Catalog Nissan PATROL 02.2000 12.2008 MISCELLANEOUS
| Brand | Name | Model Year From | Model Year To | Model | Market | Body Style | Engine | Grade | |
|---|---|---|---|---|---|---|---|---|---|
 NISSAN |
PATROL | 02.2000 | 12.2008 | Y61 | Europe (RHD) | HARDTOP | ZD30DDTI | GR |
MISCELLANEOUS
REAR VIEW MIRROR; OUTSIDE MIRROR
| Number | Name | Code | Qty Required | ApplicableModels | Specs | Prod. Date |
|---|---|---|---|---|---|---|
| 96301VB411 | DOOR MIRROR ASSY-RH | 96301M | 1 | K +W.(GR+GRX) | 10.2002 - 07.2003 | |
| 96301VB411 | DOOR MIRROR ASSY-RH | 96301M | 1 | *K +*W | DOOR MIRROR HEATER | 02.2000 - 10.2002 |
| 96301VB421 | DOOR MIRROR ASSY-RH | 96301M | 1 | K +W.(GR+GRX) | 07.2003 - 08.2004 | |
| K6301VD210 | DOOR MIRROR ASSY-RH | 96301M | 1 | K +W | 08.2004 - 10.2005 | |
| K6301VD210 | DOOR MIRROR ASSY-RH | 96301M | 1 | K +W | 10.2005 - 12.2006 | |
| 96301VB401 | DOOR MIRROR ASSY-RH | 96301M | 1 | K +W | 02.2000 - 10.2002 | |
| K6301VD21A | DOOR MIRROR ASSY-RH | 96301M | 1 | K +W | 12.2006 - ... | |
| 96302VB421 | DOOR MIRROR ASSY-LH | 96302M | 1 | K +W.(GR+GRX) | 07.2003 - 08.2004 | |
| 96302VB411 | DOOR MIRROR ASSY-LH | 96302M | 1 | *K +*W | DOOR MIRROR HEATER | 02.2000 - 10.2002 |
| K6302VD210 | DOOR MIRROR ASSY-LH | 96302M | 1 | K +W | 08.2004 - 10.2005 | |
| K6302VD210 | DOOR MIRROR ASSY-LH | 96302M | 1 | K +W | 10.2005 - 12.2006 | |
| K6302VD21A | DOOR MIRROR ASSY-LH | 96302M | 1 | K +W | 12.2006 - ... | |
| 96302VB401 | DOOR MIRROR ASSY-LH | 96302M | 1 | K +W | 02.2000 - 10.2002 | |
| 96302VB411 | DOOR MIRROR ASSY-LH | 96302M | 1 | K +W.(GR+GRX) | 10.2002 - 07.2003 | |
| 083686122G | SCR-HEX HD,PP W | 083686122G | ||||
| 963653S300 | GLASS-MIRROR,RH | 96365M | 1 | *K +*W | DOOR MIRROR HEATER | 02.2000 - 10.2002 |
| 963653S300 | GLASS-MIRROR,RH | 96365M | 1 | K +W.(GR+GRX) | 10.2002 - 07.2003 | |
| 963653S305 | GLASS-MIRROR,RH | 96365M | 1 | K +W | 08.2004 - ... | |
| 96365VB301 | GLASS-MIRROR,RH | 96365M | 1 | K +W | 02.2000 - 10.2002 | |
| 963653S305 | GLASS-MIRROR,RH | 96365M | 1 | K +W.(GR+GRX) | 07.2003 - 08.2004 | |
| 963663S300 | GLASS-MIRROR,LH | 96366M | 1 | K +W.(GR+GRX) | 10.2002 - 07.2003 | |
| 963663S305 | GLASS-MIRROR,LH | 96366M | 1 | K +W.(GR+GRX) | 07.2003 - 08.2004 | |
| 963663S305 | GLASS-MIRROR,LH | 96366M | 1 | K +W | 08.2004 - ... | |
| 963663S300 | GLASS-MIRROR,LH | 96366M | 1 | *K +*W | DOOR MIRROR HEATER | 02.2000 - 10.2002 |
| 96366VB301 | GLASS-MIRROR,LH | 96366M | 1 | K +W | 02.2000 - 10.2002 | |
| 80292VB000 | COVER-FRONT DOOR CORNER,INNER RH | 80292 | 1 | K +W | 02.2000 - 10.2002 | |
| 80292VD200 | COVER-FRONT DOOR CORNER,INNER RH | 80292 | 1 | K +W | 08.2004 - ... | |
| 80292VB000 | COVER-FRONT DOOR CORNER,INNER RH | 80292 | 1 | K +W | 10.2002 - 08.2004 | |
| 80293VB000 | COVER-FRONT DOOR CORNER,INNER LH | 80293 | 1 | K +W | 02.2000 - 10.2002 | |
| 80293VD200 | COVER-FRONT DOOR CORNER,INNER LH | 80293 | 1 | K +W | 08.2004 - ... | |
| 80293VB000 | COVER-FRONT DOOR CORNER,INNER LH | 80293 | 1 | K +W | 10.2002 - 08.2004 | |
| 0155301583 | CLIP | 96300F | 2 | K +W | 10.2002 - 08.2004 | |
| 0155301583 | CLIP | 96300F | 2 | K +W | 08.2004 - ... | |
| 0155301583 | CLIP | 96300F | 2 | K +W | 02.2000 - 10.2002 | |
| 7684851S00 | GROMMET | 96300E | 4 | K +W | 08.2004 - ... | |
