Catalog
| Brand | Name | Code | |
|---|---|---|---|
 |
NISSAN |
Nissan | NISSAN201809 |
Model
| Name | Model Year From | Model Year To | Model | Market | Body Style | Engine | Grade | Transmission | |
|---|---|---|---|---|---|---|---|---|---|
| SAFARI | 07.1999 | 11.2003 | Y61 | General/Asia (LHD) | HARDTOP | TB45S | STD | MT |
EXHAUST & COOLING
EXHAUST TUBE & MUFFLER
| Number | Name | Code | Qty Required | ApplicableModels | Prod. Date |
|---|---|---|---|---|---|
| 0112101413 | BOLT | 20030AD | 2 | TB45S | 07.2002 - 11.2003 |
| 0112101413 | BOLT | 20030AD | 2 | TB45S | 09.2001 - 07.2002 |
| 20020VB900 | TUBE ASSY-EXHAUST,FRONT | 20020 | 1 | TB45S | 07.1999 - 03.2000 |
| 20020VB900 | TUBE ASSY-EXHAUST,FRONT | 20020 | 1 | TB45S | 03.2000 - 07.2002 |
| 20020VB900 | TUBE ASSY-EXHAUST,FRONT | 20020 | 1 | TB45S | 07.2002 - 11.2003 |
| 2074130J00 | BRACKET-EXHAUST MOUNTING | 20741 | 1 | TB45S | 03.2000 - 07.2002 |
| 2074130J00 | BRACKET-EXHAUST MOUNTING | 20741 | 1 | TB42S +TB45S | 07.1999 - 03.2000 |
| 2074130J00 | BRACKET-EXHAUST MOUNTING | 20741 | 1 | TB45S | 07.2002 - 11.2003 |
| 2064134T00 | MOUNTING-EXHAUST,RUBBER | 20641P | 1 | TB45S | 07.2002 - 11.2003 |
| 2064134T00 | MOUNTING-EXHAUST,RUBBER | 20641P | 1 | TB42S +TB45S | 07.1999 - 03.2000 |
| 2064134T00 | MOUNTING-EXHAUST,RUBBER | 20641P | 1 | TB45S | 03.2000 - 07.2002 |
| 0112101413 | BOLT | 20030AB | 2 | TB45S | 07.2002 - 11.2003 |
| 0112101413 | BOLT | 20030AB | 2 | TB45S | 09.2001 - 07.2002 |
| 20050VB760 | TUBE ASSY-EXHAUST,REAR | 20400 | 1 | TB42S +TB45S | 07.1999 - 03.2000 |
| 20050VB760 | TUBE ASSY-EXHAUST,REAR | 20400 | 1 | TB45S | 07.2002 - 11.2003 |
| 20050VB760 | TUBE ASSY-EXHAUST,REAR | 20400 | 1 | TB45S | 03.2000 - 07.2002 |
| 2069130P00 | GASKET-EXHAUST | 20691+A | 1 | TB42S +TB45S | 07.1999 - 03.2000 |
| 2069130P00 | GASKET-EXHAUST | 20691+A | 1 | TB45S | 03.2000 - 07.2002 |
| 2069130P00 | GASKET-EXHAUST | 20691+A | 1 | TB45S | 07.2002 - 11.2003 |
| 0112100483 | BOLT | 20030A | 2 | TB42S +TB45S | 07.1999 - 03.2000 |
| 0112100483 | BOLT | 20030A | 2 | TB45S | 07.2002 - 11.2003 |
| 0112100483 | BOLT | 20030A | 2 | TB45S | 03.2000 - 07.2002 |
| 083686202G | SCR-HEX HD,PP W | 083686202G | |||
| 20731VB000 | MOUNTING ASSY-EXHAUST | 20731M | 1 | TB42S +TB45S | 07.1999 - 03.2000 |
