ENGINE
FUEL TANK; 01/02
| Number | Name | Code | Date_range | Options | Qty Required |
|---|---|---|---|---|---|
| 31120H1030 | ASSIST PUMP ASSY | 31110D | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 2900 CC | 1 |
| 3111522010 | PACKING - FUEL PUMP | 31115 | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 2900 CC | 1 |
| 31124H1040 | HOSE - CHECK VALVE TO 2-WAY VALVE | 31237 | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 3118122000 | CAP ASSY - 2-WAY VALVE | 31181F | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 2900 CC | 1 |
| 1791206039 | HOSE - FUEL | 1791GS | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 2900 CC | 1 |
| 31071H1950 | HOSE - AIR PRESSURE | 31071 | 15.12.2003 - 11.09.2006 | ENGINE CAPACITY: 2900 CC; (2838) EMISSION EC 2000, (3312) FUEL INJ-ELECTRIC TYPE | 1 |
| 3103929000 | SCREW | 31039A | 15.01.2001 - 11.09.2006 | 4 | |
| 3115222200 | COVER - FUEL PUMP PLATE | 31152 | 15.01.2001 - 11.09.2006 | 1 | |
| 31118H1100 | TUBE ASSY - FUEL QUICK CONNECTOR | 31118B | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 3104824000 | PACKING - FUEL FILLER NECK | 31048B | 15.01.2001 - 11.09.2006 | 1 | |
| 31074H1040 | PACKING - FUEL PUMP | 31140B | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 1472013006B | CLIP - HOSE | 1472AV | 15.01.2001 - 11.09.2006 | 2 | |
| 31030H1042 | COMPLETE - FUEL FILLER NECK | 31040A | 26.05.2003 - 11.09.2006 | BODY TYPE: 5 DR WAGON 7; GRADE: MIDDLE GRADE; ENGINE CAPACITY: 3500 CC; (0910) UNLEADED, (2831) EVAP. GAS CONTROL | 1 |
| 31030H1032 | COMPLETE - FUEL FILLER NECK | 31040A | 15.01.2001 - 26.05.2003 | BODY TYPE: 5 DR WAGON 7; GRADE: MIDDLE GRADE; ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 3101024000 | CAP ASSY - FUEL FILLER | 31010 | 15.01.2001 - 26.05.2003 | BODY TYPE: 5 DR WAGON 7; GRADE: MIDDLE GRADE; ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 310103A901 | CAP ASSY - FUEL FILLER | 31010 | 15.12.2003 - 11.09.2006 | BODY TYPE: 5 DR WAGON 7; GRADE: MIDDLE GRADE; ENGINE CAPACITY: 2900 CC; (2838) EMISSION EC 2000, (3312) FUEL INJ-ELECTRIC TYPE | 1 |
| 310103A800 | CAP ASSY - FUEL FILLER | 31010 | 15.01.2001 - 30.04.2001 | BODY TYPE: 5 DR WAGON; GRADE: MIDDLE GRADE; TRANSMISSION: 5 SPEED MT 4WD; (3311) FUEL INJ-MACHINE TYPE | 1 |
| 31020H1000 | PACKING - SHUT-OFF VALVE | 31020 | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 31071H1000 | HOSE - FUEL | 31071A | 15.01.2001 - 11.09.2006 | 1 | |
| 1791208037 | HOSE - FUEL FEED | 1791GH | 15.01.2001 - 01.06.2001 | BODY TYPE: 5 DR WAGON 7; GRADE: MIDDLE GRADE; ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 1791208039 | HOSE - FUEL FEED | 1791GH | 15.01.2001 - 01.06.2001 | BODY TYPE: 5 DR WAGON 7; GRADE: MIDDLE GRADE; ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 1790808037 | HOSE - FUEL | 17908N | 01.06.2001 - 11.09.2006 | ENGINE CAPACITY: 3500 CC | 1 |