| 7684851S00 | GROMMET | 96300E | 4 | K +W | 02.2000 - 10.2002 | |
| 7684851S00 | GROMMET | 96300E | 4 | K +W | 10.2002 - 08.2004 |
REAR VIEW MIRROR; OUTSIDE MIRROR
| Number | Name | Code | Qty Required | ApplicableModels | Specs | Prod. Date |
|---|---|---|---|---|---|---|
| 96301VB411 | DOOR MIRROR ASSY-RH | 96301M | 1 | K +W.(GR+GRX) | 10.2002 - 07.2003 | |
| 96301VB411 | DOOR MIRROR ASSY-RH | 96301M | 1 | *K +*W | DOOR MIRROR HEATER | 02.2000 - 10.2002 |
| 96301VB421 | DOOR MIRROR ASSY-RH | 96301M | 1 | K +W.(GR+GRX) | 07.2003 - 08.2004 | |
| K6301VD210 | DOOR MIRROR ASSY-RH | 96301M | 1 | K +W | 08.2004 - 10.2005 | |
| K6301VD210 | DOOR MIRROR ASSY-RH | 96301M | 1 | K +W | 10.2005 - 12.2006 | |
| 96301VB401 | DOOR MIRROR ASSY-RH | 96301M | 1 | K +W | 02.2000 - 10.2002 | |
| K6301VD21A | DOOR MIRROR ASSY-RH | 96301M | 1 | K +W | 12.2006 - ... | |
| 96302VB421 | DOOR MIRROR ASSY-LH | 96302M | 1 | K +W.(GR+GRX) | 07.2003 - 08.2004 | |
| 96302VB411 | DOOR MIRROR ASSY-LH | 96302M | 1 | *K +*W | DOOR MIRROR HEATER | 02.2000 - 10.2002 |
| K6302VD210 | DOOR MIRROR ASSY-LH | 96302M | 1 | K +W | 08.2004 - 10.2005 | |
| K6302VD210 | DOOR MIRROR ASSY-LH | 96302M | 1 | K +W | 10.2005 - 12.2006 | |
| K6302VD21A | DOOR MIRROR ASSY-LH | 96302M | 1 | K +W | 12.2006 - ... | |
| 96302VB401 | DOOR MIRROR ASSY-LH | 96302M | 1 | K +W | 02.2000 - 10.2002 | |
| 96302VB411 | DOOR MIRROR ASSY-LH | 96302M | 1 | K +W.(GR+GRX) | 10.2002 - 07.2003 | |
| 083686122G | SCR-HEX HD,PP W | 083686122G | ||||
| 963653S300 | GLASS-MIRROR,RH | 96365M | 1 | *K +*W | DOOR MIRROR HEATER | 02.2000 - 10.2002 |
| 963653S300 | GLASS-MIRROR,RH | 96365M | 1 | K +W.(GR+GRX) | 10.2002 - 07.2003 | |
| 963653S305 | GLASS-MIRROR,RH | 96365M | 1 | K +W | 08.2004 - ... | |
| 96365VB301 | GLASS-MIRROR,RH | 96365M | 1 | K +W | 02.2000 - 10.2002 | |
| 963653S305 | GLASS-MIRROR,RH | 96365M | 1 | K +W.(GR+GRX) | 07.2003 - 08.2004 | |
| 963663S300 | GLASS-MIRROR,LH | 96366M | 1 | K +W.(GR+GRX) | 10.2002 - 07.2003 | |
| 963663S305 | GLASS-MIRROR,LH | 96366M | 1 | K +W.(GR+GRX) | 07.2003 - 08.2004 | |
| 963663S305 | GLASS-MIRROR,LH | 96366M | 1 | K +W | 08.2004 - ... | |
| 963663S300 | GLASS-MIRROR,LH | 96366M | 1 | *K +*W | DOOR MIRROR HEATER | 02.2000 - 10.2002 |
| 96366VB301 | GLASS-MIRROR,LH | 96366M | 1 | K +W | 02.2000 - 10.2002 | |
| 80292VB000 | COVER-FRONT DOOR CORNER,INNER RH | 80292 | 1 | K +W | 02.2000 - 10.2002 | |
| 80292VD200 | COVER-FRONT DOOR CORNER,INNER RH | 80292 | 1 | K +W | 08.2004 - ... | |
| 80292VB000 | COVER-FRONT DOOR CORNER,INNER RH | 80292 | 1 | K +W | 10.2002 - 08.2004 | |
| 80293VB000 | COVER-FRONT DOOR CORNER,INNER LH | 80293 | 1 | K +W | 02.2000 - 10.2002 | |
| 80293VD200 | COVER-FRONT DOOR CORNER,INNER LH | 80293 | 1 | K +W | 08.2004 - ... | |
| 80293VB000 | COVER-FRONT DOOR CORNER,INNER LH | 80293 | 1 | K +W | 10.2002 - 08.2004 | |
| 0155301583 | CLIP | 96300F | 2 | K +W | 10.2002 - 08.2004 | |
| 0155301583 | CLIP | 96300F | 2 | K +W | 08.2004 - ... | |
| 0155301583 | CLIP | 96300F | 2 | K +W | 02.2000 - 10.2002 | |
| 7684851S00 | GROMMET | 96300E | 4 | K +W | 08.2004 - ... | |
| 7684851S00 | GROMMET | 96300E | 4 | K +W | 02.2000 - 10.2002 | |
| 7684851S00 | GROMMET | 96300E | 4 | K +W | 10.2002 - 08.2004 |