| 20731VB000 | MOUNTING ASSY-EXHAUST | 20731M | 1 | TB45S | 03.2000 - 07.2002 |
| 20731VB000 | MOUNTING ASSY-EXHAUST | 20731M | 1 | TB45S | 07.2002 - 11.2003 |
| 2071137J00 | MOUNTING ASSY-EXHAUST | 20711Q | 1 | TB42S +TB45S | 07.1999 - 03.2000 |
| 2071137J00 | MOUNTING ASSY-EXHAUST | 20711Q | 1 | TB45S | 03.2000 - 07.2002 |
| 2071137J00 | MOUNTING ASSY-EXHAUST | 20711Q | 1 | TB45S | 07.2002 - 11.2003 |
| 20641S8100 | INSULATOR-EXHAUST MOUNTING | 20641N | 1 | TB45S | 03.2000 - 07.2002 |
| 20641S8100 | INSULATOR-EXHAUST MOUNTING | 20641N | 1 | TB42S +TB45S | 07.1999 - 03.2000 |
| 20641S8100 | INSULATOR-EXHAUST MOUNTING | 20641N | 1 | TB45S | 07.2002 - 11.2003 |
| 2071237J01 | BRACKET-EXHAUST TUBE MOUNTING | 20712P | 1 | TB45S | 03.2000 - 07.2002 |
| 2071237J01 | BRACKET-EXHAUST TUBE MOUNTING | 20712P | 1 | TB42S +TB45S | 07.1999 - 03.2000 |
| 2071237J01 | BRACKET-EXHAUST TUBE MOUNTING | 20712P | 1 | TB45S | 07.2002 - 11.2003 |
| 2069151E01 | GASKET-EXHAUST | 20691 | 2 | TB45S | 03.2000 - 07.2002 |
| 2069151E01 | GASKET-EXHAUST | 20691 | 2 | TB42S +TB45S | 07.1999 - 03.2000 |
| 2069151E01 | GASKET-EXHAUST | 20691 | 2 | TB45S | 07.2002 - 11.2003 |
| 0122500102 | NUT | 20030BA | 2 | TB45S | 03.2000 - 07.2002 |
| 0122500102 | NUT | 20030BA | 2 | TB45S | 07.2002 - 11.2003 |
| 0122500102 | NUT | 20030BA | 2 | TB42S +TB45S | 07.1999 - 03.2000 |
| 2060801G00 | BOLT | 20621A | 1 | TB45S | 07.2002 - 11.2003 |
| 2060801G00 | BOLT | 20621A | 1 | TB42S +TB45S | 07.1999 - 03.2000 |
| 2060801G00 | BOLT | 20621A | 1 | TB45S | 03.2000 - 07.2002 |
| 20527VB900 | HEAT INSULATOR-FRONT TUBE,UPPER | 20525MG | 1 | TB45S | 07.2002 - 11.2003 |
| 20527VB900 | HEAT INSULATOR-FRONT TUBE,UPPER | 20525MG | 1 | TB45S | 07.1999 - 03.2000 |
| 20527VB900 | HEAT INSULATOR-FRONT TUBE,UPPER | 20525MG | 1 | TB45S | 03.2000 - 07.2002 |
| 2056160J00 | CLAMP-HEAT INSULATOR | 20560MA | 2 | TB45S | 07.1999 - 03.2000 |
| 2056160J00 | CLAMP-HEAT INSULATOR | 20560MA | 2 | TB45S | 07.2002 - 11.2003 |
| 2056160J00 | CLAMP-HEAT INSULATOR | 20560MA | 2 | TB45S | 03.2000 - 07.2002 |
| 20100VB765 | MUFFLER ASSY-EXHAUST,MAIN | 20100 | 1 | K.TB42S +K.TB45S | 07.1999 - 03.2000 |
| 20100VB765 | MUFFLER ASSY-EXHAUST,MAIN | 20100 | 1 | K.TB45S | 07.2002 - 11.2003 |
