ENGINE
FRONT CASE; 01/04
| Number | Name | Code | Date_range | Options | Remarks | Qty Required |
|---|---|---|---|---|---|---|
| 2141138203 | GASKET - OIL PUMP | 21411A | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2133238200 | COVER - TIMING BELT, REAR UPPER, LH | 21332 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 213604A000 | COVER ASSY - TIMING CHAIN UPPER FRONT | 21360D | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 2136038403 | COVER ASSY - TIMING BELT UPPER | 21360A | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2135838003 | GASKET - TIMING BELT COVER | 21358 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2135438401 | GASKET - TIMING BELT COVER LOWER | 21354C | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2135338001 | GASKET - TIMING BELT COVER | 21353F | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2135238001 | GASKET - TIMING BELT COVER | 21352C | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 213504A000 | COVER ASSY - TIMING CHAIN LOWER FRONT | 21350D | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 2135038402 | COVER ASSY - TIMING BELT LOWER | 21350 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2133042000 | BRACKET - FRONT CASE SUPPORT | 21330C | 01.11.2002 - 31.12.2006 | BODY TYPE: WGN SHORT 7; GRADE: HIGH GSL; (3311) FUEL INJ-MACHINE TYPE | 1 | |
| 2136338201 | GASKET - TIMING BELT COVER | 21363F | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 233134A000 | GEAR - BALANCER SHAFT DRIVE | 23342 | 01.11.2002 - 29.11.2005 | ENGINE CAPACITY: D4CB(A ENG); FUEL TYPE: T/C INTER COOLER; TRANSMISSION: 5 SPEED MT 2WD | 1 | |
| 233144A000 | CHAIN SPROCKET - BALANCE SHAFT, LH | 23314 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 233134A400 | GEAR - BALANCER SHAFT DRIVE | 23342 | 29.11.2005 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 2113332000 | PLUG - TAPER | 21133 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 2 | |
| 1571710083 | PLUG - TAPER | 1571TA | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 3 | |
| 1571613111 | PLUG - TAPER | 1571RB | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 2 | |
| 1433108090 | BUSH | 1433CA | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 4 | |
| 1339610003 | NUT | 1339GB | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 1338606003 | NUT | 1338BA | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 2136438002 | GASKET - TIMING BELT COVER UPPER | 21363B | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2136438401 | GASKET 3 - TIMING BELT COVER UPPER | 21365E | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 1151306143 | STUD | 1151CH | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 2335132000 | BOLT | 23351 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 261254A010 | CHAIN SPROCKET - OIL PUMP | 26125B | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 2611338010 | GEAR - OIL PUMP DRIVEN | 26113B | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2611238011 | GEAR - OIL PUMP DRIVE | 26112B | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 261004A010 | PUMP ASSY - OIL | 26100 | 03.10.2004 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 261004A000 | PUMP ASSY - OIL | 26100 | 01.11.2002 - 03.10.2004 | ENGINE CAPACITY: D4CB(A ENG); FUEL TYPE: T/C INTER COOLER; TRANSMISSION: 5 SPEED MT 2WD | 1 | |
| 2512438001 | GASKET - WATER PUMP | 25124 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2435232001 | NUT | 24352 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 2414135500 | PIN - DOWEL | 24141 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 2 | |
| 2339147280 | WASHER | 23391 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 2139538060 | BRACKET - OIL FILTER | 21395 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 213704A000 | COVER ASSY - TIMING CHAIN LOWER UNDER | 21370D | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 213804A005 | COVER ASSY - TIMING CHAIN UPPER UNDER | 21380D | 22.09.2005 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 213804A003 | COVER ASSY - TIMING CHAIN UPPER UNDER | 21380D | 26.07.2005 - 22.09.2005 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 213804A002 | COVER ASSY - TIMING CHAIN UPPER UNDER | 21380D | 04.02.2005 - 26.07.2005 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 213804A001 | COVER ASSY - TIMING CHAIN UPPER UNDER | 21380D | 10.11.2002 - 04.02.2005 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 213804A000 | COVER ASSY - TIMING CHAIN UPPER UNDER | 21380D | 01.11.2002 - 10.11.2002 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 2136038403 | COVER ASSY - TIMING CHAIN UPPER UNDER | 21380D | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 2WD | 1 | |
| 2137538201 | COVER - TIMING BELT, REAR, RH | 21375 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2137238004 | GASKET - TIMING BELT COVER | 21372B | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2137138014 | GASKET - TIMING BELT COVER | 21371A | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 1220306251 | SCREW - MACHINE | 1220FS | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 4 | |
| 2133038014 | COVER ASSY - TIMING BELT REAR LOWER, LH | 21330B | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 1140308163 | BOLT | 1140FD | 01.11.2002 - 31.12.2006 | BODY TYPE: WGN SHORT 7; GRADE: HIGH GSL; (3311) FUEL INJ-MACHINE TYPE | NEW A/T | 1 |
| 1140308303 | BOLT | 1140FJ | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 3 | |
| 1140306101 | BOLT | 1140FZ | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 2WD | FLANGE | 4 |
| 1140308703 | BOLT | 1140FT | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 6 | |
| 1140306283 | BOLT | 1140ES | 01.11.2002 - 08.04.2005 | ENGINE CAPACITY: 2400 CC | FLANGE | 1 |
| 1140308503 | BOLT | 1140FP | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 6 | |
| 1140308456K | BOLT | 1140FN | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 1140308403 | BOLT | 1140FM | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 5 | |
| 1140308383 | BOLT | 1140FL | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | FLANGE | 3 |
| 1140308223 | BOLT | 1140FG | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | FLANGE | 12 |
| 1140308323 | BOLT - FLANGE | 1140GA | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 2 | |
| 1129308183 | BOLT | 1129EI | 01.11.2002 - 03.03.2003 | ENGINE CAPACITY: D4CB(A ENG) | 5 | |
| 2142133114 | SEAL - OIL | 21421 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2141038200 | GASKET - FRONT CASE | 21411B | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 213674A000 | BOLT | 1129EI | 03.03.2003 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 5 | |
| 1130206253 | BOLT | 1130DD | 01.11.2002 - 08.04.2005 | ENGINE CAPACITY: 2400 CC | 11 | |
| 1130206256K | BOLT | 1130DD | 08.04.2005 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 11 | |
| 1140306201 | BOLT - FLANGE | 11403C | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 1140306286K | BOLT | 1140ES | 08.04.2005 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 1140308803 | BOLT | 1140FZ | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 4 | |
| 1140306223 | BOLT | 1140EP | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 9 | |
| 2142133144 | SEAL - OIL | 21421B | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2142133134 | SEAL - OIL | 21421A | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 1140410603 | BOLT - ..- FLANGE -.. | 1140HL | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | FLANGE 10*25 | 1 |
