Open RegionYearModelModelCode Details
General 2015 RAV4 ASA42L-ANTXK
Catalog: TOYOTA202608 Engine: 2500CC 16-VALVE DOHC EFI Transmission Description: AUTOMATIC TRANSMISSION, MTM, 6-SPEED FLOOR SHIFT Vehicle Grade: X TYPE Steering Description: LEFT-HAND DRIVE VEHICLES Destination Description: GENERAL COUNTRIES Color Code: 040 Trim Code: FB20 Production: 201212-201510 Model Short: ASA42L-ANTXK Region: OTHER Native Region: GR

Toyota RAV4 2015 — Switch & Relay & Computer

Browse vehicle diagrams

Spare Parts

Part numberDescriptionPNCQty
84540-33010 SWITCH ASSY, NEUTRAL START 1
Note:ASA4#..6FC Production:2012-12 – 2015-10
89465-42230 SENSOR, OXYGEN 1
Note:ASA4# Production:2012-12 – 2015-10
89615-20090 SENSOR, KNOCK CONTROL 1
Note:ASA4#,ZSA4# Production:2012-12 – 2015-10
89467-21020 SENSOR, AIR FUEL RATIO 1
Note:ASA4# Production:2012-12 – 2015-10
83530-28020 SWITCH ASSY, OIL PRESSURE (FOR ENGINE) 1
Note:ASA4# Production:2012-12 – 2015-10
— Part does not apply to this vehicle configuration. 84210 —
91651-40620 standard —
16581-36010 standard —
91551-80835 standard —
90105-C0048 standard —
Replacements:91551-80835 (fitment: unknown)
90430-18008 standard —

Diagram

10 parts
Toyota RAV4 2015 — Switch & Relay & Computer