| 20100VB765 | MUFFLER ASSY-EXHAUST,MAIN | 20100 | 1 | K.TB45S | 03.2000 - 07.2002 |
| 20510VB000 | INSULATOR ASSY-FRONT TUBE | 20510G | 1 | TB42S +TB45S | 07.1999 - 03.2000 |
| 20510VB000 | INSULATOR ASSY-FRONT TUBE | 20510G | 1 | TB45S | 03.2000 - 07.2002 |
| 20510VB000 | INSULATOR ASSY-FRONT TUBE | 20510G | 1 | TB45S | 07.2002 - 11.2003 |
| 206921E810 | GASKET-EXHAUST | 20692M | 1 | TB45S | 07.2002 - 11.2003 |
| 206921E810 | GASKET-EXHAUST | 20692M | 1 | TB42S +TB45S | 07.1999 - 03.2000 |
| 206921E810 | GASKET-EXHAUST | 20692M | 1 | TB45S | 03.2000 - 07.2002 |
| 2060241G00 | NUT-FIX,EXHAUST TUBE | 20602 | 3 | TB45S | 03.2000 - 07.2002 |
| 2060241G00 | NUT-FIX,EXHAUST TUBE | 20602 | 3 | TB42S +TB45S | 07.1999 - 03.2000 |
| 2060241G00 | NUT-FIX,EXHAUST TUBE | 20602 | 3 | TB45S | 07.2002 - 11.2003 |
| 081108551D | BOLT-HEX | 081108551D | |||
| 089115401A | NUT-HEX | 089115401A | |||
| 083638301D | SCREW-MACHINE | 083638301D | |||
| 20515VB000 | INSULATOR ASSY-FRONT TUBE | 20515E | 1 | TB42S +TB45S | 07.1999 - 03.2000 |
| 20515VB000 | INSULATOR ASSY-FRONT TUBE | 20515E | 1 | TB45S | 07.2002 - 11.2003 |
| 20515VB000 | INSULATOR ASSY-FRONT TUBE | 20515E | 1 | TB45S | 03.2000 - 07.2002 |
| 2056137J01 | CLAMP-HEAT INSULATOR | 20560M | 4 | TB45S | 07.2002 - 11.2003 |
| 2056137J01 | CLAMP-HEAT INSULATOR | 20560M | 4 | TB45S | 07.1999 - 03.2000 |
| 2056137J01 | CLAMP-HEAT INSULATOR | 20560M | 4 | TB45S | 03.2000 - 07.2002 |
EXHAUST TUBE & MUFFLER
| Number | Name | Code | Qty Required | ApplicableModels | Prod. Date |
|---|---|---|---|---|---|
| 20020VB900 | TUBE ASSY-EXHAUST,FRONT | 20020 | 1 | TB45S | 07.1999 - 03.2000 |
| 20020VB900 | TUBE ASSY-EXHAUST,FRONT | 20020 | 1 | TB45S | 07.2002 - 11.2003 |
| 20020VB900 | TUBE ASSY-EXHAUST,FRONT | 20020 | 1 | TB45S | 03.2000 - 07.2002 |
| 2074130J00 | BRACKET-EXHAUST MOUNTING | 20741 | 1 | TB45S | 03.2000 - 07.2002 |
| 2074130J00 | BRACKET-EXHAUST MOUNTING | 20741 | 1 | TB42S +TB45S | 07.1999 - 03.2000 |
| 2074130J00 | BRACKET-EXHAUST MOUNTING | 20741 | 1 | TB45S | 07.2002 - 11.2003 |
| 2064134T00 | MOUNTING-EXHAUST,RUBBER | 20641P | 1 | TB45S | 07.2002 - 11.2003 |
| 2064134T00 | MOUNTING-EXHAUST,RUBBER | 20641P | 1 | TB42S +TB45S | 07.1999 - 03.2000 |
| 2064134T00 | MOUNTING-EXHAUST,RUBBER | 20641P | 1 | TB45S | 03.2000 - 07.2002 |
