Catalog
Brand Name Code

NISSAN

Nissan NISSAN201809
Model
NameModel Year FromModel Year ToModel MarketBody StyleEngineGradeTransmission
SAFARI10.199703.2000Y61General/Asia (LHD)WAGONRD28TISTDMT

POWER TRAIN

TRANSMISSION GEAR; MAIN GEAR(FS5R30A)

NumberNameCode
3226157G15GEAR ASSY-3RD,MAIN SHAFT32260
3226157G15GEAR ASSY-3RD,MAIN SHAFT32260
3226157G15GEAR ASSY-3RD,MAIN SHAFT32260
32261VB000GEAR ASSY-3RD,MAIN SHAFT32260
3225301G01BUSH-1ST GEAR32253
3225301G01BUSH-1ST GEAR32253
3225301G01BUSH-1ST GEAR32253
3260430P61RING-BAULK32604+D
322460W000WASHER-THRUST32246
3260430P61RING-BAULK32604+D
3260430P61RING-BAULK32604+D
322460W000WASHER-THRUST32246
322460W000WASHER-THRUST32246
3263101J01RING-BAULK32604+D
3226421P00BEARING-NEEDLE,MAIN SHAFT32264RA
32264VB001BEARING-NEEDLE,MAIN SHAFT32264RA
3226421P00BEARING-NEEDLE,MAIN SHAFT32264RA
3226421P00BEARING-NEEDLE,MAIN SHAFT32264RA
32611AA510SLEEVE-COUPLING32606+B
3261130P10SLEEVE-COUPLING32606+B
32611AA510SLEEVE-COUPLING32606+B
32611AA510SLEEVE-COUPLING32606+B
32231VB000GEAR ASSY-1ST,MAIN SHAFT32230
3223101G74GEAR ASSY-1ST,MAIN SHAFT32230
3223101G74GEAR ASSY-1ST,MAIN SHAFT32230
3223101G74GEAR ASSY-1ST,MAIN SHAFT32230
3260530P11HUB-SYNCHRONIZER32601+A
3260530P11HUB-SYNCHRONIZER32601+A
3260530P11HUB-SYNCHRONIZER32601+A
3260423P60RING-BAULK32604+A
32620VB002RING-BAULK32604+A
3260423P60RING-BAULK32604+A
3260423P60RING-BAULK32604+A
3260330P00SPRING-SHIFTING INSERT32602+A
3260330P00SPRING-SHIFTING INSERT32602+A
3260330P00SPRING-SHIFTING INSERT32602+A
3260301T03SPRING-SHIFTING INSERT32602+A
3260440P61RING-BAULK32604+E
3260440P61RING-BAULK32604+E
3260440P61RING-BAULK32604+E
3260130P00HUB-SYNCHRONIZER32601
3260130P00HUB-SYNCHRONIZER32601
3260130P00HUB-SYNCHRONIZER32601
322210W000SPACER-PILOT BEARING32272E
322210W000SPACER-PILOT BEARING32272E
322210W000SPACER-PILOT BEARING32272E
3260430P60RING-BAULK32604+B
3260430P60RING-BAULK32604+B
3260430P60RING-BAULK32604+B
32620VB003RING-BAULK32604+B
3235021U00HOLDER-C RING32351
3235021U00HOLDER-C RING32351
3235021U00HOLDER-C RING32351
32201VB320GEAR ASSY-MAIN DRIVE32200
32201VB320GEAR ASSY-MAIN DRIVE32200
32201VB320GEAR ASSY-MAIN DRIVE32200
3234801G05RING-C,MAIN SHAFT32348
3234801G05RING-C,MAIN SHAFT32348
3234801G06RING-C,MAIN SHAFT32348
3234801G06RING-C,MAIN SHAFT32348
3234801G05RING-C,MAIN SHAFT32348
3234801G01RING-C,MAIN SHAFT32348