| 1799313000 | STRAP | 1799JC | 21.08.2001 - 11.09.2006 | 1 | |
| 31037H1000 | HOSE - FUEL FILLER NECK | 31036 | 15.01.2001 - 11.09.2006 | 1 | |
| 311453B000 | SUPPORT ASSY - FUEL PUMP | 31114E | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 31038H1000 | HOSE - LEVELLING PIPE | 31037 | 15.01.2001 - 11.09.2006 | 1 | |
| 1799322000 | STRAP | 1799JF | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 3500 CC | 1 |
| 31110H1032 | FUEL PUMP & SENDER MODULE ASSY | 31110C | 22.08.2005 - 11.09.2006 | BODY TYPE: 5 DR WAGON; GRADE: MIDDLE GRADE; TRANSMISSION: 5 SPEED MT 4WD; (3311) FUEL INJ-MACHINE TYPE | 1 |
| 31110H1041 | FUEL PUMP & SENDER MODULE ASSY | 31110C | 15.01.2001 - 26.05.2003 | BODY TYPE: 5 DR WAGON 7; GRADE: MIDDLE GRADE; ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 3113736000 | CLIP - FUEL HOSE | 31137 | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 2 |
| 31110H1031 | FUEL PUMP & SENDER MODULE ASSY | 31110C | 15.01.2001 - 30.04.2001 | BODY TYPE: 5 DR WAGON; GRADE: MIDDLE GRADE; TRANSMISSION: 5 SPEED MT 4WD; (3311) FUEL INJ-MACHINE TYPE | 1 |
| 1471150001 | CLAMP - (HOSE) | 1471DC | 15.01.2001 - 11.09.2006 | 2 | |
| 3112343010 | RETAINER - FUEL FILLER CAP | 31123R | 15.01.2001 - 11.09.2006 | 1 | |
| 1472012006B | CLAMP - (HOSE) | 1472AF | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 2900 CC | 2 |
| 3111636000 | HOSE - FUEL PUMP | 31116 | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 31126H1030 | SENDER ASSY - FUEL PUMP | 94460 | 15.01.2001 - 30.04.2001 | BODY TYPE: 5 DR WAGON; GRADE: MIDDLE GRADE; TRANSMISSION: 5 SPEED MT 4WD; (3311) FUEL INJ-MACHINE TYPE | 1 |
| 31126H1000 | SENDER ASSY - FUEL PUMP | 94460 | 15.01.2001 - 26.05.2003 | BODY TYPE: 5 DR WAGON 7; GRADE: MIDDLE GRADE; ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 1471155001 | CLAMP - (HOSE) | 1471EF | 15.01.2001 - 11.09.2006 | 1 | |
| 31050H1000 | VALVE ASSY - FUEL CUT | 31050B | 15.01.2001 - 11.09.2006 | 1 | |
| 3111138050 | PUMP ASSY - FUEL | 31111B | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 31111H1000 | TUBE ASSY - SUCTION | 31340B | 15.01.2001 - 11.09.2006 | 1 | |
| 3103805000 | LABEL - FUEL FILLER DOOR | 31038 | 04.10.2001 - 26.05.2003 | ENGINE CAPACITY: 3500 CC; (0910) UNLEADED, (2831) EVAP. GAS CONTROL | 1 |
| 3103843250 | LABEL - FUEL FILLER DOOR | 31038 | 15.01.2001 - 30.04.2001 | BODY TYPE: 5 DR WAGON; GRADE: MIDDLE GRADE; TRANSMISSION: 5 SPEED MT 4WD; (3311) FUEL INJ-MACHINE TYPE | 1 |
| 31131H1040 | FILTER - FUEL PUMP | 31112 | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 3111737300 | RUBBER MOUNT | 31117B | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 1471156006B | CLAMP - (HOSE) | 1471DG | 15.01.2001 - 11.09.2006 | 1 | |
