ENGINE
FRONT CASE; 01/02
| Number | Name | Code | Date_range | Remarks | Qty Required |
|---|---|---|---|---|---|
| 2630042040 | FILTER ASSY - ENGINE OIL | 26300 | 17.08.2000 - 02.05.2007 | 1 | |
| 9475037000 | SWITCH ASSY - OIL PRESSURE | 94750 | 03.11.2003 - 01.01.2007 | 1 | |
| 1571717121 | PLUG - TAPER | 1571TC | 03.10.2003 - 01.01.2007 | 1 | |
| 1571713111 | PLUG - TAPER | 1571TB | 01.09.1999 - 02.05.2007 | 1 | |
| 2632542000 | VALVE - OIL COOLER BY-PASS | 26325 | 12.03.2001 - 01.01.2007 | 1 | |
| 2143142060 | PLATE - CYLINDER BLOCK, REAR | 21431 | 13.02.2004 - 01.01.2007 | 1 | |
| 2143142001 | PLATE - CYLINDER BLOCK, REAR | 21431 | 01.09.1999 - 13.02.2004 | 1 | |
| 1140306106K | BOLT | 1140FZ | 01.09.2006 - 01.01.2007 | 2 | |
| 1140306103 | BOLT | 1140FZ | 21.10.2002 - 01.09.2006 | 2 | |
| 2632542011 | VALVE - OIL COOLER BY-PASS | 26325 | 12.03.2001 - 01.01.2007 | 1 | |
| 2633542001 | CAP - OIL FILTER BRACKET | 26335 | 22.08.2001 - 01.01.2007 | 1 | |
| 2632442100 | NIPPLE | 22133 | 01.09.1999 - 02.03.2001 | 1 | |
| 9475021030 | SWITCH ASSY - OIL PRESSURE | 94750 | 01.09.1999 - 12.03.2001 | 1 | |
| 1123306123 | BOLT - WASHER ASSY | 1123GF | 01.09.1999 - 13.02.2004 | 2 | |
| 2632042115 | BRACKET ASSY - OIL FILTER | 21394 | 12.03.2001 - 03.11.2003 | 1 | |
| 2632042116 | BRACKET ASSY - OIL FILTER | 21394 | 03.11.2003 - 02.05.2007 | 1 | |
| 2632642060 | GASKET - OIL FILTER BRACKET | 21396 | 01.09.1999 - 27.12.2000 | 1 | |
| 2632642070 | GASKET - OIL FILTER BRACKET | 21396 | 27.12.2000 - 02.05.2007 | 1 | |
| 2632042110 | BRACKET ASSY - OIL FILTER | 21394 | 01.09.1999 - 12.03.2001 | 1 | |
| 1140308256K | BOLT | 1140EB | 14.12.2006 - 02.05.2007 | 1 | |
| 9475042000 | SWITCH ASSY - OIL PRESSURE | 94750 | 12.03.2001 - 03.11.2003 | 1 | |
| 1123308166K | BOLT | 1123GT | 14.12.2006 - 02.05.2007 | 1 | |
| 1123308163 | BOLT | 1123GT | 08.08.2001 - 01.01.2007 | 1 | |
| 2131042510 | CASE ASSY - FRONT | 21310B | 01.01.2007 - 02.05.2007 | 1 | |
| 2131042501 | CASE ASSY - FRONT | 21310B | 01.09.1999 - 03.07.2001 | 1 | |
| 1140308163 | BOLT | 1140FD | 01.09.1999 - 02.05.2007 | NEW A/T | 1 |
| 1140308756K | BOLT - FLANGE | 1011AC | 01.01.2007 - 02.05.2007 | 1 | |
| 2133042000 | BRACKET - FRONT CASE SUPPORT | 21330C | 01.09.1999 - 01.01.2007 | 1 | |
| 1140308753 | BOLT | 1140GB | 01.09.1999 - 01.01.2007 | 1 | |
| 2141142000 | GASKET - FRONT CASE, UPPER | 21411C | 01.09.1999 - 17.08.2000 | 1 | |
