414134A000 Hyundai / KIA FORK ASSY-RELEASE, Price: 16.30$, Weight: 0.415kg

Clutch release fork for Hyundai/Kia vans, trucks and SUV

Why this part is needed

This lever is the heart of the clutch actuation. It transfers push from the slave cylinder to the release bearing, releasing the pressure plate so you can select gears smoothly. A sound fork keeps pedal effort light, shift feel clean, and driveline parts safe during daily use, towing, or stop‑go traffic.

How it works ⚙️

The fork pivots on a ball stud inside the bellhousing. One end receives the hydraulic pushrod; the other presses the bearing against the clutch spring. Hardened contact pads and correct geometry deliver straight force and even wear. A dust boot and a thin film of high‑temp grease prevent noise, friction, and corrosion.

What happens if it’s broken ❗

Warning signs: heavy or inconsistent pedal, squeaks, grinding into gear, partial disengagement, or sudden no‑drive. A cracked arm, worn pivot cup, or bent tips can strand the vehicle and scar the bearing and pressure plate. Replace fork together with pivot ball, retaining clip, release bearing, and boot for best results.

Build and install ✅

Forged, heat‑treated steel with anti‑corrosion coating. Direct fit in the bellhousing; works with OE slave cylinder and release bearing. No machining required.

Compatibility

• Terracan
• Grace
• Libero
• Starex
• Grand Starex
• Porter
• Porter II
• Porter 2
• Porter 2 Features
• H-1
• H100
• H-100
