚠️
- Parking brake won’t hold or won’t release
- Warning light, EPB/ABS/VSC messages
- Stuck wheel or uneven pad wear
- Battery drain from a jammed motor
Tech tips ✅
- Fits rear RH side only
- Perform EPB service mode and calibration with a scan tool
- Torque fasteners correctly; keep connector dry and clean
Compatibility
- C-HR
- Corolla