| 2141142060 | GASKET - FRONT CASE, UPPER | 21411C | 17.08.2000 - 03.07.2001 | 1 | |
| 2141142061 | GASKET - FRONT CASE, UPPER | 21411C | 02.06.2003 - 01.01.2007 | 1 | |
| 1151308306K | STUD | 1151CE | 01.01.2007 - 02.05.2007 | 2 | |
| 1151308305 | STUD | 1151CE | 01.09.1999 - 03.07.2001 | 2 | |
| 2132142011 | SEAL - OIL | 21321 | 01.09.1999 - 01.01.2007 | 1 | |
| 1140308253 | BOLT | 1140FH | 01.09.1999 - 03.07.2001 | FLANGE | 2 |
| 1140308353 | BOLT | 1140FH | 01.09.1999 - 03.07.2001 | 4 | |
| 1140308356K | BOLT | 1140FH | 01.09.2006 - 01.01.2007 | 4 | |
| 2139032000 | O-RING | 21390 | 01.09.1999 - 03.07.2001 | 1 | |
| 2139038000 | O-RING | 21390 | 02.04.2002 - 01.01.2007 | 1 | |
| 1140308556K | BOLT | 1140FR | 01.09.2006 - 01.01.2007 | 3 | |
| 1140308551 | BOLT | 1140FR | 01.09.1999 - 03.07.2001 | 3 | |
| 1140308553 | BOLT | 1140FR | 01.09.1999 - 03.07.2001 | 3 | |
| 2334242500 | GEAR - BALANCER SHAFT DRIVE | 23344 | 18.09.2001 - 01.01.2007 | 1 | |
| 1140308351 | BOLT | 1140FK | 03.10.2003 - 01.01.2007 | 3 | |
| 1430306140 | PIN - DOWEL | 1430JJ | 01.09.1999 - 01.01.2007 | 2 | |
| 2141242000 | GASKET - FRONT CASE, LOWER | 21412A | 01.09.1999 - 17.08.2000 | 1 | |
| 2141242060 | GASKET - FRONT CASE, LOWER | 21412A | 17.08.2000 - 03.07.2001 | 1 | |
| 2141242061 | GASKET - FRONT CASE, LOWER | 21412A | 03.06.2003 - 01.01.2007 | 1 | |
| 2139132020 | PLUG - CAP | 21391 | 01.09.1999 - 03.07.2001 | 1 | |
| 2139142000 | PLUG - CAP | 21391 | 23.02.2006 - 01.01.2007 | 1 | |
| 2334742500 | SLEEVE | 21726D | 01.09.1999 - 02.05.2007 | 1 | |
| 2614842800 | SCREW - MACHINE | 26148 | 01.09.1999 - 01.01.2007 | 6 | |
| 2334542000 | GEAR - BALANCER SHAFT DRIVEN | 23345 | 01.09.1999 - 01.01.2007 | 1 | |
| 2614242800 | COVER - OIL PUMP | 21313 | 11.10.1999 - 01.01.2007 | 1 | |
| 2132142021 | SEAL - OIL | 21321A | 01.09.1999 - 01.01.2007 | 1 | |
| 2614442805 | ROTOR - OIL PUMP OUTER | 26113C | 21.09.2003 - 02.05.2007 | 1 | |
| 2614442800 | ROTOR - OIL PUMP OUTER | 26113C | 01.09.1999 - 03.07.2001 | 1 | |
| 2614442804 | ROTOR - OIL PUMP OUTER | 26113C | 03.05.2002 - 21.09.2003 | 1 | |
| 2614342800 | ROTOR - OIL PUMP INNER | 26112C | 01.09.1999 - 03.07.2001 | 1 | |
| 2614342805 | ROTOR - OIL PUMP INNER | 26112C | 21.09.2003 - 02.05.2007 | 1 | |
| 2612321000 | SPRING - RELIEF | 26123 | 01.09.1999 - 03.07.2001 | 1 | |
| 2134542000 | SPRING - RELIEF | 26123 | 03.10.2003 - 01.01.2007 | 1 | |
