Toyota Hilux 2020 — Switch & Relay & Computer
Spare Parts
| Part number | Description | PNC | Qty |
|---|---|---|---|
| — | Part does not apply to this vehicle configuration. | 84751 | — |
| 83950-0K031 | LAMP ASSY, TELLTALE | 1 | |
Note:GUN125,126,135,TGN126..(ADC,TDC)..(BZAGT,LA);GGN125,GUN136,TGN128,13#..(ADC,TDC)..(BZAGT,GEN,LA) Production:2019-05 – 2020-10 Fitment:Matches · model | |||
| 83910-0K180 | CLOCK ASSY | 1 | |
Note:TGN136..ADC,ASC,SDC;GGN125,135,GUN122,125,126,13#,KUN12#,13#,LAN125,TGN12#,138..ADC,ASC,KDC,KSC,MDC,MSC,PDC,PSC,SDC,SSC,SXT Production:2015-11 – 2021-05 Fitment:Matches · model | |||
| 84223-0K010 | SWITCH, TRANSFER POSITION | 1 | |
Note:GGN125,GUN125,126,KUN125,126,LAN125,TGN126,128 Production:2015-05 – 2021-05 Fitment:Matches · model | |||
| — | Part does not apply to this vehicle configuration. | 84453 | — |
| — | Part does not apply to this vehicle configuration. | 87290 | — |
| — | Part does not apply to this vehicle configuration. | 84152 | — |
| 89611-0K011 | SWITCH, PUSH START | 1 | |
Note:GUN122..5F..M..TH;GUN126,136..M..(PH,TH,VN);GUN126..LHD..6FC..M..(LA,SA);GGN125,135,GUN125,135,KUN125,126,TGN126,136..(ADC,SDC,SXT,TDC,TXT)..M..(LA,PH,SA,TH,VN) Production:2016-07 – 2020-10 Spec:WIRELESS DOOR LOCK-WITH(*SES & ANSWER BACK & PANIC BUTTON) Fitment:Matches · model | |||
| 84725-0K080 | SWITCH, DIFFERENTIAL LOCK | 1 | |
Note:GUN136..BZAGT;GUN126..X..BZAGT;GUN126..ADC..6FC..X;GUN126..LHD..(ADC,SDC)..(H,L,M,S);GUN125,135..LHD..(ADC,SDC,SSC,SXT)..S;GUN125,135,TGN136..(ADC,ASC,SDC,SSC,SXT)..(L,M,X);GGN125,LAN125,TGN126,128,138..LHD..(ADC,ASC,SDC,SSC) Production:2017-10 – 2020-10 Spec:DIFFERENTIAL LOCK-WITH Fitment:Matches · model | |||
| 84970-0K020 | SWITCH ASSY, COMBINATION | 1 | |
Note:GUN126,TGN121..6FC;GUN125..SDC..6FC..S;GUN125..(ADC,MDC,SSC,TDC,TSC,TXT)..6FC;GGN12#,135,GUN120,13#,TGN126,128,13#..(ADC,MDC,SDC,SSC,SXT,TDC,TXT)..6FC Production:2015-05 – 2021-05 Fitment:Matches · model | |||
| 84988-0K010 | SWITCH, VSC OFF | 1 | |
Note:GUN126..M..LA;TGN136..S..LA;GUN126..6FC..PH;TGN126..TDC..S..GCC;GUN126..RHD..SDC..M;TGN121,126..GCC..IV3;GUN122,125,13#..(S,X)..ARL;GUN126..6FC..H..(BZAGT,TH,VN);GUN136,TGN126..6FC..M..(BZAGT,GEN);GUN136,TGN121..(H,X)..(ARL,BZAGT,SA);GUN125,136..(SDC,SXT,TDC)..M..(ARL,IDN,SA);GUN125..LHD..(SSC,TDC)..6F..S..(GCC,GEN,SA);GGN12#,135,GUN123,KUN125..(5F,5FC,6FC)..(H,M,S);GUN126..(KDC,MDC,SXT,TDC,TSC,TXT)..(ARL,GCC,KEN,MA,SA,TAIW);GUN125,126,135,KUN126..LHD..(ADC,SDC,TDC)..(5FC,6F)..(H,X)..(BZAGT,SA,VN) Production:2015-05 – 2021-05 Fitment:Matches · model | |||
| 85530-0K040 | SOCKET ASSY, POWER OUTLET, NO.1 | 2 | |
Note:TGN126..M..(BZAGT,GEN,LA);GUN125..(MDC,TDC,TXT)..(MA,TH);GUN122,135,TGN121,136..(L,M,S)..(MA,TH);GGN125,135,GUN120,136,KUN13#,TGN128,136..H,L,M;GUN126..(ADC,KDC,MDC,SDC,SSC,SXT,TDC,TXT)..(H,M);GUN122,125,135,KUN12#,TGN121,138..(H,M)..(BZAGT,GCC,GEN,IDN,LA,PH,SA,VN) Production:2015-05 – 2021-02 Fitment:Matches · model | |||
| 85535-0K090-C0 | COVER, POWER OUTLET SOCKET, NO.1 | 2 | |
Note:GUN136..LA,TH;GUN136..H..BZAGT;GUN136..6F..M..BZAGT;GUN126..LHD..6F..H..GEN;GUN126..6FC..(H,M)..GEN;GUN120,KUN13#,TGN128,136..H,L,M;GUN126,KUN122..TDC..MTM..M..GEN;GUN126..(H,M)..(BZAGT,LA,PH,TH,VN);GUN122,125,135,TGN121,136..(L,M,S)..TH;GUN122,125,135,KUN125,126,TGN126,138..(ADC,TDC)..(H,M)..(BZAGT,GEN,IDN,LA,PH,VN) Production:2015-05 – 2020-10 Spec:BLACK,TRIM2#,4# Fitment:Matches · model | |||
| — | Part does not apply to this vehicle configuration. | 84988H | — |
| — | Part does not apply to this vehicle configuration. | 85531 | — |
| — | Part does not apply to this vehicle configuration. | 84746 | — |
| — | Part does not apply to this vehicle configuration. | 84752 | — |
| — | Part does not apply to this vehicle configuration. | 84270M | — |
| — | Part does not apply to this vehicle configuration. | 84255 | — |
| 90167-T0012 | standard | — | |
Replacements:93568-55014 (fitment: unknown) Fitment:Matches · model | |||
| 93568-55014 | standard | — | |
Fitment:Matches · model | |||
Diagram
11 parts
