Catalog
Brand Name Code

HYUNDAI

Hyundai HYW201905
Model
NameFamilyVehicle CategoryModel Year FromModel Year ToModel Option S
I20I20Passenger20142018C7S8K461BTRANSAXLE: (B) AUTO - 4 SPEED 2W

CHASSIS

POWER STEERING GEARBOX

01/02
NumberNameCode
565001R091Gear assy - steering56500B
565001R101Gear assy - steering56500B
565171C000Packing - dust56517B
565171C000Packing - dust56517B
5655325000Stopper - rack57738B
5655325000Stopper - rack57738B
565160U500Cap - dust56856
565160U500Cap - dust56856
562240U500Clamp - steering gearbox mounting [ b ]56224A
562240U500Clamp - steering gearbox mounting [ b ]56224A
565181C100Seal - oil56529
565181C100Seal - oil56529
565511C100Top plug - steering gearbox56551B
565511C100Top plug - steering gearbox56551B
577182D000Nut - lock57718A
577182D000Nut - lock57718A
56552B4000Bearing56551C
56552B4000Bearing56551C
562220U500Rubber - gearbox mounting56222
562220U500Rubber - gearbox mounting56222
577201R100Spring - yoke57720
577201R100Spring - yoke57720
5652207600Rubber - cushion56522
5652207600Rubber - cushion56522
565111R501Pinion assy - steering gearbox56510B
565111R591Pinion assy - steering gearbox56510B
565551Y600Rack bush56555B
565550X500Rack bush56555B
565551Y600Rack bush56555B
577371R100Plug - yoke57737
577371R100Plug - yoke57737
57715C8000Yoke assy - rack support57715
57715C8000Yoke assy - rack support57715
577151R100Yoke assy - rack support57715
577573K000Bearing - needle57757
577573K000Bearing - needle57757
565120U500Rack56512A
565121R090Rack56512A
572801R090Heat protector assy - power steering57280
572801R000Heat protector assy - power steering57280
565180U000Bush - rack57753
565180U000Bush - rack57753
1124212356KBolt - washer assy1124AA
1124212356KBolt - washer assy1124AA
1123612356KBolt - washer assy1124AE
1123612356KBolt - washer assy1124AE
577402K001Bellows - steering gearbox57774
577402K001Bellows - steering gearbox57774
1140306106KBolt1140FZ
1140306106KBolt1140FZ
568211R591End assy - tie rod, rh56820J
568211R591End assy - tie rod, rh56820J
577592E000Nut57146
577592E000Nut57146
1123306126BBolt - washer assy1123GF
1123306126BBolt - washer assy1123GF
5778347300Clip - hose57783B
5778347300Clip - hose57783B
565400U500Inner ball joint assy56540A
565400U500Inner ball joint assy56540A
1123412506KBolt1123MC
1123412506KBolt1123MC
565271R000Steel bend56527D
565271R000Steel bend56527D
577994D200Pin1430AK
577994D200Pin1430AK
5773907600Washer57739B
5773907600Washer57739B
568201R501End assy - tie rod, lh56820H
568201R501End assy - tie rod, lh56820H
1313410007KNut - slotted1313DA
1313410007KNut - slotted1313DA

POWER STEERING GEARBOX

02/02
NumberNameCode
565001R101Gear assy - steering56500B
565001R091Gear assy - steering56500B
565171C000Packing - dust56517B
565171C000Packing - dust56517B
565160U500Cap - dust56856
565160U500Cap - dust56856
565181C100Seal - oil56529
565181C100Seal - oil56529
577182D000Nut - lock57718A
577182D000Nut - lock57718A
565511C100Top plug - steering gearbox56551B
565511C100Top plug - steering gearbox56551B
577201R100Spring - yoke57720
577201R100Spring - yoke57720
56552B4000Bearing56551C
56552B4000Bearing56551C
565111R501Pinion assy - steering gearbox56510B
565111R591Pinion assy - steering gearbox56510B
577371R100Plug - yoke57737
577371R100Plug - yoke57737
57715C8000Yoke assy - rack support57715
57715C8000Yoke assy - rack support57715
577151R100Yoke assy - rack support57715
565121R090Rack56512A
565120U500Rack56512A
562240U500Clamp - steering gearbox mounting [ b ]56224A
562240U500Clamp - steering gearbox mounting [ b ]56224A
562220U500Rubber - gearbox mounting56222
562220U500Rubber - gearbox mounting56222
577573K000Bearing - needle57757
577573K000Bearing - needle57757
5652207600Rubber - cushion56522
5652207600Rubber - cushion56522
565551Y600Rack bush56555B
565551Y600Rack bush56555B
565550X500Rack bush56555B
5655325000Stopper - rack57738B
5655325000Stopper - rack57738B
577402K001Bellows - steering gearbox57774
577402K001Bellows - steering gearbox57774
1123412506KBolt1123MC
1123412506KBolt1123MC
1123612356KBolt - washer assy1124AE
1123612356KBolt - washer assy1124AE
568211R591End assy - tie rod, rh56820J
568211R591End assy - tie rod, rh56820J
1124212356KBolt - washer assy1124AA
1124212356KBolt - washer assy1124AA
577592E000Nut57146
577592E000Nut57146
5778347300Clip - hose57783B
5778347300Clip - hose57783B
565400U500Inner ball joint assy56540A
565400U500Inner ball joint assy56540A
1125106166KBolt - washer assy1125DA
565180U000Bush - rack57753
565180U000Bush - rack57753
565271R000Steel bend56527D
565271R000Steel bend56527D
577994D200Pin1430AK
577994D200Pin1430AK
572801R090Heat protector assy - power steering57280
572801R000Heat protector assy - power steering57280
1140306106KBolt1140FZ
1140306106KBolt1140FZ
5773907600Washer57739B
5773907600Washer57739B
568201R501End assy - tie rod, lh56820H
1123306126BBolt - washer assy1123GF
1123306126BBolt - washer assy1123GF
568201R501End assy - tie rod, lh56820H
1313410007KNut - slotted1313DA
1313410007KNut - slotted1313DA