| 2612242510 | PLUNGER - RELIEF | 26122 | 03.10.2003 - 01.01.2007 | 1 | |
| 2612221000 | PLUNGER - RELIEF | 26122 | 01.09.1999 - 03.07.2001 | 1 | |
| 2612411010 | PLUG | 26124 | 01.09.1999 - 03.07.2001 | 1 | |
| 261244A100 | PLUG | 26124 | 23.02.2006 - 01.01.2007 | 1 | |
| 2132142031 | SEAL - OIL | 21321B | 01.09.1999 - 01.01.2007 | 1 | |
| 2151311000 | GASKET - OIL PLUG | 21513 | 01.09.1999 - 02.05.2007 | 1 | |
| 1151308203 | STUD | 1151CF | 28.08.2006 - 01.01.2007 | 2 | |
| 2134042506 | CASE ASSY - OIL PUMP | 21340A | 03.10.2003 - 01.01.2007 | 1 | |
| 2134042501 | CASE ASSY - OIL PUMP | 21340A | 01.09.1999 - 03.07.2001 | 1 | |
| 2134042503 | CASE ASSY - OIL PUMP | 21340A | 18.09.2001 - 03.05.2002 | 1 | |
| 2134042504 | CASE ASSY - OIL PUMP | 21340A | 03.05.2002 - 02.05.2007 | 1 | |
| 1140308906K | BOLT | 11403A | 01.09.2006 - 01.01.2007 | 1 | |
| 1140308751 | BOLT | 1140FU | 01.09.1999 - 02.05.2007 | 1 | |
| 1140308656K | BOLT | 1140FS | 01.09.2006 - 01.01.2007 | 1 | |
| 1140308653 | BOLT | 1140FS | 01.09.1999 - 03.07.2001 | 1 | |
| K995641800 | PACKING | K41800 | 03.10.2003 - 01.01.2007 | 1 | |
| 1140308901 | BOLT | 1140FW | 01.09.1999 - 02.05.2007 | 2 |
FRONT CASE; 02/02
| Number | Name | Code | Date_range | Remarks | Qty Required |
|---|---|---|---|---|---|
| 1140308753 | BOLT | 1140GB | 01.09.1999 - 01.01.2007 | 1 | |
| 2151311000 | GASKET - OIL PLUG | 21513 | 01.09.1999 - 02.05.2007 | 1 | |
| 2134042503 | CASE ASSY - OIL PUMP | 21340A | 18.09.2001 - 03.05.2002 | 1 | |
| 2134042504 | CASE ASSY - OIL PUMP | 21340A | 03.05.2002 - 02.05.2007 | 1 | |
| 2134042506 | CASE ASSY - OIL PUMP | 21340A | 03.10.2003 - 01.01.2007 | 1 | |
| 2139032000 | O-RING | 21390 | 01.09.1999 - 03.07.2001 | 1 | |
| 2139038000 | O-RING | 21390 | 02.04.2002 - 01.01.2007 | 1 | |
| 1140308756K | BOLT - FLANGE | 1011AC | 01.01.2007 - 02.05.2007 | 1 | |
| 2139142000 | PLUG - CAP | 21391 | 23.02.2006 - 01.01.2007 | 1 | |
| 2141142000 | GASKET - FRONT CASE, UPPER | 21411C | 01.09.1999 - 17.08.2000 | 1 | |
| 2141142060 | GASKET - FRONT CASE, UPPER | 21411C | 17.08.2000 - 03.07.2001 | 1 | |
| 2141142061 | GASKET - FRONT CASE, UPPER | 21411C | 02.06.2003 - 01.01.2007 | 1 | |
| 2141242000 | GASKET - FRONT CASE, LOWER | 21412A | 01.09.1999 - 17.08.2000 | 1 | |
| 2141242060 | GASKET - FRONT CASE, LOWER | 21412A | 17.08.2000 - 03.07.2001 | 1 | |