| 1140410353 | BOLT | 1140HF | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 1140306143 | BOLT | 1140GG | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 8 | |
| L2630042040 | FILTER ASSY - ENGINE OIL | 26300 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| 2630042040 | FILTER ASSY - ENGINE OIL | 26300 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| 2630035500 | FILTER ASSY - ENGINE OIL | 26300 | 01.11.2002 - 15.07.2003 | ENGINE CAPACITY: 2400 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 2WD | 1 | |
| S2630042040 | FILTER ASSY - ENGINE OIL | 26300 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI) | [PRODUCT LINE 2: Not to be used for warranty repair] | 1 |
| 2630035501 | FILTER ASSY - ENGINE OIL | 26300 | 15.07.2003 - 31.12.2006 | ENGINE CAPACITY: 2400 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 2WD | 1 | |
| L2630035500 | FILTER ASSY - ENGINE OIL | 26300 | 01.11.2002 - 15.07.2003 | ENGINE CAPACITY: 2400 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 2WD | 1 | |
| 1540710201 | BOLT - EYE JOINT | 1540TA | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| 2633542001 | CAP - OIL FILTER BRACKET | 26335 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| 2632042905 | BRACKET ASSY - OIL FILTER | 21394 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| 2632542000 | VALVE - OIL COOLER BY-PASS | 26325 | 01.11.2002 - 31.12.2006 | BODY TYPE: WGN SHORT 7; GRADE: TOP GRADE; ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| 2632542011 | VALVE - OIL COOLER BY-PASS | 26325 | 01.11.2002 - 31.12.2006 | BODY TYPE: WGN SHORT 7; GRADE: TOP GRADE; ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| 1571717121 | PLUG - TAPER | 1571TC | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 1571713111 | PLUG - TAPER | 1571TB | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| 1123308163 | BOLT | 1123GT | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2131542004 | BRACKET - TOP SHIELD | 21315A | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2141142060 | GASKET - FRONT CASE, UPPER | 21411C | 01.11.2002 - 02.06.2003 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2141142061 | GASKET - FRONT CASE, UPPER | 21411C | 02.06.2003 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2632642070 | GASKET - OIL FILTER BRACKET | 21396 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| 2139638061 | GASKET - OIL FILTER BRACKET | 21396 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 2WD | 1 | |
| 1151308305 | STUD | 1151CE | 01.11.2002 - 31.12.2006 | BODY TYPE: WGN SHORT 7; GRADE: HIGH GSL; (3311) FUEL INJ-MACHINE TYPE | 2 | |
| 243824A000 | STUD | 1151CE | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 2131038062 | CASE ASSY - FRONT | 21310B | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2131042501 | CASE ASSY - FRONT | 21310B | 01.11.2002 - 31.12.2006 | BODY TYPE: WGN SHORT 7; GRADE: HIGH GSL; (3311) FUEL INJ-MACHINE TYPE | 1 | |
| 9475042000 | SWITCH ASSY - OIL PRESSURE | 94750 | 01.11.2002 - 03.11.2003 | ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| 9475037000 | SWITCH ASSY - OIL PRESSURE | 94750 | 03.11.2003 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2132047280 | SEAL - OIL | 21321 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | T=8MM | 1 |
| 2132142011 | SEAL - OIL | 21321 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2141242060 | GASKET - FRONT CASE, LOWER | 21412A | 01.11.2002 - 03.06.2003 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2141242061 | GASKET - FRONT CASE, LOWER | 21412A | 03.06.2003 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2334742500 | SLEEVE | 21726D | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 1140308353 | BOLT | 1140FH | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 4 | |
| 1140308903 | BOLT | 1140FW | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 2 | |
| 2614242800 | COVER - OIL PUMP | 21313 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2131338010 | COVER - OIL PUMP | 21313 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 2WD | 1 | |
| 1430306140 | PIN - DOWEL | 1430JC | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 2 | |
| 2614842800 | SCREW - MACHINE | 26148 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 6 | |
| 2614342804 | ROTOR - OIL PUMP INNER | 26112C | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| K995641800 | PACKING | K41800 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 1140308201 | BOLT | 1140FF | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | FLANGE | 5 |
| 1140308226K | BOLT | 1140FF | 01.09.2006 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| 2139038000 | O-RING | 21390 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 2WD | 1 | |
| 2139032000 | O-RING | 21390 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2334542000 | GEAR - BALANCER SHAFT DRIVEN | 23345 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 1140308553 | BOLT | 1140FR | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 3 | |
| 1140308551 | BOLT | 1140FR | 01.11.2002 - 31.12.2006 | BODY TYPE: WGN SHORT 7; GRADE: HIGH GSL; (3311) FUEL INJ-MACHINE TYPE | 3 | |
| 1140308453 | BOLT | 1140FR | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 2WD | FLANGE | 1 |
| 2614442804 | ROTOR - OIL PUMP OUTER | 26113C | 01.11.2002 - 21.09.2003 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2614442805 | ROTOR - OIL PUMP OUTER | 26113C | 21.09.2003 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 1140308351 | BOLT | 1140FK | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 3 | |
| 1140308653 | BOLT | 1140FS | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 1151308203 | STUD | 1151CF | 28.08.2006 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 2 | |
| 2132142021 | SEAL - OIL | 21321A | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 1140308906K | BOLT | 11403A | 01.09.2006 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 2 | |
| 2139132010 | PLUG - CAP | 21391 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 2WD | 1 | |
| 2139132020 | PLUG - CAP | 21391 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2612242500 | PLUNGER - RELIEF | 26122 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2612221000 | PLUNGER - RELIEF | 26122 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2612321000 | SPRING - RELIEF | 26123 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2132142031 | SEAL - OIL | 21321B | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 1140308256K | BOLT | 1140EB | 14.12.2006 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2151311000 | GASKET - OIL PLUG | 21513 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 1601106000 | BALL - STEEL | 1601DC | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2334242500 | GEAR - BALANCER SHAFT DRIVE | 23344 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2612411010 | PLUG | 26124 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2134042103 | CASE ASSY - OIL PUMP | 21340A | 01.11.2002 - 23.08.2003 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2134042104 | CASE ASSY - OIL PUMP | 21340A | 23.08.2003 - 21.09.2003 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2134042105 | CASE ASSY - OIL PUMP | 21340A | 21.09.2003 - 03.10.2003 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2134042106 | CASE ASSY - OIL PUMP | 21340A | 03.10.2003 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 |
FRONT CASE; 02/04