3234801G01RING-C,MAIN SHAFT32348
3234801G02RING-C,MAIN SHAFT32348
3234801G06RING-C,MAIN SHAFT32348
3234801G01RING-C,MAIN SHAFT32348
3234801G00RING-C,MAIN SHAFT32348
3234801G02RING-C,MAIN SHAFT32348
3234801G02RING-C,MAIN SHAFT32348
3234801G04RING-C,MAIN SHAFT32348
3234801G04RING-C,MAIN SHAFT32348
3234801G03RING-C,MAIN SHAFT32348
3234801G03RING-C,MAIN SHAFT32348
3234801G03RING-C,MAIN SHAFT32348
3234801G04RING-C,MAIN SHAFT32348
3234801G12RING-C,MAIN SHAFT32348
3234801G13RING-C,MAIN SHAFT32348
3234801G13RING-C,MAIN SHAFT32348
3234801G12RING-C,MAIN SHAFT32348
3234801G12RING-C,MAIN SHAFT32348
3234801G11RING-C,MAIN SHAFT32348
3234801G13RING-C,MAIN SHAFT32348
3234801G14RING-C,MAIN SHAFT32348
3234801G15RING-C,MAIN SHAFT32348
3234801G15RING-C,MAIN SHAFT32348
3234801G15RING-C,MAIN SHAFT32348
3234801G14RING-C,MAIN SHAFT32348
3234801G14RING-C,MAIN SHAFT32348
3234801G11RING-C,MAIN SHAFT32348
3234801G11RING-C,MAIN SHAFT32348
3234801G08RING-C,MAIN SHAFT32348
3234801G08RING-C,MAIN SHAFT32348
3234801G08RING-C,MAIN SHAFT32348
3234801G07RING-C,MAIN SHAFT32348
3234801G07RING-C,MAIN SHAFT32348
3234801G09RING-C,MAIN SHAFT32348
3234801G09RING-C,MAIN SHAFT32348
3234801G10RING-C,MAIN SHAFT32348
3234801G10RING-C,MAIN SHAFT32348
3234801G10RING-C,MAIN SHAFT32348
3234801G09RING-C,MAIN SHAFT32348
3234801G07RING-C,MAIN SHAFT32348
3234801G00RING-C,MAIN SHAFT32348
3234801G00RING-C,MAIN SHAFT32348
32609AA510INSERT-SHIFTING32608+B
3260930P00INSERT-SHIFTING32608+B
3260970L15INSERT-SHIFTING32608+B
32609AA510INSERT-SHIFTING32608+B
32609AA510INSERT-SHIFTING32608+B
3260630P10SLEEVE-COUPLING32606+A
3260630P10SLEEVE-COUPLING32606+A
3260630P10SLEEVE-COUPLING32606+A
32203C8017BEARING-MAIN DRIVE32203
32203VB000BEARING-MAIN DRIVE32203
32203C8017BEARING-MAIN DRIVE32203
32203C8017BEARING-MAIN DRIVE32203
3220401G66RING-SNAP32204+C
3220401G65RING-SNAP32204+C
3220401G66RING-SNAP32204+C
3220401G65RING-SNAP32204+C
3220401G67RING-SNAP32204+C
3220401G65RING-SNAP32204+C
3220401G67RING-SNAP32204+C
3220401G66RING-SNAP32204+C
3220401G62RING-SNAP32204+C
3220401G63RING-SNAP32204+C
3220401G67RING-SNAP32204+C
3220401G62RING-SNAP32204+C
3220401G63RING-SNAP32204+C
3220401G63RING-SNAP32204+C
3220401G64RING-SNAP32204+C
3220401G64RING-SNAP32204+C
3220401G64RING-SNAP32204+C
3220401G62RING-SNAP32204+C
3260923P00INSERT-SHIFTING32608+A
