Catalog
Brand Name Code

HYUNDAI

Hyundai HYW201905
Model
NameFamilyVehicle CategoryModel Year FromModel Year ToModel Option S
Grand StarexGrand StarexR/V20072015GDBCL4B4BTRANSAXLE: (B) AUTO - 4 SPEED 2W

ELECTRIC

HEATER SYSTEM - HEATER & BLOWER

01/02
NumberNameCode
972004H000Heater unit97202
972004H050Heater unit97202
972004H150Heater unit97202
972004H250Heater unit97202
971114H000Duct - foot shower, lh97112E
971114H000Duct - foot shower, lh97112E
971114H000Duct - foot shower, lh97112E
971114H000Duct - foot shower, lh97112E
971544H000Actuator motor assy97107A
971544H000Actuator motor assy97107A
971344H050Seal - duct no. 497246L
971344H050Seal - duct no. 497246L
971494H000Link - air inlet door97108
971494H000Link - air inlet door97108
971494H000Link - air inlet door97108
971494H000Link - air inlet door97108
972414H000Seal (a) - heater to ventilator97129F
972414H000Seal (a) - heater to ventilator97129F
972424H000Seal (b) - heater to duct97230K
972424H000Seal (b) - heater to duct97230K
971834H000Arm - ventilator door97224C
971834H000Arm - ventilator door97224C
971834H000Arm - ventilator door97224C
971834H000Arm - ventilator door97224C
9731317000Grommet - heater pipe97313
9731317000Grommet - heater pipe97313
971844H000Arm - defroster door97211J
971844H000Arm - defroster door97211J
971844H000Arm - defroster door97211J
971844H000Arm - defroster door97211J
972444H000Seal (d) - heater to duct97230M
972444H000Seal (d) - heater to duct97230M
971344H000Case - heater & evaporator, lh97134L
971344H000Case - heater & evaporator, lh97134L
971504H000Lever - floor door97111B
971504H000Lever - floor door97111B
971504H000Lever - floor door97111B
971504H000Lever - floor door97111B
9731534000Cover - heater pipe97211C
9731534000Cover - heater pipe97211C
971644H000Washer - spring97235C
971644H000Washer - spring97235C
971644H000Washer - spring97235C
971644H000Washer - spring97235C
1327106006BNut [w/ washer ]1327AB
1327106006BNut [w/ washer ]1327AB
971874H000Clip - heater case97187B
971874H000Clip - heater case97187B
971874H000Clip - heater case97187B
971874H000Clip - heater case97187B
9731417000Grommet - heater pipe97261A
9731417000Grommet - heater pipe97261A
971344H010Seal - duct no. 197246H
971344H010Seal - duct no. 197246H
972464H000Seal - duct no. 197246H
972464H000Seal - duct no. 197246H
971474H000Door assy - defroster97147A
971474H000Door assy - defroster97147A
971854H000Arm - mode door97240
971854H000Arm - mode door97240
971854H000Arm - mode door97240
971854H000Arm - mode door97240
971604H000Actuator - temperature door97236E
971604H000Actuator - temperature door97236E
971604H000Actuator - temperature door97236E
971604H000Actuator - temperature door97236E
971864H000Arm - temperature door97115B
971864H000Arm - temperature door97115B
971864H000Arm - temperature door97115B
971864H000Arm - temperature door97115B
971464H000Door assy - ventilator97146A
971464H000Door assy - ventilator97146A
971354H050Case - heater & evaporator, rh97134R
971354H050Case - heater & evaporator, rh97134R
971064F000Screw - tapping97114C
971064F000Screw - tapping97114C
971064F000Screw - tapping97114C
971064F000Screw - tapping97114C
972434H000Seal (c) - heater to duct97230L
972434H000Seal (c) - heater to duct97230L
971484H000Door assy - foot97148B
971484H000Door assy - foot97148B
1327008001Nut [washer assy]1327AC
1327008001Nut [washer assy]1327AC
1327008001Nut [washer assy]1327AC
1327008001Nut [washer assy]1327AC
972454H000Seal97367
972454H000Seal97367
972184H000Lever - floor door97223G
972184H000Lever - floor door97223G
971554H000Clamp - heater core pipe97155D
971554H000Clamp - heater core pipe97155D
971554H000Clamp - heater core pipe97155D
971554H000Clamp - heater core pipe97155D
972674H000Sensor - heater water temperature97267C
972674H000Sensor - heater water temperature97267C
971714H000Cover - heater core97122
971714H000Cover - heater core97122
971714H000Cover - heater core97122
971714H000Cover - heater core97122
972824H000Duct - foot shower, rh97112D
972824H000Duct - foot shower, rh97112D
972824H000Duct - foot shower, rh97112D
972824H000Duct - foot shower, rh97112D
972324H000Nut97047
972324H000Nut97047
971384H000Core assy - heater97926
971384H000Core assy - heater97926
971384H000Core assy - heater97926
971384H000Core assy - heater97926
972724H000Clamp97371
972724H000Clamp97371
971914H000Ptc heater97191B
971914H000Ptc heater97191B
1129308201Bolt1129EJ
1129308201Bolt1129EJ
1129308201Bolt1129EJ
1129308201Bolt1129EJ
1125408201Bolt1125KE
1125408201Bolt1125KE