| Number | Name | Code | Date_range | Options | Remarks | Qty Required |
|---|---|---|---|---|---|---|
| 1123308163 | BOLT | 1123GT | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2137538201 | COVER - TIMING BELT, REAR, RH | 21375 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2141142061 | GASKET - FRONT CASE, UPPER | 21411C | 02.06.2003 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2141142060 | GASKET - FRONT CASE, UPPER | 21411C | 01.11.2002 - 02.06.2003 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2141038200 | GASKET - FRONT CASE | 21411B | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2141138203 | GASKET - OIL PUMP | 21411A | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2632642070 | GASKET - OIL FILTER BRACKET | 21396 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| 2139638061 | GASKET - OIL FILTER BRACKET | 21396 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 2WD | 1 | |
| 2139538060 | BRACKET - OIL FILTER | 21395 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2632042905 | BRACKET ASSY - OIL FILTER | 21394 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| 2139132020 | PLUG - CAP | 21391 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2139132010 | PLUG - CAP | 21391 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 2WD | 1 | |
| 2139038000 | O-RING | 21390 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 2WD | 1 | |
| 2139032000 | O-RING | 21390 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2137238004 | GASKET - TIMING BELT COVER | 21372B | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2141242061 | GASKET - FRONT CASE, LOWER | 21412A | 03.06.2003 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2137138014 | GASKET - TIMING BELT COVER | 21371A | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2136438401 | GASKET 3 - TIMING BELT COVER UPPER | 21365E | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2136338201 | GASKET - TIMING BELT COVER | 21363F | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2136438002 | GASKET - TIMING BELT COVER UPPER | 21363B | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2136038403 | COVER ASSY - TIMING BELT UPPER | 21360A | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2135838003 | GASKET - TIMING BELT COVER | 21358 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2135338001 | GASKET - TIMING BELT COVER | 21353F | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2135238001 | GASKET - TIMING BELT COVER | 21352C | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2135038402 | COVER ASSY - TIMING BELT LOWER | 21350 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2134042106 | CASE ASSY - OIL PUMP | 21340A | 03.10.2003 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2134042105 | CASE ASSY - OIL PUMP | 21340A | 21.09.2003 - 03.10.2003 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2134042104 | CASE ASSY - OIL PUMP | 21340A | 23.08.2003 - 21.09.2003 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2141242060 | GASKET - FRONT CASE, LOWER | 21412A | 01.11.2002 - 03.06.2003 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2142133114 | SEAL - OIL | 21421 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2133238200 | COVER - TIMING BELT, REAR UPPER, LH | 21332 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2612411010 | PLUG | 26124 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 9475042000 | SWITCH ASSY - OIL PRESSURE | 94750 | 01.11.2002 - 03.11.2003 | ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| 9475037000 | SWITCH ASSY - OIL PRESSURE | 94750 | 03.11.2003 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2633542001 | CAP - OIL FILTER BRACKET | 26335 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| 2632542011 | VALVE - OIL COOLER BY-PASS | 26325 | 01.11.2002 - 31.12.2006 | BODY TYPE: WGN SHORT 7; GRADE: TOP GRADE; ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| 2632542000 | VALVE - OIL COOLER BY-PASS | 26325 | 01.11.2002 - 31.12.2006 | BODY TYPE: WGN SHORT 7; GRADE: TOP GRADE; ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| S2630042040 | FILTER ASSY - ENGINE OIL | 26300 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI) | [PRODUCT LINE 2: Not to be used for warranty repair] | 1 |
| L2630042040 | FILTER ASSY - ENGINE OIL | 26300 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| L2630035500 | FILTER ASSY - ENGINE OIL | 26300 | 01.11.2002 - 15.07.2003 | ENGINE CAPACITY: 2400 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 2WD | 1 | |
| 2630042040 | FILTER ASSY - ENGINE OIL | 26300 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| 2630035501 | FILTER ASSY - ENGINE OIL | 26300 | 15.07.2003 - 31.12.2006 | ENGINE CAPACITY: 2400 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 2WD | 1 | |
| 2630035500 | FILTER ASSY - ENGINE OIL | 26300 | 01.11.2002 - 15.07.2003 | ENGINE CAPACITY: 2400 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 2WD | 1 | |
| 2614842800 | SCREW - MACHINE | 26148 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 6 | |
| 2612321000 | SPRING - RELIEF | 26123 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2142133134 | SEAL - OIL | 21421A | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2612242500 | PLUNGER - RELIEF | 26122 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2612221000 | PLUNGER - RELIEF | 26122 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2614442805 | ROTOR - OIL PUMP OUTER | 26113C | 21.09.2003 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2614442804 | ROTOR - OIL PUMP OUTER | 26113C | 01.11.2002 - 21.09.2003 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2614342804 | ROTOR - OIL PUMP INNER | 26112C | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2611238011 | GEAR - OIL PUMP DRIVE | 26112B | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2512438001 | GASKET - WATER PUMP | 25124 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2335132000 | BOLT | 23351 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2334242500 | GEAR - BALANCER SHAFT DRIVE | 23344 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2334742500 | SLEEVE | 21726D | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2151311000 | GASKET - OIL PLUG | 21513 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2142133144 | SEAL - OIL | 21421B | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2134042103 | CASE ASSY - OIL PUMP | 21340A | 01.11.2002 - 23.08.2003 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2135438401 | GASKET - TIMING BELT COVER LOWER | 21354C | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2133042000 | BRACKET - FRONT CASE SUPPORT | 21330C | 01.11.2002 - 31.12.2006 | BODY TYPE: WGN SHORT 7; GRADE: HIGH GSL; (3311) FUEL INJ-MACHINE TYPE | 1 | |
| 1140308351 | BOLT | 1140FK | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 3 | |
| 1151308203 | STUD | 1151CF | 28.08.2006 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 2 | |
| 2133038014 | COVER ASSY - TIMING BELT REAR LOWER, LH | 21330B | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 1140308903 | BOLT | 1140FW | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 2 | |
| 1140308653 | BOLT | 1140FS | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 1140308553 | BOLT | 1140FR | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 3 | |
| 1140308551 | BOLT | 1140FR | 01.11.2002 - 31.12.2006 | BODY TYPE: WGN SHORT 7; GRADE: HIGH GSL; (3311) FUEL INJ-MACHINE TYPE | 3 | |