3260923P00INSERT-SHIFTING32608+A
3260923P00INSERT-SHIFTING32608+A
32609VB000INSERT-SHIFTING32608+A
3227201G00BEARING-PILOT,MAIN32272
3227201G00BEARING-PILOT,MAIN32272
32271Z5004BEARING-PILOT,MAIN32272
3227201G00BEARING-PILOT,MAIN32272
0092213200RING-SNAP0092213200
3260323P00SPRING-SHIFTING INSERT32602
3260301J01SPRING-SHIFTING INSERT32602
3260323P00SPRING-SHIFTING INSERT32602
3260323P00SPRING-SHIFTING INSERT32602
3220401G64RING-SNAP32204+B
3220401G63RING-SNAP32204+B
3220401G64RING-SNAP32204+B
3220401G64RING-SNAP32204+B
3220401G63RING-SNAP32204+B
3220401G65RING-SNAP32204+B
3220401G61RING-SNAP32204+B
3220401G60RING-SNAP32204+B
3220401G60RING-SNAP32204+B
3220401G60RING-SNAP32204+B
3220401G61RING-SNAP32204+B
3220401G61RING-SNAP32204+B
3220401G62RING-SNAP32204+B
3220401G62RING-SNAP32204+B
3220401G62RING-SNAP32204+B
3220401G63RING-SNAP32204+B
3220401G65RING-SNAP32204+B
3220401G65RING-SNAP32204+B
3272014600BALL-STEEL32701BB
3272014600BALL-STEEL32701BB
3272014600BALL-STEEL32701BB
3225130P14GEAR ASSY-2ND,MAIN SHAFT32250
3220331G00BEARING-MAIN SHAFT32275
3225130P14GEAR ASSY-2ND,MAIN SHAFT32250
3220331G00BEARING-MAIN SHAFT32275
3220331G00BEARING-MAIN SHAFT32275
3225130P14GEAR ASSY-2ND,MAIN SHAFT32250
32251VB000GEAR ASSY-2ND,MAIN SHAFT32250
3226401G00BEARING-NEEDLE,MAIN SHAFT32264R
3226401T00BEARING-NEEDLE,MAIN SHAFT32264R
3226401G00BEARING-NEEDLE,MAIN SHAFT32264R
3226401G00BEARING-NEEDLE,MAIN SHAFT32264R
3262001G00SPACER-MAIN SHAFT32265
3262001G00SPACER-MAIN SHAFT32265
3262001G00SPACER-MAIN SHAFT32265
3261830P00SLEEVE-COUPLING32606+C
3261830P00SLEEVE-COUPLING32606+C
3261830P00SLEEVE-COUPLING32606+C
3225801G10HUB-SYNCHRONIZER32601+B
3225801G10HUB-SYNCHRONIZER32601+B
3225801G10HUB-SYNCHRONIZER32601+B
3224801G00BEARING-NEEDLE32264Q
3224801G00BEARING-NEEDLE32264Q
3224801G00BEARING-NEEDLE32264Q
3224131G60SHAFT-MAIN32241
3224131G60SHAFT-MAIN32241
3224131G60SHAFT-MAIN32241
3224501J02GEAR-REVERSE,MAIN SHAFT32245
3224530P60GEAR-REVERSE,MAIN SHAFT32245
3224530P60GEAR-REVERSE,MAIN SHAFT32245
3224530P60GEAR-REVERSE,MAIN SHAFT32245
3224701G01BUSH-REVERSE GEAR,MAIN SHAFT32253M
3224701G00BUSH-REVERSE GEAR,MAIN SHAFT32253M
3224701G01BUSH-REVERSE GEAR,MAIN SHAFT32253M
3224701G00BUSH-REVERSE GEAR,MAIN SHAFT32253M
3234101G11GEAR ASSY-OVERDRIVE32340
3234101G11GEAR ASSY-OVERDRIVE32340
3234101G11GEAR ASSY-OVERDRIVE32340
