14053VS40A Nissan PIPE ASSY-MANIF, Price: 11.81$, Weight: 0.07kg
| Make | Number | Name | Availability | Weight, kg | Ship in, Days | Price |
|---|---|---|---|---|---|---|
Nissan |
14053VS40A |
PIPE ASSY-MANIF |
1 |
0.07 |
|
11.81$ |
Originals
| Make | Number | Name | Availability | Weight, kg | Processing, days | Price | |
|---|---|---|---|---|---|---|---|
| Nissan |
PIPE ASSY-MANIF
|
1 |
0.081
|
2-3
|
9.84$
|
Compatibility
| Body Style | Engine | Frame | Vehicle Grade | Market | Model | Model Year From | Diagram |
|---|---|---|---|---|---|---|---|
| LONG BODY | ZD30DDTI | VWME25 | GX | Japan | E25 | 09.2007 | View |
| Body Style | Engine | Vehicle Grade | Market | Model | Model Year From | Model Year To | Diagram |
|---|---|---|---|---|---|---|---|
| WAGON | ZD30DDTI | GR | Europe (LHD) | Y61 | 02.2000 | 03.2010 | View |
| Body Style | Engine | Vehicle Grade | Market | Model | Model Year From | Options | Diagram |
|---|---|---|---|---|---|---|---|
| WAGON | ZD30DDTI | AD | General/Asia (RHD) | Y61 | 12.2009 | AREA:GENERAL AREA | View |
| Body Style | Engine | Vehicle Grade | Market | Model | Model Year From | Options | Diagram |
|---|---|---|---|---|---|---|---|
| PICKUP | ZD30DDTI | AD | General/Asia (RHD) | TY61 | 12.2012 | SUSPENSION:LEAF; AREA:GENERAL AREA | View |
| Body Style | Engine | Vehicle Grade | Market | Model | Model Year From | Model Year To | Diagram |
|---|---|---|---|---|---|---|---|
| PANEL VAN | ZD30DDTI | DV | General/Asia (RHD) | E25 | 11.2007 | 11.2012 | View |
Engine Intake Manifold Pipe Assembly ?
This manifold pipe assembly is a vital link between the intake manifold and connected vacuum/air passages. It is needed to keep engine airflow and vacuum signals correct, so the ECU can manage fuel delivery, idle stability, and overall driveability. A tight, leak-free pipe also helps the engine run smoother and more efficiently.
How It Works ⚙️
The pipe routes metered air and/or vacuum to specific engine circuits. With proper sealing at the joints, it maintains steady pressure and prevents unfiltered air from entering the system. This supports accurate sensor readings and consistent combustion, especially during cold starts, acceleration, and idle.
What Happens If It’s Damaged ?
A cracked pipe, loose fitting, or failed seal can cause vacuum leaks. Common results include rough idle, hesitation, higher fuel consumption, whistling noises, and warning lights. Long-term driving with leaks may lead to lean running, overheating of components, misfires, and catalytic converter stress.
Technician Tip ✅
Always inspect O-rings/gaskets and clamps during installation, and check nearby hoses for brittleness—small leaks can mimic sensor or injector faults.
Compatibility
- Challenger