| 1140308453 | BOLT | 1140FR | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 2WD | FLANGE | 1 |
| 1140308383 | BOLT | 1140FL | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | FLANGE | 3 |
| 1140308353 | BOLT | 1140FH | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 4 | |
| 1540710201 | BOLT - EYE JOINT | 1540TA | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| 1140308163 | BOLT | 1140FD | 01.11.2002 - 31.12.2006 | BODY TYPE: WGN SHORT 7; GRADE: HIGH GSL; (3311) FUEL INJ-MACHINE TYPE | NEW A/T | 1 |
| 1140306286K | BOLT | 1140ES | 08.04.2005 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 1140306283 | BOLT | 1140ES | 01.11.2002 - 08.04.2005 | ENGINE CAPACITY: 2400 CC | FLANGE | 1 |
| 1140308256K | BOLT | 1140EB | 14.12.2006 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 1140306201 | BOLT - FLANGE | 11403C | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 1140308906K | BOLT | 11403A | 01.09.2006 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 2 | |
| 1130206256K | BOLT | 1130DD | 08.04.2005 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 11 | |
| 1130206253 | BOLT | 1130DD | 01.11.2002 - 08.04.2005 | ENGINE CAPACITY: 2400 CC | 11 | |
| 1430306140 | PIN - DOWEL | 1430JC | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 2 | |
| 1140308323 | BOLT - FLANGE | 1140GA | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 2 | |
| K995641800 | PACKING | K41800 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 1571713111 | PLUG - TAPER | 1571TB | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| 2132142031 | SEAL - OIL | 21321B | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2132142021 | SEAL - OIL | 21321A | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2131542004 | BRACKET - TOP SHIELD | 21315A | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2614242800 | COVER - OIL PUMP | 21313 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2131338010 | COVER - OIL PUMP | 21313 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 2WD | 1 | |
| 2131042501 | CASE ASSY - FRONT | 21310B | 01.11.2002 - 31.12.2006 | BODY TYPE: WGN SHORT 7; GRADE: HIGH GSL; (3311) FUEL INJ-MACHINE TYPE | 1 | |
| 2131038062 | CASE ASSY - FRONT | 21310B | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 1601106000 | BALL - STEEL | 1601DC | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 1571717121 | PLUG - TAPER | 1571TC | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2113332000 | PLUG - TAPER | 21133 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 2 | |
| 1571613111 | PLUG - TAPER | 1571RB | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 2 | |
| 213804A000 | COVER ASSY - TIMING CHAIN UPPER UNDER | 21380D | 01.11.2002 - 10.11.2002 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 213804A001 | COVER ASSY - TIMING CHAIN UPPER UNDER | 21380D | 10.11.2002 - 04.02.2005 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 213804A002 | COVER ASSY - TIMING CHAIN UPPER UNDER | 21380D | 04.02.2005 - 26.07.2005 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 213804A003 | COVER ASSY - TIMING CHAIN UPPER UNDER | 21380D | 26.07.2005 - 22.09.2005 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 213804A005 | COVER ASSY - TIMING CHAIN UPPER UNDER | 21380D | 22.09.2005 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 2136038403 | COVER ASSY - TIMING CHAIN UPPER UNDER | 21380D | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 2WD | 1 | |
| 1140306223 | BOLT | 1140EP | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 9 | |
| 2414135500 | PIN - DOWEL | 24141 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 2 | |
| 1140308201 | BOLT | 1140FF | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | FLANGE | 5 |
| 1140308226K | BOLT | 1140FF | 01.09.2006 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| 1571710083 | PLUG - TAPER | 1571TA | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 3 | |
| 1140308403 | BOLT | 1140FM | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 5 | |
| 243824A000 | STUD | 1151CE | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 1151308305 | STUD | 1151CE | 01.11.2002 - 31.12.2006 | BODY TYPE: WGN SHORT 7; GRADE: HIGH GSL; (3311) FUEL INJ-MACHINE TYPE | 2 | |
| 1140306143 | BOLT | 1140GG | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 8 | |
| 1338606003 | NUT | 1338BA | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 213704A000 | COVER ASSY - TIMING CHAIN LOWER UNDER | 21370D | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 1140308456K | BOLT | 1140FN | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 233134A400 | GEAR - BALANCER SHAFT DRIVE | 23342 | 29.11.2005 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 233134A000 | GEAR - BALANCER SHAFT DRIVE | 23342 | 01.11.2002 - 29.11.2005 | ENGINE CAPACITY: D4CB(A ENG); FUEL TYPE: T/C INTER COOLER; TRANSMISSION: 5 SPEED MT 2WD | 1 | |
| 1140308303 | BOLT | 1140FJ | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 3 | |
| 1220306251 | SCREW - MACHINE | 1220FS | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 4 | |
| 213604A000 | COVER ASSY - TIMING CHAIN UPPER FRONT | 21360D | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 213504A000 | COVER ASSY - TIMING CHAIN LOWER FRONT | 21350D | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 1433108090 | BUSH | 1433CA | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 4 | |
| 2334542000 | GEAR - BALANCER SHAFT DRIVEN | 23345 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2132047280 | SEAL - OIL | 21321 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | T=8MM | 1 |
| 1129308183 | BOLT | 1129EI | 01.11.2002 - 03.03.2003 | ENGINE CAPACITY: D4CB(A ENG) | 5 | |
| 2132142011 | SEAL - OIL | 21321 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 213674A000 | BOLT | 1129EI | 03.03.2003 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 5 | |
| 233144A000 | CHAIN SPROCKET - BALANCE SHAFT, LH | 23314 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 1151306143 | STUD | 1151CH | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 2435232001 | NUT | 24352 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 1339610003 | NUT | 1339GB | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 2339147280 | WASHER | 23391 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 1140308703 | BOLT | 1140FT | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 6 | |
| 261004A000 | PUMP ASSY - OIL | 26100 | 01.11.2002 - 03.10.2004 | ENGINE CAPACITY: D4CB(A ENG); FUEL TYPE: T/C INTER COOLER; TRANSMISSION: 5 SPEED MT 2WD | 1 | |
| 261004A010 | PUMP ASSY - OIL | 26100 | 03.10.2004 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 1140306101 | BOLT | 1140FZ | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 2WD | FLANGE | 4 |
| 1140308803 | BOLT | 1140FZ | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 4 | |
| 1140410353 | BOLT | 1140HF | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 1140308503 | BOLT | 1140FP | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 6 | |
| 261254A010 | CHAIN SPROCKET - OIL PUMP | 26125B | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 1140308223 | BOLT | 1140FG | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | FLANGE | 12 |
| 2611338010 | GEAR - OIL PUMP DRIVEN | 26113B | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 1140410603 | BOLT - ..- FLANGE -.. | 1140HL | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | FLANGE 10*25 | 1 |
FRONT CASE; 03/04
| Number | Name | Code | Date_range | Options | Remarks | Qty Required |