| 31040H1031 | HOSE - FILLER | 31040 | 15.01.2001 - 11.09.2006 | 1 | |
| 3111237250 | CLIP | 31112D | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 31155H1000 | HOSE - SUCTION REAR | 31155C | 26.05.2003 - 11.09.2006 | 1 | |
| 1130006301 | BOLT | 1130AF | 15.01.2001 - 11.09.2006 | 1 | |
| 1472013008 | CLIP - HOSE | 1472AG | 26.05.2003 - 11.09.2006 | ENGINE CAPACITY: 3500 CC | 2 |
| 3116138500 | CASE - VALVE | 31161B | 26.05.2003 - 11.09.2006 | ENGINE CAPACITY: 3500 CC; (0910) UNLEADED, (2831) EVAP. GAS CONTROL | 1 |
| 3116038500 | VALVE ASSY - FUEL SHUT-OFF | 31160B | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 3115938000 | SPRING | 31159A | 26.05.2003 - 11.09.2006 | ENGINE CAPACITY: 3500 CC; (0910) UNLEADED, (2831) EVAP. GAS CONTROL | 1 |
| 1472018006B | CLIP - HOSE | 1472AM | 15.01.2001 - 11.09.2006 | 2 | |
| 3115322000 | COVER - FUEL CUT-OFF VALVE | 31153B | 15.01.2001 - 11.09.2006 | 1 | |
| 31116H1030 | HOSE - VAPOR | 31186 | 15.01.2001 - 11.09.2006 | 1 | |
| 311532D000 | CAP - THREAD | 31153A | 15.01.2001 - 11.09.2006 | 1 | |
| 1472019006B | CLIP - HOSE | 1472AI | 15.01.2001 - 11.09.2006 | 1 | |
| 1124006251 | BOLT | 1124AB | 15.01.2001 - 11.09.2006 | 1 | |
| 3119422020 | PACKING - CUT VALVE | 31194C | 15.01.2001 - 11.09.2006 | 1 | |
| 31124H1000 | BRACKET - TANK MOUNTING | 31124B | 15.01.2001 - 11.09.2006 | 1 | |
| 31515H1032 | PROTECTOR - FILLER HOSE | 31515E | 15.01.2001 - 11.09.2006 | 1 | |
| 31191H1000 | COVER - FUEL CUT VALVE | 31153 | 15.01.2001 - 11.09.2006 | 1 | |
| 31112H1000 | PLATE ASSY - FUEL SUCTION | 31112K | 15.01.2001 - 30.04.2001 | BODY TYPE: 5 DR WAGON; GRADE: MIDDLE GRADE; TRANSMISSION: 5 SPEED MT 4WD; (3311) FUEL INJ-MACHINE TYPE | 1 |
| 31112H1040 | PLATE ASSY - FUEL SUCTION | 31112K | 15.01.2001 - 26.05.2003 | BODY TYPE: 5 DR WAGON 7; GRADE: MIDDLE GRADE; ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 31190H1000 | VALVE ASSY - 2-WAY & FUEL CUT | 31190B | 15.01.2001 - 11.09.2006 | 1 | |
| 310902D000 | FILTER - PUMP | 31090B | 15.01.2001 - 11.09.2006 | BODY TYPE: 5 DR WAGON 7; GRADE: MIDDLE GRADE; ENGINE CAPACITY: 3500 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 4WD; (0920) LEADED, (2831) EVAP. GAS CONTROL | 1 |
| 310902D900 | FILTER - PUMP | 31090B | 01.02.2005 - 11.09.2006 | BODY TYPE: 5 DR WAGON; GRADE: MIDDLE GRADE; TRANSMISSION: 5 SPEED MT 4WD; (3311) FUEL INJ-MACHINE TYPE | 1 |
| 31103H1000 | PAD - FUEL TANK | 31101A | 11.05.2001 - 11.09.2006 | 1 | |
| 31075H1040 | PACKING - FUEL CHECK VALVE | 31192 | 15.01.2001 - 26.05.2003 | BODY TYPE: 5 DR WAGON 7; GRADE: MIDDLE GRADE; ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 3119229000 | PACKING - FUEL CHECK VALVE | 31192 | 15.01.2001 - 30.04.2001 | BODY TYPE: 5 DR WAGON; GRADE: MIDDLE GRADE; TRANSMISSION: 5 SPEED MT 4WD; (3311) FUEL INJ-MACHINE TYPE | 1 |
