ENGINE
SPARK PLUG & CABLE; 01/02
| Number | Name | Code | Date_range | Options | Remarks | Qty Required |
|---|---|---|---|---|---|---|
| 1339608007K | NUT | 1339GA | 01.08.2005 - 31.12.2006 | ENGINE CAPACITY: 1400 CC | 2 | |
| 2750126D00 | CABLE SET - SPARK PLUG | 27501 | 01.08.2005 - 31.12.2006 | ENGINE CAPACITY: 1400 CC | 1 | |
| 2750122B10 | CABLE SET - SPARK PLUG | 27501 | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | 1 | |
| 2748232500 | SUPPORT - CABLE | 27482A | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | 1 | |
| 2742026700 | CABLE ASSY - SPARK PLUG NO. 1 | 27420 | 01.08.2005 - 31.12.2006 | ENGINE CAPACITY: 1400 CC | 1 | |
| 2742022020 | CABLE ASSY - SPARK PLUG NO. 1 | 27420 | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | 1 | |
| 2836721300 | CLAMP - (HOSE) | 28367 | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | 1 | |
| 2745026700 | CABLE ASSY - SPARK PLUG NO. 4 | 27450 | 01.08.2005 - 31.12.2006 | ENGINE CAPACITY: 1400 CC | 1 | |
| 2745022020 | CABLE ASSY - SPARK PLUG NO. 4 | 27450 | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | 1 | |
| 2748622000 | CLAMP - CABLE | 27486 | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | 1 | |
| 2748522000 | CLAMP - CABLE | 27485 | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | 1 | |
| 2744026700 | CABLE ASSY - SPARK PLUG NO. 3 | 27440 | 01.08.2005 - 31.12.2006 | ENGINE CAPACITY: 1400 CC | 1 | |
| 2744022020 | CABLE ASSY - SPARK PLUG NO. 3 | 27440 | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | 1 | |
| 2743026700 | CABLE ASSY - SPARK PLUG NO. 2 | 27430 | 01.08.2005 - 31.12.2006 | ENGINE CAPACITY: 1400 CC | 1 | |
| 2743022020 | CABLE ASSY - SPARK PLUG NO. 2 | 27430 | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | 1 | |
| 1882311101 | PLUG ASSY - SPARK | 10930A | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | RC10YC4 | 1 |
| 1881411051 | PLUG ASSY - SPARK | 10930A | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | BKR5ES-11 | 4 |
| 2730122600 | COIL ASSY - IGNITION | 27301 | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | 1 | |
| 2730126600 | COIL ASSY - IGNITION | 27301 | 01.08.2005 - 31.12.2006 | ENGINE CAPACITY: 1400 CC | 1 | |
| 2736622602 | BRACKET - CONNECTOR | 27366 | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | 1 | |
| 2732522610 | CONDENSER ASSY - IGNITION COIL | 27325 | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | 1 | |
| 2732522600 | CONDENSER ASSY - IGNITION COIL | 27325 | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | 1 | |
| 2731026600 | COIL - IGNITION | 27310 | 01.08.2005 - 31.12.2006 | ENGINE CAPACITY: 1400 CC | 1 | |
| 2731022610 | COIL - IGNITION | 27310 | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | 1 | |
| 2731022600 | COIL - IGNITION | 27310 | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | 1 | |
| 2736522600 | BRACKET - IGNITION COIL | 27365E | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | 1 | |
| 1231005107B | SCREW - MACHINE | 1231DB | 01.08.2005 - 31.12.2006 | ENGINE CAPACITY: 1400 CC | 1 | |
| 1231005103 | SCREW - MACHINE | 1230BA | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | 1 | |
| 9195225400 | BRACKET - WIRING | 91591 | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | 1 | |
| 1231006167B | SCREW - MACHINE | 1231FH | 01.08.2005 - 31.12.2006 | ENGINE CAPACITY: 1400 CC | 4 | |
| 1231006163 | SCREW - MACHINE | 1231FH | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | 4 | |
| 1735006000 | PLUG | 1735AA | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | 2 | |
| 1140308167K | BOLT | 1140FD | 01.08.2005 - 31.12.2006 | ENGINE CAPACITY: 1400 CC | 1 | |
| 1140308163 | BOLT | 1140FD | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | NEW A/T | 2 |
