1305016020 PULLEY, CAMSHAFT TIMING
Images
2 Images
Compatibility
Toyota 1305016020
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| AT21#,CT21#,ST215 | AT210-CEMVF | ATM,MTM: MANUAL TRANSMISSION; Grade: GT TYPE; Gear Shift Type: MTM, 5-SPEED FLOOR SHIFT; Engine: (4AGE) 1600CC 20-VALVE DOHC EFI | 08.1996 - 08.1998 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| AE10#,CE10#,EE10# | AE101G-AWMVF | ATM,MTM: MANUAL TRANSMISSION; Body: WAGON; Grade: BZ-TOURING TYPE; Gear Shift Type: MTM, 5-SPEED FLOOR SHIFT; Engine: (4AGE) 1600CC 16-VALVE DOHC EFI; Engine: (4AGE) 1600CC 20-VALVE DOHC EFI | 05.1996 - 05.1997 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| AE11# | AE111-BCPZF | ATM,MTM: AUTOMATIC TRANSMISSION; Body: COUPE; Grade: BZ-G TYPE; Gear Shift Type: ATM, 4-SPEED FLOOR SHIFT; Engine: (4AGE) 1600CC 16-VALVE DOHC EFI; Engine: (4AGE) 1600CC 20-VALVE DOHC EFI | 05.1995 - 08.2000 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| AE10# | AE101-BTPVF | ATM,MTM: AUTOMATIC TRANSMISSION; Body: HARDTOP; Grade: G TYPE; Gear Shift Type: ATM, 4-SPEED FLOOR SHIFT; Engine: (4AGE) 1600CC 16-VALVE DOHC EFI; Engine: (4AGE) 1600CC 20-VALVE DOHC EFI | 05.1992 - 08.1998 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| AE11#,CE11#,EE111 | AE111-BEFVF | ATM,MTM: MANUAL TRANSMISSION; Body: SEDAN; Grade: GT TYPE; Gear Shift Type: MTM, 6-SPEED FLOOR SHIFT; Engine: (4AGE) 1600CC 16-VALVE DOHC EFI; Engine: (4AGE) 1600CC 20-VALVE DOHC EFI | 04.1997 - 08.2000 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| AE11# | AE111G-CWMVF | ATM,MTM: MANUAL TRANSMISSION; Grade: BZ-TOURING TYPE; Gear Shift Type: MTM, 5-SPEED FLOOR SHIFT; Engine: (4AGE) 1600CC 16-VALVE DOHC EFI; Engine: (4AGE) 1600CC 20-VALVE DOHC EFI | 05.1996 - 04.1997 | View |
Information
Engine Timing Pulley ⏱️
Why You Need This Part
The camshaft timing pulley is vital for precise engine timing. It synchronizes the camshaft with the crankshaft, making sure the engine’s valves open and close at the correct moments. This ensures optimal performance, fuel efficiency, and prevents engine misfires.
How It Works
This pulley connects to the camshaft and is driven by the timing belt or chain. As the crankshaft turns, it spins the pulley, precisely controlling the camshaft rotation. This action manages the opening and closing of the engine valves, keeping everything in perfect harmony.
Signs of Failure
If this part breaks, the timing can slip, leading to rough engine performance, poor acceleration, or even severe engine damage such as bent valves. A failing pulley often causes unusual noises from the timing area and triggers warning lights.
Compatible Car Models
- Carina Ff
- Corolla
- Levin/Trueno
- Lvn/Cre/Trn/Mrn
- Sprinter
- Sprinter Carib