|---|---|---|---|---|---|---|
| 1123308163 | BOLT | 1123GT | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2136038403 | COVER ASSY - TIMING BELT UPPER | 21360A | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 213804A001 | COVER ASSY - TIMING CHAIN UPPER UNDER | 21380D | 10.11.2002 - 04.02.2005 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 213804A000 | COVER ASSY - TIMING CHAIN UPPER UNDER | 21380D | 01.11.2002 - 10.11.2002 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 2137538201 | COVER - TIMING BELT, REAR, RH | 21375 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2137238004 | GASKET - TIMING BELT COVER | 21372B | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2137138014 | GASKET - TIMING BELT COVER | 21371A | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 213704A000 | COVER ASSY - TIMING CHAIN LOWER UNDER | 21370D | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 2136438401 | GASKET 3 - TIMING BELT COVER UPPER | 21365E | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2136338201 | GASKET - TIMING BELT COVER | 21363F | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2136438002 | GASKET - TIMING BELT COVER UPPER | 21363B | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 213604A000 | COVER ASSY - TIMING CHAIN UPPER FRONT | 21360D | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 2135838003 | GASKET - TIMING BELT COVER | 21358 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 213804A003 | COVER ASSY - TIMING CHAIN UPPER UNDER | 21380D | 26.07.2005 - 22.09.2005 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 2135438401 | GASKET - TIMING BELT COVER LOWER | 21354C | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 1129308183 | BOLT | 1129EI | 01.11.2002 - 03.03.2003 | ENGINE CAPACITY: D4CB(A ENG) | 5 | |
| 2135238001 | GASKET - TIMING BELT COVER | 21352C | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 213504A000 | COVER ASSY - TIMING CHAIN LOWER FRONT | 21350D | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 2135038402 | COVER ASSY - TIMING BELT LOWER | 21350 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2133238200 | COVER - TIMING BELT, REAR UPPER, LH | 21332 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2133042000 | BRACKET - FRONT CASE SUPPORT | 21330C | 01.11.2002 - 31.12.2006 | BODY TYPE: WGN SHORT 7; GRADE: HIGH GSL; (3311) FUEL INJ-MACHINE TYPE | 1 | |
| 2133038014 | COVER ASSY - TIMING BELT REAR LOWER, LH | 21330B | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2132142031 | SEAL - OIL | 21321B | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2132142021 | SEAL - OIL | 21321A | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2132142011 | SEAL - OIL | 21321 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 213804A002 | COVER ASSY - TIMING CHAIN UPPER UNDER | 21380D | 04.02.2005 - 26.07.2005 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 213804A005 | COVER ASSY - TIMING CHAIN UPPER UNDER | 21380D | 22.09.2005 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 2131542004 | BRACKET - TOP SHIELD | 21315A | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2435232001 | NUT | 24352 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 2633542001 | CAP - OIL FILTER BRACKET | 26335 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| 2632542011 | VALVE - OIL COOLER BY-PASS | 26325 | 01.11.2002 - 31.12.2006 | BODY TYPE: WGN SHORT 7; GRADE: TOP GRADE; ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| 2632542000 | VALVE - OIL COOLER BY-PASS | 26325 | 01.11.2002 - 31.12.2006 | BODY TYPE: WGN SHORT 7; GRADE: TOP GRADE; ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| 2614842800 | SCREW - MACHINE | 26148 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 6 | |
| 261254A010 | CHAIN SPROCKET - OIL PUMP | 26125B | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 2614442805 | ROTOR - OIL PUMP OUTER | 26113C | 21.09.2003 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2614442804 | ROTOR - OIL PUMP OUTER | 26113C | 01.11.2002 - 21.09.2003 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2614342804 | ROTOR - OIL PUMP INNER | 26112C | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 261004A010 | PUMP ASSY - OIL | 26100 | 03.10.2004 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 261004A000 | PUMP ASSY - OIL | 26100 | 01.11.2002 - 03.10.2004 | ENGINE CAPACITY: D4CB(A ENG); FUEL TYPE: T/C INTER COOLER; TRANSMISSION: 5 SPEED MT 2WD | 1 | |
| 2414135500 | PIN - DOWEL | 24141 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 2 | |
| 2632042905 | BRACKET ASSY - OIL FILTER | 21394 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| 2339147280 | WASHER | 23391 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 2334542000 | GEAR - BALANCER SHAFT DRIVEN | 23345 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2334242500 | GEAR - BALANCER SHAFT DRIVE | 23344 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 233134A400 | GEAR - BALANCER SHAFT DRIVE | 23342 | 29.11.2005 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 233134A000 | GEAR - BALANCER SHAFT DRIVE | 23342 | 01.11.2002 - 29.11.2005 | ENGINE CAPACITY: D4CB(A ENG); FUEL TYPE: T/C INTER COOLER; TRANSMISSION: 5 SPEED MT 2WD | 1 | |
| 233144A000 | CHAIN SPROCKET - BALANCE SHAFT, LH | 23314 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 2334742500 | SLEEVE | 21726D | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2141242061 | GASKET - FRONT CASE, LOWER | 21412A | 03.06.2003 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2141242060 | GASKET - FRONT CASE, LOWER | 21412A | 01.11.2002 - 03.06.2003 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2141142061 | GASKET - FRONT CASE, UPPER | 21411C | 02.06.2003 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2141142060 | GASKET - FRONT CASE, UPPER | 21411C | 01.11.2002 - 02.06.2003 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2132047280 | SEAL - OIL | 21321 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | T=8MM | 1 |
| 2135338001 | GASKET - TIMING BELT COVER | 21353F | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| K995641800 | PACKING | K41800 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 1140308351 | BOLT | 1140FK | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 3 | |
| 1140306101 | BOLT | 1140FZ | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 2WD | FLANGE | 4 |
| 1140308903 | BOLT | 1140FW | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 2 | |
| 1140308703 | BOLT | 1140FT | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 6 | |
| 1140308653 | BOLT | 1140FS | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 1140308553 | BOLT | 1140FR | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 3 | |
| 2136038403 | COVER ASSY - TIMING CHAIN UPPER UNDER | 21380D | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 2WD | 1 | |
| 1140308453 | BOLT | 1140FR | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 2WD | FLANGE | 1 |
| 1140308503 | BOLT | 1140FP | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 6 | |
| 1140308403 | BOLT | 1140FM | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 5 | |
| 1140308303 | BOLT | 1140FJ | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 3 | |
| 1140306143 | BOLT | 1140GG | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 8 | |
| 1140308353 | BOLT | 1140FH | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 4 | |
