Catalog
Brand Name Code

HYUNDAI

Hyundai HYW201905
Model
NameFamilyVehicle CategoryModel Year FromModel Year ToModel Option S
NEW PONY (1982-1986)New PonyPassenger19821986APGR4GPUSpecial Car: (G) GENERAL;Grade:

TRANSMISSION

TRANSMISSION CASE

4 M/T
NumberNameCode
4143011900Shaft complete - clutch realese fork41430A
4145311001Pin - [ spring ]41453
4145311000Pin - [ spring ]41453
4143511900Lever assy - clutch control41435
4145111000Spring - return, lh41451A
4144111000Arm - clutch shaft41441
4313411000Packing43134
4313311000Seal - oil43133
4311111101Case - manual transmission43111
4311111100Case - manual transmission43111
4314411000Retainer - bearing rear43144
4145211000Spring - return, rh41452
1123008251Bolt1123AS
4314511000Plate - stop43145A
4314311010Seal - oil43143
4314311000Seal - oil43143
4142114500Bearing - clutch release41421C
4142133020Bearing - clutch release41421C
4313434000Seal - oil21421
4313111000Bush - clutch control shaft43131A
4313211000Cap43132A
1751116000Gasket1751DD
4141111000Body - cylinder41411A
4312111000Plug - magnet43121
4318111000Housing - center43181
1153008205Stud1153AA
4142111000Bearing - clutch release41421B
4314211000Gasket - bearing retainer front43142
4314111000Retainer - bearing front43141
4142211000Clip - return41422
1360208001Washer - spring1360GG
1123008161Bolt [w/ washer]1123AN
4312211000Cover - inspection hole43122
1320008001Nut1320AA
4316011000Cover assy - under43160
4317111000Plug - drain43171

TRANSMISSION CASE

5 M/T
NumberNameCode
4310014590Case - transmission43100
Case - manual transmission43111
4314514500Bush - knock43145B
4313311000Seal - oil43133
4145211000Spring - return, rh41452
4143014590Shaft complete - clutch realese fork41430A
4145311000Pin - [ spring ]41453
4145311001Pin - [ spring ]41453
4145111000Spring - return, lh41451A
4314414500Retainer - bearing rear43144
4313211000Cap43132A
4313411000Packing43134
4313111000Bush - clutch control shaft43131A
4316714500Gasket - under cover43167
4314114500Retainer - bearing front43141
1751116000Gasket1751DD
4312111000Plug - magnet43121
1113008121Bolt [w/ washer]1113AH
1123008161Bolt [w/ washer]1123AN
4314311010Seal - oil43143
4314311000Seal - oil43143
4313434000Seal - oil21421
4314614500Seal - oil43146A
Plate - connection43112A
4314214500Gasket - bearing retainer front43142
4142211000Clip - return41422
4142114500Bearing - clutch release41421C
4142133020Bearing - clutch release41421C
4316014500Cover assy - under43160
Cover - under43116A
5221311100Plug - drain52213A
4314814500Plug - expansion43148