| 2141242061 | GASKET - FRONT CASE, LOWER | 21412A | 03.06.2003 - 01.01.2007 | 1 | |
| 2334742500 | SLEEVE | 21726D | 01.09.1999 - 02.05.2007 | 1 | |
| 2133042000 | BRACKET - FRONT CASE SUPPORT | 21330C | 01.09.1999 - 01.01.2007 | 1 | |
| 2334242500 | GEAR - BALANCER SHAFT DRIVE | 23344 | 18.09.2001 - 01.01.2007 | 1 | |
| 2334542000 | GEAR - BALANCER SHAFT DRIVEN | 23345 | 01.09.1999 - 01.01.2007 | 1 | |
| 2614342800 | ROTOR - OIL PUMP INNER | 26112C | 01.09.1999 - 03.07.2001 | 1 | |
| 2614342805 | ROTOR - OIL PUMP INNER | 26112C | 21.09.2003 - 02.05.2007 | 1 | |
| 2614442800 | ROTOR - OIL PUMP OUTER | 26113C | 01.09.1999 - 03.07.2001 | 1 | |
| 2614442804 | ROTOR - OIL PUMP OUTER | 26113C | 03.05.2002 - 21.09.2003 | 1 | |
| 2614442805 | ROTOR - OIL PUMP OUTER | 26113C | 21.09.2003 - 02.05.2007 | 1 | |
| 2612221000 | PLUNGER - RELIEF | 26122 | 01.09.1999 - 03.07.2001 | 1 | |
| 2612242510 | PLUNGER - RELIEF | 26122 | 03.10.2003 - 01.01.2007 | 1 | |
| 2134542000 | SPRING - RELIEF | 26123 | 03.10.2003 - 01.01.2007 | 1 | |
| 2612321000 | SPRING - RELIEF | 26123 | 01.09.1999 - 03.07.2001 | 1 | |
| 2612411010 | PLUG | 26124 | 01.09.1999 - 03.07.2001 | 1 | |
| 261244A100 | PLUG | 26124 | 23.02.2006 - 01.01.2007 | 1 | |
| 2614842800 | SCREW - MACHINE | 26148 | 01.09.1999 - 01.01.2007 | 6 | |
| 2134042501 | CASE ASSY - OIL PUMP | 21340A | 01.09.1999 - 03.07.2001 | 1 | |
| 2139132020 | PLUG - CAP | 21391 | 01.09.1999 - 03.07.2001 | 1 | |
| 2132142031 | SEAL - OIL | 21321B | 01.09.1999 - 01.01.2007 | 1 | |
| 1140308901 | BOLT | 1140FW | 01.09.1999 - 02.05.2007 | 2 | |
| 1123308163 | BOLT | 1123GT | 08.08.2001 - 01.01.2007 | 1 | |
| 1123308166K | BOLT | 1123GT | 14.12.2006 - 02.05.2007 | 1 | |
| 1140308906K | BOLT | 11403A | 01.09.2006 - 01.01.2007 | 1 | |
| 1140308163 | BOLT | 1140FD | 01.09.1999 - 02.05.2007 | NEW A/T | 1 |
| 1140308253 | BOLT | 1140FH | 01.09.1999 - 03.07.2001 | FLANGE | 2 |
| 1140308353 | BOLT | 1140FH | 01.09.1999 - 03.07.2001 | 4 | |
| 1140308356K | BOLT | 1140FH | 01.09.2006 - 01.01.2007 | 4 | |
| 1140308351 | BOLT | 1140FK | 03.10.2003 - 01.01.2007 | 3 | |
| 1140308551 | BOLT | 1140FR | 01.09.1999 - 03.07.2001 | 3 | |
| 1140308553 | BOLT | 1140FR | 01.09.1999 - 03.07.2001 | 3 | |
| 1140308556K | BOLT | 1140FR | 01.09.2006 - 01.01.2007 | 3 | |
| 1140308653 | BOLT | 1140FS | 01.09.1999 - 03.07.2001 | 1 | |
| 2132142021 | SEAL - OIL | 21321A | 01.09.1999 - 01.01.2007 | 1 | |
