TRANSMISSION
MANUAL TRANSMISSION GEAR
| Number | Name | Code | Date_range | Remarks | Qty Required |
|---|---|---|---|---|---|
| 433724B000 | KEY - SYNCHRONIZER | 43372A | 18.08.1997 - ... | 6 | |
| 432604B000 | GEAR ASSY - 3RD SPEED | 43260 | 18.08.1997 - ... | 1 | |
| 4325343010 | BEARING - MANUAL TRANSMISSION 2ND GEAR | 43253A | 18.08.1997 - ... | 1 | |
| 433944B000 | RING - SYNCHRONIZER (3RD) | 43374A | 18.08.1997 - ... | 1 | |
| 433764B001 | SLEEVE - SYNCHRONIZER | 43376 | 18.08.1997 - ... | 1 | |
| 4344543101 | NUT - BEARING LOCK | 43445 | 18.08.1997 - ... | 1 | |
| 433514B000 | HUB - SYNCHRONIZER | 43351 | 01.04.1999 - ... | 1 | |
| 4335133000 | HUB - SYNCHRONIZER | 43351 | 18.08.1997 - 01.04.1999 | 1 | |
| MD703798 | BEARING - BALL | 43222A | 18.08.1997 - ... | 1 | |
| 4322244000 | BEARING | 43222A | 18.08.1997 - 01.02.1999 | 1 | |
| 4322244040 | BEARING | 43222A | 01.02.1999 - ... | 1 | |
| 433844B000 | RING - SYNCHRONIZER | 43374 | 18.08.1997 - ... | 2 | |
| 4341443102 | GEAR - COUNTERSHAFT OVER TOP | 43414 | 18.08.1997 - ... | 1 | |
| 4336111150 | RING - SNAP | 43361 | 18.08.1997 - ... | T=2.15 | 1 |
| 4336111220 | RING - SNAP | 43361 | 18.08.1997 - ... | T=2.22 | 1 |
| 4336111290 | RING - SNAP | 43361 | 18.08.1997 - ... | T=2.29 | 1 |
| 4336111360 | RING - SNAP | 43361 | 18.08.1997 - ... | T=2.36 | 1 |
| 4344244000 | SPACER | 43442 | 18.08.1997 - ... | 1 | |
| 4328333003 | SLEEVE - 1ST GEAR BEARING | 43283 | 18.08.1997 - ... | 1 | |
| 4328333000 | SLEEVE - 1ST GEAR BEARING | 43283 | 18.08.1997 - ... | 1 | |
| 4325244910 | BEARING | 43252 | 18.08.1997 - ... | 1 | |
| 4341344000 | GEAR - COUNTERSHAFT REVERSE | 43413 | 18.08.1997 - ... | 1 | |
| 4321043102 | GEAR ASSY - MAIN DRIVE | 43210 | 18.08.1997 - ... | 1 | |
| 4344644000 | SPACER | 43446 | 18.08.1997 - ... | 1 | |
| MD712954 | SPACER | 43446 | 18.08.1997 - ... | 1 | |
| 433864B000 | RING - SYNCHRONIZER | 43374B | 18.08.1997 - ... | 1 | |
| 4321721530 | SPACER | 43217 | 18.08.1997 - ... | T=2.53 | 1 |
| 4321721200 | SPACER | 43217 | 18.08.1997 - ... | T=2.20 | 1 |
| 4321721020 | SPACER | 43217 | 18.08.1997 - ... | T=2.02 | 1 |
| 4321721050 | SPACER | 43217 | 18.08.1997 - ... | T=2.05 | 1 |
| 4321721080 | SPACER | 43217 | 18.08.1997 - ... | T=2.08 | 1 |
| 4321721110 | SPACER | 43217 | 18.08.1997 - ... | T=2.11 | 1 |
| 4321721140 | SPACER | 43217 | 18.08.1997 - ... | T=2.14 | 1 |
| 4321721170 | SPACER | 43217 | 18.08.1997 - ... | T=2.17 | 1 |
| 4321721230 | SPACER | 43217 | 18.08.1997 - ... | T=2.23 | 1 |
| 4321721260 | SPACER | 43217 | 18.08.1997 - ... | T=2.26 | 1 |
| 4321721290 | SPACER | 43217 | 18.08.1997 - ... | T=2.29 | 1 |
| 4321721320 | SPACER | 43217 | 18.08.1997 - ... | T=2.32 | 1 |
| 4321721410 | SPACER | 43217 | 18.08.1997 - ... | T=2.41 | 1 |
| 4321721440 | SPACER | 43217 | 18.08.1997 - ... | T=2.44 | 1 |
| 4321721470 | SPACER | 43217 | 18.08.1997 - ... | T=2.47 | 1 |
| 4321721500 | SPACER | 43217 | 18.08.1997 - ... | T=2.50 | 1 |
| 4321721560 | SPACER | 43217 | 18.08.1997 - ... | T=2.56 | 1 |
| 4322144001 | BEARING | 43221A | 18.08.1997 - ... | 1 | |
| 4322144010 | BEARING | 43221A | 18.08.1997 - ... | 1 | |
| 433754B000 | SLEEVE - SYNCHRONIZER | 43373A | 18.08.1997 - ... | 1 | |
| 4324111930 | SPACER | 43241 | 18.08.1997 - ... | T=0.93 | 1 |
| 4324111110 | SPACER | 43241 | 18.08.1997 - ... | T=1.11 | 1 |
| 4324111380 | SPACER | 43241 | 18.08.1997 - ... | T=1.29 | 1 |
| 4324111200 | SPACER | 43241 | 18.08.1997 - ... | T=1.20 | 1 |