| 1140308163 | BOLT | 1140FD | 01.11.2002 - 31.12.2006 | BODY TYPE: WGN SHORT 7; GRADE: HIGH GSL; (3311) FUEL INJ-MACHINE TYPE | NEW A/T | 1 |
| 1140306286K | BOLT | 1140ES | 08.04.2005 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 1140306283 | BOLT | 1140ES | 01.11.2002 - 08.04.2005 | ENGINE CAPACITY: 2400 CC | FLANGE | 1 |
| 1140306223 | BOLT | 1140EP | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 9 | |
| 1140308256K | BOLT | 1140EB | 14.12.2006 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 1140308906K | BOLT | 11403A | 01.09.2006 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 2 | |
| 1130206256K | BOLT | 1130DD | 08.04.2005 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 11 | |
| 1130206253 | BOLT | 1130DD | 01.11.2002 - 08.04.2005 | ENGINE CAPACITY: 2400 CC | 11 | |
| 213674A000 | BOLT | 1129EI | 03.03.2003 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 5 | |
| 1140308803 | BOLT | 1140FZ | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 4 | |
| 1140308551 | BOLT | 1140FR | 01.11.2002 - 31.12.2006 | BODY TYPE: WGN SHORT 7; GRADE: HIGH GSL; (3311) FUEL INJ-MACHINE TYPE | 3 | |
| 1140410353 | BOLT | 1140HF | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 1571717121 | PLUG - TAPER | 1571TC | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 1339610003 | NUT | 1339GB | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 1140410603 | BOLT - ..- FLANGE -.. | 1140HL | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | FLANGE 10*25 | 1 |
| 1338606003 | NUT | 1338BA | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 1571710083 | PLUG - TAPER | 1571TA | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 3 | |
| 1540710201 | BOLT - EYE JOINT | 1540TA | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| 1571713111 | PLUG - TAPER | 1571TB | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| 2131038062 | CASE ASSY - FRONT | 21310B | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 1220306251 | SCREW - MACHINE | 1220FS | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 4 | |
| 1151306143 | STUD | 1151CH | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 1151308203 | STUD | 1151CF | 28.08.2006 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 2 | |
| 243824A000 | STUD | 1151CE | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 1151308305 | STUD | 1151CE | 01.11.2002 - 31.12.2006 | BODY TYPE: WGN SHORT 7; GRADE: HIGH GSL; (3311) FUEL INJ-MACHINE TYPE | 2 | |
| 2131042501 | CASE ASSY - FRONT | 21310B | 01.11.2002 - 31.12.2006 | BODY TYPE: WGN SHORT 7; GRADE: HIGH GSL; (3311) FUEL INJ-MACHINE TYPE | 1 | |
| 2512438001 | GASKET - WATER PUMP | 25124 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2141138203 | GASKET - OIL PUMP | 21411A | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2141038200 | GASKET - FRONT CASE | 21411B | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2134042103 | CASE ASSY - OIL PUMP | 21340A | 01.11.2002 - 23.08.2003 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2134042104 | CASE ASSY - OIL PUMP | 21340A | 23.08.2003 - 21.09.2003 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2134042106 | CASE ASSY - OIL PUMP | 21340A | 03.10.2003 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2134042105 | CASE ASSY - OIL PUMP | 21340A | 21.09.2003 - 03.10.2003 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 1140308201 | BOLT | 1140FF | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | FLANGE | 5 |
| 1140308226K | BOLT | 1140FF | 01.09.2006 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| 2614242800 | COVER - OIL PUMP | 21313 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2131338010 | COVER - OIL PUMP | 21313 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 2WD | 1 | |
| 2142133134 | SEAL - OIL | 21421A | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2611238011 | GEAR - OIL PUMP DRIVE | 26112B | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2632642070 | GASKET - OIL FILTER BRACKET | 21396 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| 2139638061 | GASKET - OIL FILTER BRACKET | 21396 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 2WD | 1 | |
| 2139538060 | BRACKET - OIL FILTER | 21395 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 1433108090 | BUSH | 1433CA | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 4 | |
| L2630035500 | FILTER ASSY - ENGINE OIL | 26300 | 01.11.2002 - 15.07.2003 | ENGINE CAPACITY: 2400 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 2WD | 1 | |
| 2630042040 | FILTER ASSY - ENGINE OIL | 26300 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| 2630035501 | FILTER ASSY - ENGINE OIL | 26300 | 15.07.2003 - 31.12.2006 | ENGINE CAPACITY: 2400 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 2WD | 1 | |
| 2630035500 | FILTER ASSY - ENGINE OIL | 26300 | 01.11.2002 - 15.07.2003 | ENGINE CAPACITY: 2400 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 2WD | 1 | |
| L2630042040 | FILTER ASSY - ENGINE OIL | 26300 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| S2630042040 | FILTER ASSY - ENGINE OIL | 26300 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI) | [PRODUCT LINE 2: Not to be used for warranty repair] | 1 |
| 1430306140 | PIN - DOWEL | 1430JC | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 2 | |
| 2611338010 | GEAR - OIL PUMP DRIVEN | 26113B | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2142133114 | SEAL - OIL | 21421 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2142133144 | SEAL - OIL | 21421B | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2113332000 | PLUG - TAPER | 21133 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 2 | |
| 1571613111 | PLUG - TAPER | 1571RB | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 2 | |
| 1601106000 | BALL - STEEL | 1601DC | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2612221000 | PLUNGER - RELIEF | 26122 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2612242500 | PLUNGER - RELIEF | 26122 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2139038000 | O-RING | 21390 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 2WD | 1 | |
| 2139032000 | O-RING | 21390 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2612321000 | SPRING - RELIEF | 26123 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2151311000 | GASKET - OIL PLUG | 21513 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2612411010 | PLUG | 26124 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2139132020 | PLUG - CAP | 21391 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2139132010 | PLUG - CAP | 21391 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 2WD | 1 | |
| 1140308223 | BOLT | 1140FG | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | FLANGE | 12 |
| 1140308456K | BOLT | 1140FN | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 9475037000 | SWITCH ASSY - OIL PRESSURE | 94750 | 03.11.2003 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 9475042000 | SWITCH ASSY - OIL PRESSURE | 94750 | 01.11.2002 - 03.11.2003 | ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| 1140308323 | BOLT - FLANGE | 1140GA | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 2 | |
| 1140306201 | BOLT - FLANGE | 11403C | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2335132000 | BOLT | 23351 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 1140308383 | BOLT | 1140FL | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | FLANGE | 3 |
FRONT CASE; 04/04
| Number | Name | Code | Date_range | Options | Remarks | Qty Required |