| 1140308751 | BOLT | 1140FU | 01.09.1999 - 02.05.2007 | 1 | |
| 1140308656K | BOLT | 1140FS | 01.09.2006 - 01.01.2007 | 1 | |
| K995641800 | PACKING | K41800 | 03.10.2003 - 01.01.2007 | 1 | |
| 2131042501 | CASE ASSY - FRONT | 21310B | 01.09.1999 - 03.07.2001 | 1 | |
| 1151308305 | STUD | 1151CE | 01.09.1999 - 03.07.2001 | 2 | |
| 2132142011 | SEAL - OIL | 21321 | 01.09.1999 - 01.01.2007 | 1 | |
| 1151308306K | STUD | 1151CE | 01.01.2007 - 02.05.2007 | 2 | |
| 1151308203 | STUD | 1151CF | 28.08.2006 - 01.01.2007 | 2 | |
| 2614242800 | COVER - OIL PUMP | 21313 | 11.10.1999 - 01.01.2007 | 1 | |
| 2131042510 | CASE ASSY - FRONT | 21310B | 01.01.2007 - 02.05.2007 | 1 | |
| 1430306140 | PIN - DOWEL | 1430JJ | 01.09.1999 - 01.01.2007 | 2 | |
| 2632042116 | BRACKET ASSY - OIL FILTER | 21394 | 03.11.2003 - 02.05.2007 | 1 | |
| 2632042115 | BRACKET ASSY - OIL FILTER | 21394 | 12.03.2001 - 03.11.2003 | 1 | |
| 2632042110 | BRACKET ASSY - OIL FILTER | 21394 | 01.09.1999 - 12.03.2001 | 1 | |
| 2632442100 | NIPPLE | 22133 | 01.09.1999 - 02.03.2001 | 1 | |
| 2633542001 | CAP - OIL FILTER BRACKET | 26335 | 22.08.2001 - 01.01.2007 | 1 | |
| 1140306106K | BOLT | 1140FZ | 01.09.2006 - 01.01.2007 | 2 | |
| 1140306103 | BOLT | 1140FZ | 21.10.2002 - 01.09.2006 | 2 | |
| 1123306123 | BOLT - WASHER ASSY | 1123GF | 01.09.1999 - 13.02.2004 | 2 | |
| 2630042040 | FILTER ASSY - ENGINE OIL | 26300 | 17.08.2000 - 02.05.2007 | 1 | |
| 2632642060 | GASKET - OIL FILTER BRACKET | 21396 | 01.09.1999 - 27.12.2000 | 1 | |
| 2632642070 | GASKET - OIL FILTER BRACKET | 21396 | 27.12.2000 - 02.05.2007 | 1 | |
| 2632542000 | VALVE - OIL COOLER BY-PASS | 26325 | 12.03.2001 - 01.01.2007 | 1 | |
| 2632542011 | VALVE - OIL COOLER BY-PASS | 26325 | 12.03.2001 - 01.01.2007 | 1 | |
| 1571717121 | PLUG - TAPER | 1571TC | 03.10.2003 - 01.01.2007 | 1 | |
| 1571713111 | PLUG - TAPER | 1571TB | 01.09.1999 - 02.05.2007 | 1 | |
| 9475021030 | SWITCH ASSY - OIL PRESSURE | 94750 | 01.09.1999 - 12.03.2001 | 1 | |
| 9475037000 | SWITCH ASSY - OIL PRESSURE | 94750 | 03.11.2003 - 01.01.2007 | 1 | |
| 9475042000 | SWITCH ASSY - OIL PRESSURE | 94750 | 12.03.2001 - 03.11.2003 | 1 | |
| 2143142060 | PLATE - CYLINDER BLOCK, REAR | 21431 | 13.02.2004 - 01.01.2007 | 1 | |
| 2143142001 | PLATE - CYLINDER BLOCK, REAR | 21431 | 01.09.1999 - 13.02.2004 | 1 | |
| 1140308256K | BOLT | 1140EB | 14.12.2006 - 02.05.2007 | 1 |