32203C8017BEARING-MAIN DRIVE32203+A
32203C8017BEARING-MAIN DRIVE32203+A
32203C8017BEARING-MAIN DRIVE32203+A

TRANSMISSION GEAR; MAIN GEAR(FS5R30A)

NumberNameCode
3226157G15GEAR ASSY-3RD,MAIN SHAFT32260
3226157G15GEAR ASSY-3RD,MAIN SHAFT32260
3226157G15GEAR ASSY-3RD,MAIN SHAFT32260
32261VB000GEAR ASSY-3RD,MAIN SHAFT32260
3225301G01BUSH-1ST GEAR32253
3225301G01BUSH-1ST GEAR32253
3225301G01BUSH-1ST GEAR32253
3260430P61RING-BAULK32604+D
322460W000WASHER-THRUST32246
3260430P61RING-BAULK32604+D
3260430P61RING-BAULK32604+D
322460W000WASHER-THRUST32246
322460W000WASHER-THRUST32246
3263101J01RING-BAULK32604+D
3226421P00BEARING-NEEDLE,MAIN SHAFT32264RA
32264VB001BEARING-NEEDLE,MAIN SHAFT32264RA
3226421P00BEARING-NEEDLE,MAIN SHAFT32264RA
3226421P00BEARING-NEEDLE,MAIN SHAFT32264RA
32611AA510SLEEVE-COUPLING32606+B
3261130P10SLEEVE-COUPLING32606+B
32611AA510SLEEVE-COUPLING32606+B
32611AA510SLEEVE-COUPLING32606+B
32231VB000GEAR ASSY-1ST,MAIN SHAFT32230
3223101G74GEAR ASSY-1ST,MAIN SHAFT32230
3223101G74GEAR ASSY-1ST,MAIN SHAFT32230
3223101G74GEAR ASSY-1ST,MAIN SHAFT32230
3260530P11HUB-SYNCHRONIZER32601+A
3260530P11HUB-SYNCHRONIZER32601+A
3260530P11HUB-SYNCHRONIZER32601+A
3260423P60RING-BAULK32604+A
32620VB002RING-BAULK32604+A
3260423P60RING-BAULK32604+A
3260423P60RING-BAULK32604+A
3260330P00SPRING-SHIFTING INSERT32602+A
3260330P00SPRING-SHIFTING INSERT32602+A
3260330P00SPRING-SHIFTING INSERT32602+A
3260301T03SPRING-SHIFTING INSERT32602+A
3260440P61RING-BAULK32604+E
3260440P61RING-BAULK32604+E
3260440P61RING-BAULK32604+E
3260130P00HUB-SYNCHRONIZER32601
3260130P00HUB-SYNCHRONIZER32601
3260130P00HUB-SYNCHRONIZER32601
322210W000SPACER-PILOT BEARING32272E
322210W000SPACER-PILOT BEARING32272E
322210W000SPACER-PILOT BEARING32272E
3260430P60RING-BAULK32604+B
3260430P60RING-BAULK32604+B
32620VB003RING-BAULK32604+B
3260430P60RING-BAULK32604+B
32201VB320GEAR ASSY-MAIN DRIVE32200
32201VB320GEAR ASSY-MAIN DRIVE32200
32201VB320GEAR ASSY-MAIN DRIVE32200
3235021U00HOLDER-C RING32351
3235021U00HOLDER-C RING32351
3235021U00HOLDER-C RING32351
3234801G05RING-C,MAIN SHAFT32348
3234801G05RING-C,MAIN SHAFT32348
3234801G06RING-C,MAIN SHAFT32348
3234801G06RING-C,MAIN SHAFT32348
3234801G05RING-C,MAIN SHAFT32348
3234801G01RING-C,MAIN SHAFT32348
3234801G01RING-C,MAIN SHAFT32348
3234801G02RING-C,MAIN SHAFT32348
3234801G06RING-C,MAIN SHAFT32348