| 1125006163 | BOLT | 1125AC | 26.05.2003 - 11.09.2006 | ENGINE CAPACITY: 3500 CC | 3 |
| 1129006121 | BOLT | 1129AC | 15.01.2001 - 11.09.2006 | 3 | |
| 31227H1000 | CLIP - FUEL TANK HOLDER | 31227A | 26.05.2003 - 11.09.2006 | ENGINE CAPACITY: 3500 CC | 2 |
| 31104H1000 | PAD - FUEL TANK | 31101B | 11.05.2001 - 11.09.2006 | 1 | |
| 3110122200 | PAD - FUEL TANK | 31101D | 15.01.2001 - 11.09.2006 | 3 | |
| 1472010006B | CLIP - HOSE | 1472AD | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 2 |
| 31060H1000 | STUD | 31061 | 15.01.2001 - 11.09.2006 | 1 | |
| 31150H1031 | TANK ASSY - FUEL | 31150 | 15.01.2001 - 30.04.2001 | BODY TYPE: 5 DR WAGON; GRADE: MIDDLE GRADE; TRANSMISSION: 5 SPEED MT 4WD; (3311) FUEL INJ-MACHINE TYPE | 1 |
| 31150H1041 | TANK ASSY - FUEL | 31150 | 15.01.2001 - 26.05.2003 | BODY TYPE: 5 DR WAGON 7; GRADE: MIDDLE GRADE; ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 31073H1000 | HOSE - VAPOR | 31188 | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 31226H1032 | PROTECTOR - FUEL TANK | 31223 | 15.01.2001 - 11.09.2006 | 1 | |
| 1791006025 | HOSE - VAPOR | 1791AM | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 31102H1000 | PAD - FUEL TANK | 31102P | 11.05.2001 - 11.09.2006 | 1 | |
| 312674B000 | PAD | 31267A | 15.01.2001 - 11.09.2006 | 3 | |
| 5465928000 | NUT | 54659 | 15.01.2001 - 11.09.2006 | 4 | |
| 1311006001 | NUT | 1311BA | 15.01.2001 - 11.09.2006 | 1 |
FUEL TANK; 02/02
| Number | Name | Code | Date_range | Options | Qty Required |
|---|---|---|---|---|---|
| 311453B000 | SUPPORT ASSY - FUEL PUMP | 31114E | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 3113736000 | CLIP - FUEL HOSE | 31137 | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 2 |
| 3111138050 | PUMP ASSY - FUEL | 31111B | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 31131H1040 | FILTER - FUEL PUMP | 31112 | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 31020H1000 | PACKING - SHUT-OFF VALVE | 31020 | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 1799322000 | STRAP | 1799JF | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 3500 CC | 1 |
| 1791006025 | HOSE - VAPOR | 1791AM | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 3111237250 | CLIP | 31112D | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 1799313000 | STRAP | 1799JC | 21.08.2001 - 11.09.2006 | 1 | |
| 31118H1100 | TUBE ASSY - FUEL QUICK CONNECTOR | 31118B | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 3111737300 | RUBBER MOUNT | 31117B | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 3111636000 | HOSE - FUEL PUMP | 31116 | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 31073H1000 | HOSE - VAPOR | 31188 | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 31074H1040 | PACKING - FUEL PUMP | 31140B | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 3103929000 | SCREW | 31039A | 15.01.2001 - 11.09.2006 | 4 | |