|---|---|---|---|---|---|---|
| 1123308163 | BOLT | 1123GT | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2139638061 | GASKET - OIL FILTER BRACKET | 21396 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 2WD | 1 | |
| 233144A000 | CHAIN SPROCKET - BALANCE SHAFT, LH | 23314 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 2334742500 | SLEEVE | 21726D | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2151311000 | GASKET - OIL PLUG | 21513 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2142133144 | SEAL - OIL | 21421B | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2142133134 | SEAL - OIL | 21421A | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2142133114 | SEAL - OIL | 21421 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2141242061 | GASKET - FRONT CASE, LOWER | 21412A | 03.06.2003 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2141242060 | GASKET - FRONT CASE, LOWER | 21412A | 01.11.2002 - 03.06.2003 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2141142061 | GASKET - FRONT CASE, UPPER | 21411C | 02.06.2003 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2141142060 | GASKET - FRONT CASE, UPPER | 21411C | 01.11.2002 - 02.06.2003 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2141038200 | GASKET - FRONT CASE | 21411B | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2141138203 | GASKET - OIL PUMP | 21411A | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2632642070 | GASKET - OIL FILTER BRACKET | 21396 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| 2139538060 | BRACKET - OIL FILTER | 21395 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 233134A400 | GEAR - BALANCER SHAFT DRIVE | 23342 | 29.11.2005 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 2632042905 | BRACKET ASSY - OIL FILTER | 21394 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| 2139132020 | PLUG - CAP | 21391 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2139132010 | PLUG - CAP | 21391 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 2WD | 1 | |
| 2139038000 | O-RING | 21390 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 2WD | 1 | |
| 2139032000 | O-RING | 21390 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 213804A005 | COVER ASSY - TIMING CHAIN UPPER UNDER | 21380D | 22.09.2005 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 213804A003 | COVER ASSY - TIMING CHAIN UPPER UNDER | 21380D | 26.07.2005 - 22.09.2005 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 213804A002 | COVER ASSY - TIMING CHAIN UPPER UNDER | 21380D | 04.02.2005 - 26.07.2005 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 213804A001 | COVER ASSY - TIMING CHAIN UPPER UNDER | 21380D | 10.11.2002 - 04.02.2005 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 213804A000 | COVER ASSY - TIMING CHAIN UPPER UNDER | 21380D | 01.11.2002 - 10.11.2002 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 2136038403 | COVER ASSY - TIMING CHAIN UPPER UNDER | 21380D | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 2WD | 1 | |
| 213704A000 | COVER ASSY - TIMING CHAIN LOWER UNDER | 21370D | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 213604A000 | COVER ASSY - TIMING CHAIN UPPER FRONT | 21360D | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 233134A000 | GEAR - BALANCER SHAFT DRIVE | 23342 | 01.11.2002 - 29.11.2005 | ENGINE CAPACITY: D4CB(A ENG); FUEL TYPE: T/C INTER COOLER; TRANSMISSION: 5 SPEED MT 2WD | 1 | |
| 2334242500 | GEAR - BALANCER SHAFT DRIVE | 23344 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 213504A000 | COVER ASSY - TIMING CHAIN LOWER FRONT | 21350D | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 2612411010 | PLUG | 26124 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 9475042000 | SWITCH ASSY - OIL PRESSURE | 94750 | 01.11.2002 - 03.11.2003 | ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| 9475037000 | SWITCH ASSY - OIL PRESSURE | 94750 | 03.11.2003 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2633542001 | CAP - OIL FILTER BRACKET | 26335 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| 2632542011 | VALVE - OIL COOLER BY-PASS | 26325 | 01.11.2002 - 31.12.2006 | BODY TYPE: WGN SHORT 7; GRADE: TOP GRADE; ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| 2632542000 | VALVE - OIL COOLER BY-PASS | 26325 | 01.11.2002 - 31.12.2006 | BODY TYPE: WGN SHORT 7; GRADE: TOP GRADE; ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| S2630042040 | FILTER ASSY - ENGINE OIL | 26300 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI) | [PRODUCT LINE 2: Not to be used for warranty repair] | 1 |
| L2630042040 | FILTER ASSY - ENGINE OIL | 26300 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| L2630035500 | FILTER ASSY - ENGINE OIL | 26300 | 01.11.2002 - 15.07.2003 | ENGINE CAPACITY: 2400 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 2WD | 1 | |
| 2630042040 | FILTER ASSY - ENGINE OIL | 26300 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| 2630035501 | FILTER ASSY - ENGINE OIL | 26300 | 15.07.2003 - 31.12.2006 | ENGINE CAPACITY: 2400 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 2WD | 1 | |
| 2630035500 | FILTER ASSY - ENGINE OIL | 26300 | 01.11.2002 - 15.07.2003 | ENGINE CAPACITY: 2400 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 2WD | 1 | |
| 2614842800 | SCREW - MACHINE | 26148 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 6 | |
| 261254A010 | CHAIN SPROCKET - OIL PUMP | 26125B | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 2612321000 | SPRING - RELIEF | 26123 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2334542000 | GEAR - BALANCER SHAFT DRIVEN | 23345 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2612242500 | PLUNGER - RELIEF | 26122 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2612221000 | PLUNGER - RELIEF | 26122 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2614442805 | ROTOR - OIL PUMP OUTER | 26113C | 21.09.2003 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2614442804 | ROTOR - OIL PUMP OUTER | 26113C | 01.11.2002 - 21.09.2003 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2611338010 | GEAR - OIL PUMP DRIVEN | 26113B | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2614342804 | ROTOR - OIL PUMP INNER | 26112C | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2611238011 | GEAR - OIL PUMP DRIVE | 26112B | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 261004A010 | PUMP ASSY - OIL | 26100 | 03.10.2004 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 261004A000 | PUMP ASSY - OIL | 26100 | 01.11.2002 - 03.10.2004 | ENGINE CAPACITY: D4CB(A ENG); FUEL TYPE: T/C INTER COOLER; TRANSMISSION: 5 SPEED MT 2WD | 1 | |
| 2512438001 | GASKET - WATER PUMP | 25124 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2435232001 | NUT | 24352 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 2414135500 | PIN - DOWEL | 24141 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 2 | |
| 2339147280 | WASHER | 23391 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 2335132000 | BOLT | 23351 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 1129308183 | BOLT | 1129EI | 01.11.2002 - 03.03.2003 | ENGINE CAPACITY: D4CB(A ENG) | 5 | |
| K995641800 | PACKING | K41800 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2134042106 | CASE ASSY - OIL PUMP | 21340A | 03.10.2003 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 1140308453 | BOLT | 1140FR | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 2WD | FLANGE | 1 |