SPARK PLUG & CABLE; 02/02
| Number | Name | Code | Date_range | Options | Remarks | Qty Required |
|---|---|---|---|---|---|---|
| 9195225400 | BRACKET - WIRING | 91591 | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | 1 | |
| 1735006000 | PLUG | 1735AA | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | 2 | |
| 2836721300 | CLAMP - (HOSE) | 28367 | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | 1 | |
| 2748622000 | CLAMP - CABLE | 27486 | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | 1 | |
| 2748522000 | CLAMP - CABLE | 27485 | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | 1 | |
| 2748232500 | SUPPORT - CABLE | 27482A | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | 1 | |
| 2736522600 | BRACKET - IGNITION COIL | 27365E | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | 1 | |
| 2750126D00 | CABLE SET - SPARK PLUG | 27501 | 01.08.2005 - 31.12.2006 | ENGINE CAPACITY: 1400 CC | 1 | |
| 2750122B10 | CABLE SET - SPARK PLUG | 27501 | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | 1 | |
| 2743026700 | CABLE ASSY - SPARK PLUG NO. 2 | 27430 | 01.08.2005 - 31.12.2006 | ENGINE CAPACITY: 1400 CC | 1 | |
| 2743022020 | CABLE ASSY - SPARK PLUG NO. 2 | 27430 | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | 1 | |
| 2742026700 | CABLE ASSY - SPARK PLUG NO. 1 | 27420 | 01.08.2005 - 31.12.2006 | ENGINE CAPACITY: 1400 CC | 1 | |
| 2742022020 | CABLE ASSY - SPARK PLUG NO. 1 | 27420 | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | 1 | |
| 2745026700 | CABLE ASSY - SPARK PLUG NO. 4 | 27450 | 01.08.2005 - 31.12.2006 | ENGINE CAPACITY: 1400 CC | 1 | |
| 2745022020 | CABLE ASSY - SPARK PLUG NO. 4 | 27450 | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | 1 | |
| 2744026700 | CABLE ASSY - SPARK PLUG NO. 3 | 27440 | 01.08.2005 - 31.12.2006 | ENGINE CAPACITY: 1400 CC | 1 | |
| 2744022020 | CABLE ASSY - SPARK PLUG NO. 3 | 27440 | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | 1 | |
| 1881411051 | PLUG ASSY - SPARK | 10930A | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | BKR5ES-11 | 4 |
| 1882311101 | PLUG ASSY - SPARK | 10930A | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | RC10YC4 | 1 |
| 2730126600 | COIL ASSY - IGNITION | 27301 | 01.08.2005 - 31.12.2006 | ENGINE CAPACITY: 1400 CC | 1 | |
| 2730122600 | COIL ASSY - IGNITION | 27301 | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | 1 | |
| 2736622602 | BRACKET - CONNECTOR | 27366 | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | 1 | |
| 1339608007K | NUT | 1339GA | 01.08.2005 - 31.12.2006 | ENGINE CAPACITY: 1400 CC | 2 | |
| 1231006163 | SCREW - MACHINE | 1231FH | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | 4 | |
| 1231006167B | SCREW - MACHINE | 1231FH | 01.08.2005 - 31.12.2006 | ENGINE CAPACITY: 1400 CC | 4 | |
| 1140308167K | BOLT | 1140FD | 01.08.2005 - 31.12.2006 | ENGINE CAPACITY: 1400 CC | 1 | |
| 1140308163 | BOLT | 1140FD | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | NEW A/T | 2 |
| 2731026600 | COIL - IGNITION | 27310 | 01.08.2005 - 31.12.2006 | ENGINE CAPACITY: 1400 CC | 1 | |
| 2731022610 | COIL - IGNITION | 27310 | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | 1 | |
| 2731022600 | COIL - IGNITION | 27310 | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | 1 | |
| 2732522610 | CONDENSER ASSY - IGNITION COIL | 27325 | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | 1 | |
| 2732522600 | CONDENSER ASSY - IGNITION COIL | 27325 | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | 1 | |
| 1231005107B | SCREW - MACHINE | 1231DB | 01.08.2005 - 31.12.2006 | ENGINE CAPACITY: 1400 CC | 1 | |
| 1231005103 | SCREW - MACHINE | 1230BA | 01.09.2002 - 01.08.2005 | ENGINE CAPACITY: 1300 CC | 1 |