| 3115222200 | COVER - FUEL PUMP PLATE | 31152 | 15.01.2001 - 11.09.2006 | 1 | |
| 3104824000 | PACKING - FUEL FILLER NECK | 31048B | 15.01.2001 - 11.09.2006 | 1 | |
| 3111522010 | PACKING - FUEL PUMP | 31115 | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 2900 CC | 1 |
| 1791206039 | HOSE - FUEL | 1791GS | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 2900 CC | 1 |
| 31030H1032 | COMPLETE - FUEL FILLER NECK | 31040A | 15.01.2001 - 26.05.2003 | BODY TYPE: 5 DR WAGON 7; GRADE: MIDDLE GRADE; ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 31030H1042 | COMPLETE - FUEL FILLER NECK | 31040A | 26.05.2003 - 11.09.2006 | BODY TYPE: 5 DR WAGON 7; GRADE: MIDDLE GRADE; ENGINE CAPACITY: 3500 CC; (0910) UNLEADED, (2831) EVAP. GAS CONTROL | 1 |
| 1472010006B | CLIP - HOSE | 1472AD | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 2 |
| 1472013006B | CLIP - HOSE | 1472AV | 15.01.2001 - 11.09.2006 | 2 | |
| 3101024000 | CAP ASSY - FUEL FILLER | 31010 | 15.01.2001 - 26.05.2003 | BODY TYPE: 5 DR WAGON 7; GRADE: MIDDLE GRADE; ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 310103A800 | CAP ASSY - FUEL FILLER | 31010 | 15.01.2001 - 30.04.2001 | BODY TYPE: 5 DR WAGON; GRADE: MIDDLE GRADE; TRANSMISSION: 5 SPEED MT 4WD; (3311) FUEL INJ-MACHINE TYPE | 1 |
| 310103A901 | CAP ASSY - FUEL FILLER | 31010 | 15.12.2003 - 11.09.2006 | BODY TYPE: 5 DR WAGON 7; GRADE: MIDDLE GRADE; ENGINE CAPACITY: 2900 CC; (2838) EMISSION EC 2000, (3312) FUEL INJ-ELECTRIC TYPE | 1 |
| 3112343010 | RETAINER - FUEL FILLER CAP | 31123R | 15.01.2001 - 11.09.2006 | 1 | |
| 1790808037 | HOSE - FUEL | 17908N | 01.06.2001 - 11.09.2006 | ENGINE CAPACITY: 3500 CC | 1 |
| 1791208037 | HOSE - FUEL FEED | 1791GH | 15.01.2001 - 01.06.2001 | BODY TYPE: 5 DR WAGON 7; GRADE: MIDDLE GRADE; ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 1791208039 | HOSE - FUEL FEED | 1791GH | 15.01.2001 - 01.06.2001 | BODY TYPE: 5 DR WAGON 7; GRADE: MIDDLE GRADE; ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 31071H1000 | HOSE - FUEL | 31071A | 15.01.2001 - 11.09.2006 | 1 | |
| 31037H1000 | HOSE - FUEL FILLER NECK | 31036 | 15.01.2001 - 11.09.2006 | 1 | |
| 31120H1030 | ASSIST PUMP ASSY | 31110D | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 2900 CC | 1 |
| 31038H1000 | HOSE - LEVELLING PIPE | 31037 | 15.01.2001 - 11.09.2006 | 1 | |
| 31110H1041 | FUEL PUMP & SENDER MODULE ASSY | 31110C | 15.01.2001 - 26.05.2003 | BODY TYPE: 5 DR WAGON 7; GRADE: MIDDLE GRADE; ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 31071H1950 | HOSE - AIR PRESSURE | 31071 | 15.12.2003 - 11.09.2006 | ENGINE CAPACITY: 2900 CC; (2838) EMISSION EC 2000, (3312) FUEL INJ-ELECTRIC TYPE | 1 |
