Open RegionYearModelModelCode Details
USA / Canada 2018 ES350 300H AXZH10L-AEXGBA
Catalog: LEXUS202608 Engine: 2500CC 16-VALVE DOHC Transmission Description: CONTINUOUSLY VARIABLE TRANSMISSION Color Code: 4X8 Trim Code: LC11 Production: 201807-999999 Model Short: AXZH10L-AEXGBA Region: NA Native Region: US

Lexus ES350-300H 2018 — Exhaust Pipe

Browse vehicle diagrams

Spare Parts

Part numberDescriptionPNCQty
17565-22040 SUPPORT, EXHAUST PIPE, NO.1 3
Note:A25AFXS..AXZH1# Production:2018-07 – 2021-10
17565-31040 SUPPORT, EXHAUST PIPE, NO.2 1
Note:A25AFXS..AXZH1# Production:2018-07 – 2021-10
17566-25010 SUPPORT, EXHAUST PIPE, NO.3 1
Note:A25AFXS..AXZH1# Production:2018-07 – 2021-10
17572-31150 BRACKET, EXHAUST PIPE SUPPORT, NO.2 1
Note:A25AFXS..AXZH10 Production:2018-06 – 2021-10
17573-25010 BRACKET, EXHAUST PIPE SUPPORT, NO.3 1
Note:A25AFXS..AXZH1# Production:2018-07 – 2021-10
17575-31160 BRACKET, EXHAUST PIPE SUPPORT, NO.5 1
Note:A25AFXS..AXZH10 Production:2018-06 – 2021-10
17577-31040 BRACKET, EXHAUST PIPE SUPPORT, NO.7 1
Note:A25AFXS..AXZH10 Production:2018-06 – 2021-10
90917-06094 GASKET, EXHAUST PIPE 1
Note:A25AFXS..AXZH1# Production:2018-07 – 2021-10
90917-06078 GASKET, EXHAUST PIPE, NO.2 1
Note:A25AFXS..AXZH1# Production:2018-07 – 2021-10
90917-06090 GASKET, EXHAUST PIPE 1
Note:A25AFXS..AXZH10 Production:2018-06 – 2021-10
17410-25190 PIPE ASSY, EXHAUST, FRONT 1
Note:A25AFXS..AXZH10 Production:2018-07 – 2019-06 Replacements:17410-25191 (fitment: unknown) Spec:*114=TOYOTA/A53/Y Spec Note:*114(CATALYST MAKE/CATALYSTID/ONBOARD DIAGNOSIS:YES OR NO(THIS INDICATION COMPLIES WITH EC DIRECTIVE.))=TOYOTA/A53/Y
17420-25060 PIPE ASSY, EXHAUST, CENTER 1
Note:A25AFXS..AXZH1# Production:2018-07 – 2021-10
17440-25060 PIPE ASSY, EXHAUST, TAIL 1
Note:A25AFXS..AXZH1# Production:2018-07 – 2021-10
90105-08488 standard —
90177-10005 standard —
90105-10585 standard —

Diagram

16 parts
Lexus ES350-300H 2018 — Exhaust Pipe
