143105A2A01 Honda ACTUATOR ASSY., VTC, Price: 172.14$, Weight: 0.77kg
| Make | Number | Name | Availability | Weight, kg | Ship in, Days | Price |
|---|---|---|---|---|---|---|
Honda |
143105A2A01 |
ACTUATOR ASSY., VTC |
233 |
0.77 |
2-3 |
172.14$ |
Compatibility
| Destination Region | Door | Vehicle Grade | Manufactured | NPl | Region | Gearbox | Diagram |
|---|---|---|---|---|---|---|---|
| KH,KP,KQ,KS,KU,KW,MA | 4 | 2.0 EX,2.0 EX EURO-5,2.0 LX,2.0 LX EURO-5,2.0 VTI,2.0 VTI-C,2.0 VTI-C US BAND,2.0 VTI-F,2.0 VTIL,2.0 VTI-S,2.4 EX,2.4 EX EURO-5,2.4 LX,2.4 LX EURO-5,2.4 S,2.4 TECH,2.4 VTI,2.4 VTIL,2.4 VTIM,3.5 EX,3.5 SIR-C,3.5 SIR-C US BAND,3.5 SV,EX,V6 EXL,V6 EXL EURO-5,V6 L,V6 VTI,V6 VTI EURO-5,VTI-HK,VTIL-F,VTIL-HK,VTILI-S,VTILN-F,VTILN-S | 2013-2014 | 18T2MD01 | General | 5AT,6AT,CVT | View |
| Destination Region | Door | Vehicle Grade | Manufactured | NPl | Region | Gearbox | Diagram |
|---|---|---|---|---|---|---|---|
| TH | 5 | E,EL,S | 2013-2016 | 18T0NDT1 | General | 5AT,CVT | View |
VTC Camshaft Timing Actuator for Honda Engines
This precision unit controls variable valve timing on the intake cam, advancing or retarding timing as the engine needs. It restores smooth idle, strong mid‑range power, better fuel economy, and lower emissions.
Why you need it
With mileage, the original actuator can wear or stick, causing rattle, poor drivability, and warning lights. Replacing it brings back crisp response and protects timing components from stress due to erratic cam phasing.
How it works ⚙️
The ECU commands a spool valve; engine oil pressure fills chambers inside the actuator, rotating a vane relative to the cam gear. This shifts cam timing in real time for idle stability, torque at low rpm, and top‑end efficiency. Clean oil is critical for precise movement.
When it fails ⚠️
Common signs include metallic rattle at start‑up, rough idle, flat acceleration, increased fuel use, and a check engine light for cam correlation. If stuck advanced/retarded, the engine may hesitate or stall. Long neglect can stress the chain and even affect the catalyst.
Tech tips ✅
Use the correct oil grade and change it on time; sludge can jam the mechanism. Replace the sealing O‑ring, align timing marks carefully, torque fasteners to spec, and prime the unit with clean oil before install.
Compatibility
- Cr-V
- Accord