| 31110H1032 | FUEL PUMP & SENDER MODULE ASSY | 31110C | 22.08.2005 - 11.09.2006 | BODY TYPE: 5 DR WAGON; GRADE: MIDDLE GRADE; TRANSMISSION: 5 SPEED MT 4WD; (3311) FUEL INJ-MACHINE TYPE | 1 |
| 31110H1031 | FUEL PUMP & SENDER MODULE ASSY | 31110C | 15.01.2001 - 30.04.2001 | BODY TYPE: 5 DR WAGON; GRADE: MIDDLE GRADE; TRANSMISSION: 5 SPEED MT 4WD; (3311) FUEL INJ-MACHINE TYPE | 1 |
| 31124H1040 | HOSE - CHECK VALVE TO 2-WAY VALVE | 31237 | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 1471150001 | CLAMP - (HOSE) | 1471DC | 15.01.2001 - 11.09.2006 | 2 | |
| 1472012006B | CLAMP - (HOSE) | 1472AF | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 2900 CC | 2 |
| 31050H1000 | VALVE ASSY - FUEL CUT | 31050B | 15.01.2001 - 11.09.2006 | 1 | |
| 31111H1000 | TUBE ASSY - SUCTION | 31340B | 15.01.2001 - 11.09.2006 | 1 | |
| 1471155001 | CLAMP - (HOSE) | 1471EF | 15.01.2001 - 11.09.2006 | 1 | |
| 31126H1030 | SENDER ASSY - FUEL PUMP | 94460 | 15.01.2001 - 30.04.2001 | BODY TYPE: 5 DR WAGON; GRADE: MIDDLE GRADE; TRANSMISSION: 5 SPEED MT 4WD; (3311) FUEL INJ-MACHINE TYPE | 1 |
| 31126H1000 | SENDER ASSY - FUEL PUMP | 94460 | 15.01.2001 - 26.05.2003 | BODY TYPE: 5 DR WAGON 7; GRADE: MIDDLE GRADE; ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 3103843250 | LABEL - FUEL FILLER DOOR | 31038 | 15.01.2001 - 30.04.2001 | BODY TYPE: 5 DR WAGON; GRADE: MIDDLE GRADE; TRANSMISSION: 5 SPEED MT 4WD; (3311) FUEL INJ-MACHINE TYPE | 1 |
| 3103805000 | LABEL - FUEL FILLER DOOR | 31038 | 04.10.2001 - 26.05.2003 | ENGINE CAPACITY: 3500 CC; (0910) UNLEADED, (2831) EVAP. GAS CONTROL | 1 |
| 31155H1000 | HOSE - SUCTION REAR | 31155C | 26.05.2003 - 11.09.2006 | 1 | |
| 1471156006B | CLAMP - (HOSE) | 1471DG | 15.01.2001 - 11.09.2006 | 1 | |
| 31040H1031 | HOSE - FILLER | 31040 | 15.01.2001 - 11.09.2006 | 1 | |
| 1472013008 | CLIP - HOSE | 1472AG | 26.05.2003 - 11.09.2006 | ENGINE CAPACITY: 3500 CC | 2 |
| 1130006301 | BOLT | 1130AF | 15.01.2001 - 11.09.2006 | 1 | |
| 3116138500 | CASE - VALVE | 31161B | 26.05.2003 - 11.09.2006 | ENGINE CAPACITY: 3500 CC; (0910) UNLEADED, (2831) EVAP. GAS CONTROL | 1 |
| 3116038500 | VALVE ASSY - FUEL SHUT-OFF | 31160B | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 1472018006B | CLIP - HOSE | 1472AM | 15.01.2001 - 11.09.2006 | 2 | |
| 3115938000 | SPRING | 31159A | 26.05.2003 - 11.09.2006 | ENGINE CAPACITY: 3500 CC; (0910) UNLEADED, (2831) EVAP. GAS CONTROL | 1 |
| 3115322000 | COVER - FUEL CUT-OFF VALVE | 31153B | 15.01.2001 - 11.09.2006 | 1 | |
| 31116H1030 | HOSE - VAPOR | 31186 | 15.01.2001 - 11.09.2006 | 1 | |
| 311532D000 | CAP - THREAD | 31153A | 15.01.2001 - 11.09.2006 | 1 | |
| 1472019006B | CLIP - HOSE | 1472AI | 15.01.2001 - 11.09.2006 | 1 | |
| 31515H1032 | PROTECTOR - FILLER HOSE | 31515E | 15.01.2001 - 11.09.2006 | 1 | |
| 1124006251 | BOLT | 1124AB | 15.01.2001 - 11.09.2006 | 1 | |