3234801G01RING-C,MAIN SHAFT32348
3234801G00RING-C,MAIN SHAFT32348
3234801G02RING-C,MAIN SHAFT32348
3234801G02RING-C,MAIN SHAFT32348
3234801G04RING-C,MAIN SHAFT32348
3234801G04RING-C,MAIN SHAFT32348
3234801G03RING-C,MAIN SHAFT32348
3234801G03RING-C,MAIN SHAFT32348
3234801G03RING-C,MAIN SHAFT32348
3234801G04RING-C,MAIN SHAFT32348
3234801G12RING-C,MAIN SHAFT32348
3234801G13RING-C,MAIN SHAFT32348
3234801G13RING-C,MAIN SHAFT32348
3234801G12RING-C,MAIN SHAFT32348
3234801G12RING-C,MAIN SHAFT32348
3234801G11RING-C,MAIN SHAFT32348
3234801G13RING-C,MAIN SHAFT32348
3234801G14RING-C,MAIN SHAFT32348
3234801G15RING-C,MAIN SHAFT32348
3234801G15RING-C,MAIN SHAFT32348
3234801G15RING-C,MAIN SHAFT32348
3234801G14RING-C,MAIN SHAFT32348
3234801G14RING-C,MAIN SHAFT32348
3234801G11RING-C,MAIN SHAFT32348
3234801G11RING-C,MAIN SHAFT32348
3234801G08RING-C,MAIN SHAFT32348
3234801G08RING-C,MAIN SHAFT32348
3234801G08RING-C,MAIN SHAFT32348
3234801G07RING-C,MAIN SHAFT32348
3234801G07RING-C,MAIN SHAFT32348
3234801G09RING-C,MAIN SHAFT32348
3234801G09RING-C,MAIN SHAFT32348
3234801G10RING-C,MAIN SHAFT32348
3234801G10RING-C,MAIN SHAFT32348
3234801G10RING-C,MAIN SHAFT32348
3234801G09RING-C,MAIN SHAFT32348
3234801G07RING-C,MAIN SHAFT32348
3234801G00RING-C,MAIN SHAFT32348
3234801G00RING-C,MAIN SHAFT32348
32609AA510INSERT-SHIFTING32608+B
3260930P00INSERT-SHIFTING32608+B
3260970L15INSERT-SHIFTING32608+B
32609AA510INSERT-SHIFTING32608+B
32609AA510INSERT-SHIFTING32608+B
3260630P10SLEEVE-COUPLING32606+A
3260630P10SLEEVE-COUPLING32606+A
3260630P10SLEEVE-COUPLING32606+A
32203C8017BEARING-MAIN DRIVE32203
32203VB000BEARING-MAIN DRIVE32203
32203C8017BEARING-MAIN DRIVE32203
32203C8017BEARING-MAIN DRIVE32203
3220401G66RING-SNAP32204+C
3220401G65RING-SNAP32204+C
3220401G66RING-SNAP32204+C
3220401G65RING-SNAP32204+C
3220401G67RING-SNAP32204+C
3220401G65RING-SNAP32204+C
3220401G67RING-SNAP32204+C
3220401G66RING-SNAP32204+C
3220401G62RING-SNAP32204+C
3220401G63RING-SNAP32204+C
3220401G67RING-SNAP32204+C
3220401G62RING-SNAP32204+C
3220401G63RING-SNAP32204+C
3220401G63RING-SNAP32204+C
3220401G64RING-SNAP32204+C
3220401G64RING-SNAP32204+C
3220401G64RING-SNAP32204+C
3220401G62RING-SNAP32204+C
32271Z5004BEARING-PILOT,MAIN32272
3227201G00BEARING-PILOT,MAIN32272
3227201G00BEARING-PILOT,MAIN32272
3227201G00BEARING-PILOT,MAIN32272
