1277169L00 Suzuki GUIDE, TIMING CHAIN, Price: 14.20$, Weight: 0.14kg
| Make | Number | Name | Availability | Weight, kg | Ship in, Days | Price |
|---|---|---|---|---|---|---|
Suzuki |
1277169L00 |
GUIDE, TIMING CHAIN |
0 |
0.14 |
2-3 |
14.20$ |
| Not Available | ||||||
Compatibility
| Model Code | Modification | Type | Diagram |
|---|---|---|---|
| AMF310 | AMF310-2 (E05) | TYPE 2 | View |
| Engine | Model Code | Modification | Diagram |
|---|---|---|---|
| K14B | A1M414 | A1M414 (E48,E85,E96) | View |
| Model Code | Modification | Type | Diagram |
|---|---|---|---|
| AVI414 | AVI414 EXP (E85,E96) | TYPE 1 | View |
| Model Code | Modification | Diagram |
|---|---|---|
| ATK412 | ATK412 (E10,E71,E85,E96) | View |
| Model Code | Modification | Diagram |
|---|---|---|
| A6G415 | A6G415 (E43) | View |
| Model Code | Model Code Breakdown | Model Year From | Spec | Diagram |
|---|---|---|---|---|
| ZC72S | ι§ε;γγγ·γ§γ³;η₯η§°;TUNER;γγ£γΉγγ£γΌγΈ | 201006 | 2WD;4WD | View |
| Model Code | Modification | Type | Diagram |
|---|---|---|---|
| A5B412 | A5B412 (E02) | TYPE 1 | View |
| Engine | Model Code | Modification | Type | Diagram |
|---|---|---|---|---|
| K12B | AZG412 | AZG412-5 | TYPE 5 | View |
| Model Code | Model Code Breakdown | Model Year From | Spec | Diagram |
|---|---|---|---|---|
| MA15S | ι§ε;η₯η§° | 201011 | K12B | View |
| Model Code | Modification | Type | Diagram |
|---|---|---|---|
| AUI412 | AUI412-3 (E35) | TYPE 3 | View |
OEM-Quality Timing Chain Guide for Suzuki Engines βοΈ
This precision chain guide keeps your timing system straight, quiet, and reliable. Engines need it to route the chain smoothly between sprockets, control whip, and cut friction. When the guide is healthy, valve timing stays locked in, cold-start rattle is reduced, and the chain and sprockets live longer.
How It Works οΈ
A hardened steel rail with a wear-resistant polymer shoe supports the chain as the hydraulic tensioner presses it into place. Oil film on the shoe surface reduces heat and noise, while the curved profile maintains correct chain path at all RPMs. The result: stable cam/crank sync and clean combustion.
What If It Fails β οΈ
Worn or cracked guides cause chain slap, metallic rattle on start-up, poor idle, misfire codes, and delayed throttle response. Severe wear can shed plastic or metal debris, let the chain jump a tooth, and in worst cases lead to no-start or valve-to-piston damage.
Tech Tips
- Replace guide with chain and tensioner as a set for best results.
- Inspect for deep grooves, cracks, heat spots; any are a replace-now sign.
- Align timing marks, torque bolts to spec, and prime the tensioner with clean oil.
- Use quality oil and filters to protect the chain drive.
Compatibility
- Ertiga
- Ignis
- Swift
- Alto - A-Star/Celerio/800/Fronte/Cultus
- Baleno/Esteem
- Splash/Ritz
- Jimny
- Wagonr+
- Kei/Swift
- Wagon R