| 31124H1000 | BRACKET - TANK MOUNTING | 31124B | 15.01.2001 - 11.09.2006 | 1 | |
| 3119422020 | PACKING - CUT VALVE | 31194C | 15.01.2001 - 11.09.2006 | 1 | |
| 31112H1040 | PLATE ASSY - FUEL SUCTION | 31112K | 15.01.2001 - 26.05.2003 | BODY TYPE: 5 DR WAGON 7; GRADE: MIDDLE GRADE; ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 31112H1000 | PLATE ASSY - FUEL SUCTION | 31112K | 15.01.2001 - 30.04.2001 | BODY TYPE: 5 DR WAGON; GRADE: MIDDLE GRADE; TRANSMISSION: 5 SPEED MT 4WD; (3311) FUEL INJ-MACHINE TYPE | 1 |
| 31191H1000 | COVER - FUEL CUT VALVE | 31153 | 15.01.2001 - 11.09.2006 | 1 | |
| 1125006163 | BOLT | 1125AC | 26.05.2003 - 11.09.2006 | ENGINE CAPACITY: 3500 CC | 3 |
| 1129006121 | BOLT | 1129AC | 15.01.2001 - 11.09.2006 | 3 | |
| 31190H1000 | VALVE ASSY - 2-WAY & FUEL CUT | 31190B | 15.01.2001 - 11.09.2006 | 1 | |
| 310902D000 | FILTER - PUMP | 31090B | 15.01.2001 - 11.09.2006 | BODY TYPE: 5 DR WAGON 7; GRADE: MIDDLE GRADE; ENGINE CAPACITY: 3500 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 4WD; (0920) LEADED, (2831) EVAP. GAS CONTROL | 1 |
| 310902D900 | FILTER - PUMP | 31090B | 01.02.2005 - 11.09.2006 | BODY TYPE: 5 DR WAGON; GRADE: MIDDLE GRADE; TRANSMISSION: 5 SPEED MT 4WD; (3311) FUEL INJ-MACHINE TYPE | 1 |
| 31103H1000 | PAD - FUEL TANK | 31101A | 11.05.2001 - 11.09.2006 | 1 | |
| 3119229000 | PACKING - FUEL CHECK VALVE | 31192 | 15.01.2001 - 30.04.2001 | BODY TYPE: 5 DR WAGON; GRADE: MIDDLE GRADE; TRANSMISSION: 5 SPEED MT 4WD; (3311) FUEL INJ-MACHINE TYPE | 1 |
| 31075H1040 | PACKING - FUEL CHECK VALVE | 31192 | 15.01.2001 - 26.05.2003 | BODY TYPE: 5 DR WAGON 7; GRADE: MIDDLE GRADE; ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 31227H1000 | CLIP - FUEL TANK HOLDER | 31227A | 26.05.2003 - 11.09.2006 | ENGINE CAPACITY: 3500 CC | 2 |
| 31060H1000 | STUD | 31061 | 15.01.2001 - 11.09.2006 | 1 | |
| 31104H1000 | PAD - FUEL TANK | 31101B | 11.05.2001 - 11.09.2006 | 1 | |
| 3110122200 | PAD - FUEL TANK | 31101D | 15.01.2001 - 11.09.2006 | 3 | |
| 3118122000 | CAP ASSY - 2-WAY VALVE | 31181F | 15.01.2001 - 11.09.2006 | ENGINE CAPACITY: 2900 CC | 1 |
| 31150H1041 | TANK ASSY - FUEL | 31150 | 15.01.2001 - 26.05.2003 | BODY TYPE: 5 DR WAGON 7; GRADE: MIDDLE GRADE; ENGINE CAPACITY: 3500 CC; (2831) EVAP. GAS CONTROL | 1 |
| 31150H1031 | TANK ASSY - FUEL | 31150 | 15.01.2001 - 30.04.2001 | BODY TYPE: 5 DR WAGON; GRADE: MIDDLE GRADE; TRANSMISSION: 5 SPEED MT 4WD; (3311) FUEL INJ-MACHINE TYPE | 1 |
| 31226H1032 | PROTECTOR - FUEL TANK | 31223 | 15.01.2001 - 11.09.2006 | 1 | |
| 31102H1000 | PAD - FUEL TANK | 31102P | 11.05.2001 - 11.09.2006 | 1 | |
| 312674B000 | PAD | 31267A | 15.01.2001 - 11.09.2006 | 3 | |
| 5465928000 | NUT | 54659 | 15.01.2001 - 11.09.2006 | 4 | |
| 1311006001 | NUT | 1311BA | 15.01.2001 - 11.09.2006 | 1 |
