Open RegionYearModelModelCode Details
USA / Canada 2025 HILUX DOUBLE CAB GUN126R-DTTHRQ
Catalog: TOYOTA202608 Engine: 2800CC DIESEL TURBO Transmission Description: AUTOMATIC TRANSMISSION, MTM, 6-SPEED FLOOR SHIFT Steering Description: RIGHT-HAND DRIVE VEHICLES Destination Description: AUSTRALIA Color Code: 089 Trim Code: LE21 Production: 202408-999999 Model Short: GUN126R-DTTHRQ Region: NA Native Region: US

Toyota HILUX-DOUBLE-CAB 2025 — Injection Pump Assembly

Browse vehicle diagrams

Spare Parts

Part numberDescriptionPNCQty
23801-0L050 HOSE, FUEL 1
Note:2GDFTV..GUN135..S..LA;1GDFTV..GUN126..H..BZAG;2GDFTV..GUN125..LHD..SP;2GDFTV..GUN135..TP..L..LA;1GDFTV..GUN126..6F..S..BZAG;2GDFTV..GUN135..BZAG,GEN,PH,SA;2GDFTV..GUN125..RHD..(GEN,IDN,KEN,MA,SA);2GDFTV..GUN125..LHD..(BZAG,GCC,GEN,GHA,LA,PH);1GDFTV..GUN126..DCRL..(GCC,GEN,GHA,KEN,LA,MA,MMR,PH,PKN,SA);1GDFTV,2GDFTV..GUN120,121,122,136..DCRL..(BZAG,GCC,GEN,LA,PH,SA,TH) Production:2024-08 – …
90466-T0023 CLIP, HOSE 2
Note:2GDFTV..GUN125..LHD..SP;2GDFTV..GUN125..RHD..(GEN,IDN,KEN,MA,SA);2GDFTV..GUN125..LHD..(BZAG,GCC,GEN,GHA,LA,PH);1GDFTV,2GDFTV..GUN120,121,122,136..BZAG,GCC,GEN,LA,PH,SA,TH;1GDFTV,2GDFTV..GUN126,135..BZAG,GCC,GEN,GHA,IND,KEN,LA,MA,MMR,PH,PKN,SA,TWN Production:2024-08 – … Replacements:96137-41701 (fitment: unknown)
23271-0E042 HOSE, FUEL 1
Note:2GDFTV..GUN125..LHD..SP;2GDFTV..GUN125..RHD..(GEN,IDN,KEN,MA,SA);2GDFTV..GUN125..LHD..(BZAG,GCC,GEN,GHA,LA,PH);1GDFTV,2GDFTV..GUN120,121,122,136..DCRL..(BZAG,GCC,GEN,LA,PH,SA,TH);1GDFTV,2GDFTV..GUN126,135..DCRL..(BZAG,GCC,GEN,GHA,IND,KEN,LA,MA,MMR,PH,PKN,SA) Production:2025-08 – …
23881-0E011 BRACKET, FUEL HOSE 1
Note:2GDFTV..GUN125..LHD..SP;2GDFTV..GUN125..RHD..(GEN,IDN,KEN,MA,SA);2GDFTV..GUN125..LHD..(BZAG,GCC,GEN,GHA,LA,PH);1GDFTV,2GDFTV..GUN120,121,122,136..DCRL..(BZAG,GCC,GEN,LA,PH,SA,TH);1GDFTV,2GDFTV..GUN126,135..DCRL..(BZAG,GCC,GEN,GHA,IND,KEN,LA,MA,MMR,PH,PKN,SA,TWN) Production:2024-08 – …
23842-0L010 CLAMP, FUEL PIPE, NO.2 1
Note:2GDFTV..GUN135..S..LA;2GDFTV..GUN125..LHD..SP;2GDFTV..GUN135..TP..L..LA;2GDFTV..GUN135..BZAG,GEN,PH,SA;2GDFTV..GUN125..RHD..(GEN,IDN,KEN,MA,SA);2GDFTV..GUN125..LHD..(BZAG,GCC,GEN,GHA,LA,PH);1GDFTV..GUN126..DCRL..(BZAG,GCC,GEN,GHA,KEN,LA,MA,MMR,PH,PKN,SA);1GDFTV,2GDFTV..GUN120,121,122,136..DCRL..(BZAG,GCC,GEN,LA,PH,SA,TH) Production:2024-08 – …
23841-0L010 CLAMP, FUEL HOSE 1
Note:2GDFTV..GUN135..S..LA;2GDFTV..GUN125..LHD..SP;2GDFTV..GUN135..TP..L..LA;2GDFTV..GUN135..BZAG,GEN,PH,SA;2GDFTV..GUN125..RHD..(GEN,IDN,KEN,MA,SA);2GDFTV..GUN125..LHD..(BZAG,GCC,GEN,GHA,LA,PH);1GDFTV,2GDFTV..GUN120,121,122,136..BZAG,GCC,GEN,LA,PH,SA,TH;1GDFTV..GUN126..BZAG,GCC,GEN,GHA,KEN,LA,MA,MMR,PH,PKN,SA,TWN Production:2024-08 – …
23273-0L132 HOSE, FUEL, NO.2 1
Note:1GDFTV..GUN126..H..BZAG;2GDFTV..GUN135..6FC..PH;2GDFTV..GUN135..6F..H..PH;2GDFTV..GUN125..H..(MA,SA);1GDFTV..GUN126..6F..S..BZAG;2GDFTV..GUN135..BZAG,GEN,LA,SA;2GDFTV..GUN125..RHD..(GEN,KEN,SA);2GDFTV..GUN125..LHD..(GAP,SP)..(L,S);2GDFTV..GUN125..6FC..(BZAG,GCC,IDN,LA);2GDFTV..GUN125..LHD..6F..(BZAG,GCC,GEN,LA);1GDFTV,2GDFTV..GUN120,121,122,136..BZAG,GCC,GEN,LA,SA,TH;1GDFTV..GUN126..GCC,GEN,GHA,IND,KEN,LA,MA,MMR,PH,PKN,SA,TWN Production:2024-08 – …
23841-0L041 CLAMP, FUEL PIPE, NO.1 1
Note:2GDFTV..GUN135..S..LA;2GDFTV..GUN125..LHD..SP;2GDFTV..GUN135..TP..L..LA;2GDFTV..GUN135..BZAG,GEN,PH,SA;2GDFTV..GUN125..RHD..(GEN,IDN,KEN,MA,SA);2GDFTV..GUN125..LHD..(BZAG,GCC,GEN,GHA,LA,PH);1GDFTV,2GDFTV..GUN120,121,122,136..BZAG,GCC,GEN,LA,PH,SA,TH;1GDFTV..GUN126..BZAG,GCC,GEN,GHA,KEN,LA,MA,MMR,PH,PKN,SA,TWN Production:2024-08 – …
90466-T0038 standard —
Replacements:96133-41500 (fitment: unknown)
90119-T0134 standard —
Replacements:91671-80612 (fitment: unknown)
90119-T0136 standard —
Replacements:91671-80614 (fitment: unknown)
90466-T0059 standard —
Replacements:96137-41501 (fitment: unknown)
90466-T0041 standard —
Replacements:96133-41300 (fitment: unknown)
96132-51300 standard —

Diagram

14 parts
Toyota HILUX-DOUBLE-CAB 2025 — Injection Pump Assembly