| 4324111290 | SPACER | 43241 | 18.08.1997 - ... | T=1.29 | 1 |
| 4324111020 | SPACER | 43241 | 18.08.1997 - ... | T=1.02 | 1 |
| 4324111840 | SPACER | 43241 | 18.08.1997 - ... | T=0.84 | 1 |
| 433524B000 | HUB - SYNCHRONIZER | 43352 | 01.04.1999 - ... | 1 | |
| 4335233000 | HUB - SYNCHRONIZER | 43352 | 18.08.1997 - 01.04.1999 | 1 | |
| 4323111300 | RING - SNAP | 43231 | 18.08.1997 - ... | T=2.3 | 1 |
| 4323111400 | RING - SNAP | 43231 | 18.08.1997 - ... | T=2.4 | 1 |
| 4323111450 | RING - SNAP | 43231 | 18.08.1997 - ... | T=2.45 | 1 |
| 4323111500 | RING - SNAP | 43231 | 18.08.1997 - ... | T=2.5 | 1 |
| 4323111350 | RING - SNAP | 43231 | 18.08.1997 - ... | T=2.35 | 1 |
| 433874B000 | SPRING - SYNCHRONIZER | 43378 | 18.08.1997 - ... | 2 | |
| 433744B000 | RING - SYNCHRONIZER | 43377 | 18.08.1997 - ... | 1 | |
| 4328243010 | BEARING | 43282 | 18.08.1997 - ... | 2 | |
| MD703774 | GEAR ASSY - 2ND | 43270A | 18.08.1997 - ... | 1 | |
| 4327033000 | GEAR ASSY - 2ND SPEED | 43270A | 18.08.1997 - ... | 2 | |
| 4341143101 | GEAR - COUNTERSHAFT CLUSTER | 43411 | 18.08.1997 - ... | 1 | |
| 1601106000 | BALL - STEEL | 16011 | 18.08.1997 - ... | 2 | |
| MF540006 | BALL - STEEL | 16011 | 18.08.1997 - ... | 1 | |
| 4328733000 | NUT - LOCKING | 43287 | 18.08.1997 - ... | 1 | |
| 4325143900 | SHAFT - MAIN | 43251 | 18.08.1997 - ... | 1 | |
| MD703787 | SPACER | 43297 | 18.08.1997 - ... | 1 | |
| 4329733000 | SPACER - BEARING | 43297 | 18.08.1997 - ... | 1 | |
| 433734B000 | KEY - SYNCHRONIZER | 43372B | 18.08.1997 - ... | 3 | |
| MD703786 | SLEEVE-O/D GEAR BEARING | 43294 | 18.08.1997 - ... | 1 | |
| 4329433000 | SLEEVE - OVER TOP SPEED GEAR | 43294 | 18.08.1997 - ... | 1 | |
| 4329043101 | GEAR ASSY - OVER TOP | 43290 | 18.08.1997 - ... | 1 | |
| 4344144010 | BEARING - COUNTER FRONT | 43441 | 18.08.1997 - ... | 2 | |
| 1430004301 | PIN | 14300 | 18.08.1997 - ... | 1 | |
| MF472085 | PIN | 14300 | 18.08.1997 - ... | 1 | |
| 4329343010 | BEARING - NEEDLE | 43293 | 18.08.1997 - ... | 1 | |
| 1314116001 | NUT - SLOTTED | 13141 | 18.08.1997 - ... | 1 | |
| 4328944000 | SPACER | 43289 | 18.08.1997 - ... | 1 | |
| 4352444000 | WASHER - THRUST REAR | 43524 | 18.08.1997 - ... | 1 | |
| MD714388 | WASHER - THRUST | 43524 | 18.08.1997 - ... | 1 | |
| 433754B010 | SLEEVE - SYNCHRONIZER | 43375 | 23.03.1999 - ... | 1 | |
| 433754B000 | SLEEVE - SYNCHRONIZER | 43375 | 17.02.1996 - 23.03.1999 | 1 | |
| 433774B000 | SLEEVE - SYNCHRONIZER | 43375 | 18.08.1997 - ... | 1 | |
| MD715770 | GEAR-REV IDDLER | 43512 | 18.08.1997 - ... | 1 | |
| 4351244000 | GEAR - REVERSE IDLER | 43512 | 18.08.1997 - ... | 1 | |
| MD704449 | BOLT | 43122 | 18.08.1997 - ... | 1 | |
| 4312244000 | BOLT | 43122 | 18.08.1997 - ... | 4 | |
| 433534B000 | HUB - SYNCHRONIZER | 43353 | 01.01.1999 - ... | 1 | |
| 4335343100 | HUB - SYNCHRONIZER | 43353 | 18.08.1997 - 01.01.1999 | 1 | |
| 4352244010 | BEARING | 43522 | 18.08.1997 - ... | 2 | |
| 4338734002 | SPRING - SYNCHRONIZER | 43371A | 18.08.1997 - ... | 4 | |
| 432314B000 | GEAR ASSY - REVERSE | 43247 | 18.08.1997 - ... | 1 | |
| 4327644000 | SLEEVE | 43276 | 18.08.1997 - ... | 1 | |
| 433214B000 | SHAFT - REVERSE IDLER GEAR | 43321 | 18.08.1997 - ... | 1 | |
| 4327544010 | BEARING - NEEDLE | 43275 | 18.08.1997 - ... | 1 | |
| 4328643100 | BEARING - DOUBLE LOW | 43286 | 18.08.1997 - 01.01.1999 | 1 | |
| 4328643130 | BEARING - DOUBLE LOW | 43286 | 01.01.1999 - ... | 1 | |
| 4328143100 | GEAR ASSY - 1ST SPEED | 43281 | 18.08.1997 - ... | 1 |
