2345A081 Mitsubishi CYL ASSY,CLUTCH MAST, Price: 156.69$, Weight: 0.14kg
| Make | Number | Name | Availability | Weight, kg | Ship in, Days | Price |
|---|---|---|---|---|---|---|
Mitsubishi |
2345A081 |
CYL ASSY,CLUTCH MAST |
0 |
0.14 |
2-3 |
156.69$ |
| Not Available | ||||||
Originals
| Make | Number | Name | Availability | Weight, kg | Processing, days | Price | |
|---|---|---|---|---|---|---|---|
| Mitsubishi |
CYL ASSY,CLUTCH MAST
|
0 |
0.161
|
-
|
163.86$
|
Not Available |
Compatibility
| Frame | Market | Model | Model Year From | Model Year To | Modification | Diagram |
|---|---|---|---|---|---|---|
| CY,CZ# | North America (PUERTO RICO & GUAM) | CZ4A | 12.2006 | 08.2017 | 2000TURBO/4WD(SEDAN)<08M-> - EVOLUTION-GSR,5FM/T NAS | View |
Clutch Master Cylinder Assembly
This hydraulic clutch control part is essential for smooth gear changes in manual transmission vehicles. It creates the pressure needed to move clutch fluid through the line, allowing the clutch to disengage cleanly when you press the pedal. Without stable hydraulic pressure, shifting becomes hard, noisy, and unsafe—especially in traffic or on hills.
Why This Part Is Needed
Every time you step on the clutch pedal, the internal piston and seals push brake-type fluid forward, transforming pedal force into hydraulic force. This helps the clutch release system work evenly, reducing driver effort and protecting the gearbox synchronizers.
How It Works
The pedal rod drives a piston inside the cylinder bore. Fluid pressure travels to the slave cylinder, which moves the release fork and separates the clutch disc from the flywheel. A return spring and reservoir feed keep the system ready for the next press.
What Happens If It Fails ❌
Common failure signs include soft or sinking pedal, fluid leaks near the firewall, hard shifting, gear grind, or the clutch not disengaging fully. If ignored, you may lose clutch control, damage transmission components, and get stranded.
Compatibility
- Mitsubishi Lancer