| 1338606003 | NUT | 1338BA | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 1151306143 | STUD | 1151CH | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 1151308203 | STUD | 1151CF | 28.08.2006 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 2 | |
| 243824A000 | STUD | 1151CE | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 1151308305 | STUD | 1151CE | 01.11.2002 - 31.12.2006 | BODY TYPE: WGN SHORT 7; GRADE: HIGH GSL; (3311) FUEL INJ-MACHINE TYPE | 2 | |
| 1140410603 | BOLT - ..- FLANGE -.. | 1140HL | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | FLANGE 10*25 | 1 |
| 1140410353 | BOLT | 1140HF | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 1140306143 | BOLT | 1140GG | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 8 | |
| 1140308323 | BOLT - FLANGE | 1140GA | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 2 | |
| 1140308903 | BOLT | 1140FW | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 2 | |
| 1140308703 | BOLT | 1140FT | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 6 | |
| 1140308653 | BOLT | 1140FS | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 1140308553 | BOLT | 1140FR | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 3 | |
| 1140308551 | BOLT | 1140FR | 01.11.2002 - 31.12.2006 | BODY TYPE: WGN SHORT 7; GRADE: HIGH GSL; (3311) FUEL INJ-MACHINE TYPE | 3 | |
| 1140308503 | BOLT | 1140FP | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 6 | |
| 1430306140 | PIN - DOWEL | 1430JC | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 2 | |
| 1140308201 | BOLT | 1140FF | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | FLANGE | 5 |
| 213674A000 | BOLT | 1129EI | 03.03.2003 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 5 | |
| 1140308906K | BOLT | 11403A | 01.09.2006 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 2 | |
| 1140306201 | BOLT - FLANGE | 11403C | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 1140308256K | BOLT | 1140EB | 14.12.2006 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 1140306223 | BOLT | 1140EP | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 9 | |
| 1140308163 | BOLT | 1140FD | 01.11.2002 - 31.12.2006 | BODY TYPE: WGN SHORT 7; GRADE: HIGH GSL; (3311) FUEL INJ-MACHINE TYPE | NEW A/T | 1 |
| 1140308226K | BOLT | 1140FF | 01.09.2006 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| 1140308456K | BOLT | 1140FN | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 1140308223 | BOLT | 1140FG | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | FLANGE | 12 |
| 1140308353 | BOLT | 1140FH | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 4 | |
| 1140308303 | BOLT | 1140FJ | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 3 | |
| 1140308351 | BOLT | 1140FK | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 3 | |
| 1140308383 | BOLT | 1140FL | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | FLANGE | 3 |
| 1140308403 | BOLT | 1140FM | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 5 | |
| 1339610003 | NUT | 1339GB | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 1 | |
| 1220306251 | SCREW - MACHINE | 1220FS | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 4 | |
| 1433108090 | BUSH | 1433CA | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 4 | |
| 2614242800 | COVER - OIL PUMP | 21313 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2134042104 | CASE ASSY - OIL PUMP | 21340A | 23.08.2003 - 21.09.2003 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2133042000 | BRACKET - FRONT CASE SUPPORT | 21330C | 01.11.2002 - 31.12.2006 | BODY TYPE: WGN SHORT 7; GRADE: HIGH GSL; (3311) FUEL INJ-MACHINE TYPE | 1 | |
| 1540710201 | BOLT - EYE JOINT | 1540TA | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| 2132142031 | SEAL - OIL | 21321B | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2132142021 | SEAL - OIL | 21321A | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2132142011 | SEAL - OIL | 21321 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2132047280 | SEAL - OIL | 21321 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | T=8MM | 1 |
| 2131542004 | BRACKET - TOP SHIELD | 21315A | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2134042103 | CASE ASSY - OIL PUMP | 21340A | 01.11.2002 - 23.08.2003 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 2131338010 | COVER - OIL PUMP | 21313 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 2WD | 1 | |
| 2131042501 | CASE ASSY - FRONT | 21310B | 01.11.2002 - 31.12.2006 | BODY TYPE: WGN SHORT 7; GRADE: HIGH GSL; (3311) FUEL INJ-MACHINE TYPE | 1 | |
| 2131038062 | CASE ASSY - FRONT | 21310B | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2113332000 | PLUG - TAPER | 21133 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 2 | |
| 1601106000 | BALL - STEEL | 1601DC | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 1571717121 | PLUG - TAPER | 1571TC | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 1571713111 | PLUG - TAPER | 1571TB | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4BH(4D56 TCI) | 1 | |
| 1571710083 | PLUG - TAPER | 1571TA | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 3 | |
| 2134042105 | CASE ASSY - OIL PUMP | 21340A | 21.09.2003 - 03.10.2003 | ENGINE CAPACITY: D4BH(4D56 TCI); (3312) FUEL INJ-ELECTRIC TYPE | 1 | |
| 1571613111 | PLUG - TAPER | 1571RB | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 2 | |
| 2137538201 | COVER - TIMING BELT, REAR, RH | 21375 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2136038403 | COVER ASSY - TIMING BELT UPPER | 21360A | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2133238200 | COVER - TIMING BELT, REAR UPPER, LH | 21332 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 1140308803 | BOLT | 1140FZ | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: D4CB(A ENG) | 4 | |
| 1140306101 | BOLT | 1140FZ | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC; FUEL TYPE: MPI-DOHC; TRANSMISSION: 5 SPEED MT 2WD | FLANGE | 4 |
| 2136338201 | GASKET - TIMING BELT COVER | 21363F | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2133038014 | COVER ASSY - TIMING BELT REAR LOWER, LH | 21330B | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2137238004 | GASKET - TIMING BELT COVER | 21372B | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2137138014 | GASKET - TIMING BELT COVER | 21371A | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2136438401 | GASKET 3 - TIMING BELT COVER UPPER | 21365E | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2135238001 | GASKET - TIMING BELT COVER | 21352C | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2136438002 | GASKET - TIMING BELT COVER UPPER | 21363B | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2135438401 | GASKET - TIMING BELT COVER LOWER | 21354C | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2135838003 | GASKET - TIMING BELT COVER | 21358 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2135038402 | COVER ASSY - TIMING BELT LOWER | 21350 | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 2135338001 | GASKET - TIMING BELT COVER | 21353F | 01.11.2002 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 1140306286K | BOLT | 1140ES | 08.04.2005 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 1 | |
| 1140306283 | BOLT | 1140ES | 01.11.2002 - 08.04.2005 | ENGINE CAPACITY: 2400 CC | FLANGE | 1 |
| 1130206256K | BOLT | 1130DD | 08.04.2005 - 31.12.2006 | ENGINE CAPACITY: 2400 CC | 11 | |
| 1130206253 | BOLT | 1130DD | 01.11.2002 - 08.04.2005 | ENGINE CAPACITY: 2400 CC | 11 |
