Catalog
Brand Name Code

HYUNDAI

Hyundai HYW201905
Model
NameFamilyVehicle CategoryModel Year FromModel Year ToModel Option S
HB20/HB20SHB20Passenger20162019IJS4D26F7TRANSAXLE: (7) MANUAL T/M - 6 SP

TRANSMISSION

TRANSAXLE GEAR - MANUAL

01/02
NumberNameCode
4322426280Ring - snap43224T
4322426250Ring - snap43224T
4322423450Ring - snap43224T
4322426310Ring - snap43224T
4322426340Ring - snap43224T
4322426430Ring - snap43224T
4322426370Ring - snap43224T
4322421380Ring - snap43224T
4322426400Ring - snap43224T
4322421240Ring - snap43224T
4322421310Ring - snap43224T
4325926000Sleeve - 4th speed gear43259B
4322126230Shaft - input43221B
4322232000Bearing43222C
4322526AA0Bearing - ball43223C
4322532000Bearing - taper roller43225B
4325432000Washer - thrust43254B
4326026200Gear assy - 3rd speed43260
4327932192Ring - snap43278A
4327932196Ring - snap43278A
4327932212Ring - snap43278A
4327932208Ring - snap43278A
4327932200Ring - snap43278A
4327932188Ring - snap43278A
4327932204Ring - snap43278A
4321526120Shaft - output43215
4339426212Ring - synchronizer (3rd)43394
4339426210Ring - synchronizer (3rd)43394
4339426600Ring - synchronizer (3rd)43394
4328026230Gear assy - 4th speed43280
4324026220Gear assy - 5th speed43240
4337626002Sleeve - synchronizer43376
4325026000Gear assy - 1st speed43281
4325026600Gear assy - 1st speed43281
4333123071Spacer43331T
4333123083Spacer43331T
4333123074Spacer43331T
4333123077Spacer43331T
4333123086Spacer43331T
4333123089Spacer43331T
4333123095Spacer43331T
4333123092Spacer43331T
4333123098Spacer43331T
4333123113Spacer43331T
4333123080Spacer43331T
4333123110Spacer43331T
4333123116Spacer43331T
4333123119Spacer43331T
4333123128Spacer43331T
4333123122Spacer43331T
4333123107Spacer43331T
4333123125Spacer43331T
4333123104Spacer43331T
4333123101Spacer43331T
4322332000Bearing - manual transmission input shaft rear43223
4326534060Bearing - needle roller43265A
4324326000Sleeve - 5th speed gear43243
4337726002Sleeve - synchronizer43377A
4337526100Sleeve - synchronizer43375
4325526000Bearing - input shaft43255
433723A010Key - synchronizer43372
4335226002Hub - synchronizer (3 & 4)43351B
4325326000Bearing - needle roller43253B
4329026230Gear assy - 6th speed43290B
4335326002Hub - synchronizer (5 & 6)43351D
4335026000Ring assy - triple cone (1st)43350G
4329426100Sleeve - 6th gear43294C
4335126001Hub - synchronizer43351A
4327026030Gear assy - 2nd speed43270
4337426200Ring - synchronizer (4, 5, 6)43374G
4337426600Ring - synchronizer (4, 5, 6)43374G
4335026010Ring assy - triple cone (2nd)43350J
4326326000Gear - 3rd speed output43263
4325826000Sleeve - 2nd speed gear43258
4321626051Nut - locking43216
4331026000Gear assy - reverse idler43310
4327526000Bearing - needle43275
4328326030Gear - 4th speed output43282A
4385526000Spacer reverse43855C
4322626AA0Bearing43226A
4322626000Bearing - manual transmission output shaft rear43220C
4332126100Shaft - reverse idler gear43321
4322826000Bearing - ball43225A
4323026020Gear - 5th speed output43230
4329326030Gear - 6th main43293B
4331834001Bolt - reverse idler43318
4331934000Gasket - reverse idler gear shaft43319
4320332070Spacer43227T
4320332067Spacer43227T
4320332064Spacer43227T
4320332055Spacer43227T
4320332073Spacer43227T
4320332052Spacer43227T
4320332058Spacer43227T
4320332061Spacer43227T
4320332085Spacer43227T
4320332100Spacer43227T
4320332103Spacer43227T
4320332106Spacer43227T
4320332109Spacer43227T
4320332097Spacer43227T
4320332094Spacer43227T
4320332079Spacer43227T
4320332082Spacer43227T
4320332088Spacer43227T
4320332076Spacer43227T
4320332091Spacer43227T
4321626151Nut - locking43287