| 083638201D | SCREW-MACHINE | 083638201D | |||
| 20050VB760 | TUBE ASSY-EXHAUST,REAR | 20400 | 1 | TB45S | 03.2000 - 07.2002 |
| 20050VB760 | TUBE ASSY-EXHAUST,REAR | 20400 | 1 | TB42S +TB45S | 07.1999 - 03.2000 |
| 20050VB760 | TUBE ASSY-EXHAUST,REAR | 20400 | 1 | TB45S | 07.2002 - 11.2003 |
| 2069130P00 | GASKET-EXHAUST | 20691+A | 1 | TB45S | 07.2002 - 11.2003 |
| 2069130P00 | GASKET-EXHAUST | 20691+A | 1 | TB42S +TB45S | 07.1999 - 03.2000 |
| 2069130P00 | GASKET-EXHAUST | 20691+A | 1 | TB45S | 03.2000 - 07.2002 |
| 0112100483 | BOLT | 20030A | 2 | TB42S +TB45S | 07.1999 - 03.2000 |
| 0112100483 | BOLT | 20030A | 2 | TB45S | 03.2000 - 07.2002 |
| 0112100483 | BOLT | 20030A | 2 | TB45S | 07.2002 - 11.2003 |
| 083686202G | SCR-HEX HD,PP W | 083686202G | |||
| 20731VB000 | MOUNTING ASSY-EXHAUST | 20731M | 1 | TB45S | 03.2000 - 07.2002 |
| 20731VB000 | MOUNTING ASSY-EXHAUST | 20731M | 1 | TB45S | 07.2002 - 11.2003 |
| 20731VB000 | MOUNTING ASSY-EXHAUST | 20731M | 1 | TB42S +TB45S | 07.1999 - 03.2000 |
| 2071137J00 | MOUNTING ASSY-EXHAUST | 20711Q | 1 | TB42S +TB45S | 07.1999 - 03.2000 |
| 2071137J00 | MOUNTING ASSY-EXHAUST | 20711Q | 1 | TB45S | 03.2000 - 07.2002 |
| 2071137J00 | MOUNTING ASSY-EXHAUST | 20711Q | 1 | TB45S | 07.2002 - 11.2003 |
| 20641S8100 | INSULATOR-EXHAUST MOUNTING | 20641N | 1 | TB45S | 07.2002 - 11.2003 |
| 20641S8100 | INSULATOR-EXHAUST MOUNTING | 20641N | 1 | TB42S +TB45S | 07.1999 - 03.2000 |
| 20641S8100 | INSULATOR-EXHAUST MOUNTING | 20641N | 1 | TB45S | 03.2000 - 07.2002 |
| 2071237J01 | BRACKET-EXHAUST TUBE MOUNTING | 20712P | 1 | TB45S | 07.2002 - 11.2003 |
| 2071237J01 | BRACKET-EXHAUST TUBE MOUNTING | 20712P | 1 | TB42S +TB45S | 07.1999 - 03.2000 |
| 2071237J01 | BRACKET-EXHAUST TUBE MOUNTING | 20712P | 1 | TB45S | 03.2000 - 07.2002 |
| 2069151E01 | GASKET-EXHAUST | 20691 | 2 | TB45S | 07.2002 - 11.2003 |
| 2069151E01 | GASKET-EXHAUST | 20691 | 2 | TB45S | 03.2000 - 07.2002 |
| 2069151E01 | GASKET-EXHAUST | 20691 | 2 | TB42S +TB45S | 07.1999 - 03.2000 |
| 0122500102 | NUT | 20030BA | 2 | TB42S +TB45S | 07.1999 - 03.2000 |
| 0122500102 | NUT | 20030BA | 2 | TB45S | 03.2000 - 07.2002 |
| 0122500102 | NUT | 20030BA | 2 | TB45S | 07.2002 - 11.2003 |
| 2060801G00 | BOLT | 20621A | 1 | TB42S +TB45S | 07.1999 - 03.2000 |