3220401G64RING-SNAP32204+B
3220401G63RING-SNAP32204+B
3220401G63RING-SNAP32204+B
3220401G64RING-SNAP32204+B
3220401G65RING-SNAP32204+B
3220401G62RING-SNAP32204+B
3220401G65RING-SNAP32204+B
3220401G64RING-SNAP32204+B
3220401G61RING-SNAP32204+B
3220401G60RING-SNAP32204+B
3220401G60RING-SNAP32204+B
3220401G60RING-SNAP32204+B
3220401G61RING-SNAP32204+B
3220401G61RING-SNAP32204+B
3220401G62RING-SNAP32204+B
3220401G65RING-SNAP32204+B
3220401G62RING-SNAP32204+B
3220401G63RING-SNAP32204+B
3260923P00INSERT-SHIFTING32608+A
3260923P00INSERT-SHIFTING32608+A
32609VB000INSERT-SHIFTING32608+A
3260923P00INSERT-SHIFTING32608+A
0092213200RING-SNAP0092213200
3260323P00SPRING-SHIFTING INSERT32602
3260323P00SPRING-SHIFTING INSERT32602
3260301J01SPRING-SHIFTING INSERT32602
3260323P00SPRING-SHIFTING INSERT32602
3272014600BALL-STEEL32701BB
3272014600BALL-STEEL32701BB
3272014600BALL-STEEL32701BB
3225130P14GEAR ASSY-2ND,MAIN SHAFT32250
32251VB000GEAR ASSY-2ND,MAIN SHAFT32250
3225130P14GEAR ASSY-2ND,MAIN SHAFT32250
3225130P14GEAR ASSY-2ND,MAIN SHAFT32250
3220331G00BEARING-MAIN SHAFT32275
3220331G00BEARING-MAIN SHAFT32275
3220331G00BEARING-MAIN SHAFT32275
3226401T00BEARING-NEEDLE,MAIN SHAFT32264R
3226401G00BEARING-NEEDLE,MAIN SHAFT32264R
3226401G00BEARING-NEEDLE,MAIN SHAFT32264R
3226401G00BEARING-NEEDLE,MAIN SHAFT32264R
3262001G00SPACER-MAIN SHAFT32265
3262001G00SPACER-MAIN SHAFT32265
3262001G00SPACER-MAIN SHAFT32265
3261830P00SLEEVE-COUPLING32606+C
3261830P00SLEEVE-COUPLING32606+C
3261830P00SLEEVE-COUPLING32606+C
3225801G10HUB-SYNCHRONIZER32601+B
3225801G10HUB-SYNCHRONIZER32601+B
3225801G10HUB-SYNCHRONIZER32601+B
3224801G00BEARING-NEEDLE32264Q
3224801G00BEARING-NEEDLE32264Q
3224801G00BEARING-NEEDLE32264Q
3224131G60SHAFT-MAIN32241
3224131G60SHAFT-MAIN32241
3224131G60SHAFT-MAIN32241
3224530P60GEAR-REVERSE,MAIN SHAFT32245
3224530P60GEAR-REVERSE,MAIN SHAFT32245
3224530P60GEAR-REVERSE,MAIN SHAFT32245
3224501J02GEAR-REVERSE,MAIN SHAFT32245
3224701G00BUSH-REVERSE GEAR,MAIN SHAFT32253M
3224701G00BUSH-REVERSE GEAR,MAIN SHAFT32253M
3224701G01BUSH-REVERSE GEAR,MAIN SHAFT32253M
3224701G01BUSH-REVERSE GEAR,MAIN SHAFT32253M
3234101G11GEAR ASSY-OVERDRIVE32340
3234101G11GEAR ASSY-OVERDRIVE32340
3234101G11GEAR ASSY-OVERDRIVE32340
32203C8017BEARING-MAIN DRIVE32203+A
32203C8017BEARING-MAIN DRIVE32203+A
32203C8017BEARING-MAIN DRIVE32203+A
