3744057L00 Suzuki SENSOR ASSY, STEERING ANGLE, Price: 158.09$, Weight: 0.05kg
| Make | Number | Name | Availability | Weight, kg | Ship in, Days | Price |
|---|---|---|---|---|---|---|
Suzuki |
3744057L00 |
SENSOR ASSY, STEERING ANGLE |
0 |
0.05 |
2-3 |
158.09$ |
| Not Available | ||||||
Compatibility
| Model Code | Model Code Breakdown | Model Year From | Spec | Diagram |
|---|---|---|---|---|
| RE91S | ι§ε;η₯η§° | 200906 | 2WD;4WD | View |
Steering Position Sensor for Stable Control ?
Keep your vehicle tracking straight and safe with this precision steering position unit. It feeds exact wheel angle and turn rate to ABS, ESC/ESP, and electric power steering. The result is smooth assist, accurate traction control, and confidence on wet or rough roads.
Why you need it β
Modern safety systems rely on the steering signal to compare where you point the car versus where it actually moves. Without a clean angle reading, stability control cannot correct a slide, and ABS may react late. Headlight leveling and lane features can also depend on this data.
How it works βοΈ
Mounted on the steering column behind the wheel, the module tracks rotation with a coded disk and magnetic sensors (Hall-effect). It measures angle and speed, then sends data via CAN bus. Dual channels improve accuracy and redundancy. After fitting, a quick calibration centers the signal.
What happens if it fails β οΈ
- ABS/ESP lights on, traction control disabled
- Heavy or inconsistent steering assist
- Vehicle pulls or corrects at the wrong time
- Driver aids unavailable; longer stopping distance
Install tips ?
Disconnect battery, set wheels straight, mark the hub, fit the unit carefully, and torque to spec. Perform lock-to-lock and scan-tool calibration. Do not rotate the clockspring while removed.
Compatibility
- Kizashi