| 2060801G00 | BOLT | 20621A | 1 | TB45S | 07.2002 - 11.2003 |
| 2060801G00 | BOLT | 20621A | 1 | TB45S | 03.2000 - 07.2002 |
| 20527VB900 | HEAT INSULATOR-FRONT TUBE,UPPER | 20525MG | 1 | TB45S | 03.2000 - 07.2002 |
| 20527VB900 | HEAT INSULATOR-FRONT TUBE,UPPER | 20525MG | 1 | TB45S | 07.1999 - 03.2000 |
| 20527VB900 | HEAT INSULATOR-FRONT TUBE,UPPER | 20525MG | 1 | TB45S | 07.2002 - 11.2003 |
| 2056160J00 | CLAMP-HEAT INSULATOR | 20560MA | 2 | TB45S | 07.1999 - 03.2000 |
| 2056160J00 | CLAMP-HEAT INSULATOR | 20560MA | 2 | TB45S | 07.2002 - 11.2003 |
| 2056160J00 | CLAMP-HEAT INSULATOR | 20560MA | 2 | TB45S | 03.2000 - 07.2002 |
| 20100VB765 | MUFFLER ASSY-EXHAUST,MAIN | 20100 | 1 | K.TB45S | 07.2002 - 11.2003 |
| 20100VB765 | MUFFLER ASSY-EXHAUST,MAIN | 20100 | 1 | K.TB42S +K.TB45S | 07.1999 - 03.2000 |
| 20100VB765 | MUFFLER ASSY-EXHAUST,MAIN | 20100 | 1 | K.TB45S | 03.2000 - 07.2002 |
| 20510VB000 | INSULATOR ASSY-FRONT TUBE | 20510G | 1 | TB45S | 07.2002 - 11.2003 |
| 20510VB000 | INSULATOR ASSY-FRONT TUBE | 20510G | 1 | TB42S +TB45S | 07.1999 - 03.2000 |
| 20510VB000 | INSULATOR ASSY-FRONT TUBE | 20510G | 1 | TB45S | 03.2000 - 07.2002 |
| 206921E810 | GASKET-EXHAUST | 20692M | 1 | TB45S | 03.2000 - 07.2002 |
| 206921E810 | GASKET-EXHAUST | 20692M | 1 | TB42S +TB45S | 07.1999 - 03.2000 |
| 206921E810 | GASKET-EXHAUST | 20692M | 1 | TB45S | 07.2002 - 11.2003 |
| 2060241G00 | NUT-FIX,EXHAUST TUBE | 20602 | 3 | TB45S | 07.2002 - 11.2003 |
| 2060241G00 | NUT-FIX,EXHAUST TUBE | 20602 | 3 | TB45S | 03.2000 - 07.2002 |
| 2060241G00 | NUT-FIX,EXHAUST TUBE | 20602 | 3 | TB42S +TB45S | 07.1999 - 03.2000 |
| 081108551D | BOLT-HEX | 081108551D | |||
| 089115401A | NUT-HEX | 089115401A | |||
| 083638301D | SCREW-MACHINE | 083638301D | |||
| 20515VB000 | INSULATOR ASSY-FRONT TUBE | 20515E | 1 | TB45S | 03.2000 - 07.2002 |
| 20515VB000 | INSULATOR ASSY-FRONT TUBE | 20515E | 1 | TB45S | 07.2002 - 11.2003 |
| 20515VB000 | INSULATOR ASSY-FRONT TUBE | 20515E | 1 | TB42S +TB45S | 07.1999 - 03.2000 |
| 2056137J01 | CLAMP-HEAT INSULATOR | 20560M | 4 | TB45S | 07.2002 - 11.2003 |
| 2056137J01 | CLAMP-HEAT INSULATOR | 20560M | 4 | TB45S | 07.1999 - 03.2000 |
| 2056137J01 | CLAMP-HEAT INSULATOR | 20560M | 4 | TB45S | 03.2000 - 07.2002 |
